The HKShanhai Group Limited TNF1SBM1M02 is a 1-channel Add/Drop Multiplexer optimized for innovative single fiber-based communication. Operating on two coarse wavelength division multiplexing (CWDM) wavelengths, 1471nm and 1491nm, this product, categorized as a B Side model, ensures efficient and reliable data transmission, making it suitable for modern network infrastructure needs.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | TNF1SBM1M02 |
| Channels | 1 |
| Wavelengths | 1471nm, 1491nm |
| Fiber Type | Single Fiber |
Product Features
- Optimized for CWDM technology
- Single Fiber operation enhances bandwidth efficiency
- Simple plug-and-play design for easy installation
- Supports Add/Drop Multiplexing for flexible network configurations
- Compact design for space-saving deployments
Product Applications
- Telecommunication network infrastructure
- Enterprise data centers and interconnects
- Metropolitan Area Network (MAN) solutions
Supported Options
| Accessory | Model |
| Fiber Optic Patch Cable | FOPC-HUA-001 |
| CWDM Mux/Demux Module | CWDM-MOD-123 |
| Optical Power Meter | OPM-HUA-456 |
Compare to Similar Items
| Model | Difference |
| TNF1SBM1M01 | Operates at different wavelengths (OBU) |
| TNF1SBM1M03 | Supports dual fiber operations |
| TNF1SBM1M04 | Includes inbuilt Error Correction Code (ECC) |
Get more information
Check HKShanhai Group Limited TNF1SBM1M02 price and TNF1SBM1M02 datasheet, buy HKShanhai Group Limited TNF1SBM1M02 with best price and fast shipping. Free Live Chat are supported. For further information about the product and its price, contact us through Live Chat or sales@router-switch.com.
HKShanhai Group Limited TNF1SBM1M02 Specification
TNF1SBM1M02 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | TNF1SBM1M02 |
| Product Type | Add/Drop Multiplexer |
| Channel Configuration | 1-ch |
| Fiber Type | Single Fiber |
| Side | B Side |
| Wavelengths Supported | 1471nm, 1491nm |
| Technology | CWDM |
| Insertion Loss | < 1.0 dB |
| Isolation | > 30 dB (channel), > 40 dB (com) |
| Return Loss | > 45 dB |
| Directivity | > 50 dB |
| Polarization Dependent Loss (PDL) | < 0.2 dB |
| Polarization Mode Dispersion (PMD) | < 0.1 ps |
| Operating Temperature Range | -5°C to 65°C |
| Storage Temperature Range | -40°C to 85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Dimensions | 120 mm x 80 mm x 20 mm |
| Connector Type | LC/UPC |
| Compliance | RoHS |
| Application | Telecommunications, Data Centers |
