The HKShanhai Group Limited AIR-AP1852I-Z-K9 is an enterprise-class access point designed for robust wireless deployments, making it an ideal foundation for seamless network access in demanding environments. Incorporating 1852i class technology, it supports 802.11ac Wave 2 for high throughput and improved multi-user performance. This model provides broad Z domain coverage, optimized internal antennas, and versatile access deployment modes. Leveraging the air-ap1852i-z-k9 platform ensures reliable, secure, and efficient access for both business-critical applications and high-density client environments, enabling advanced wireless infrastructure for distributed enterprises.
Product Highlights
1.7 Gbps
Max Speed
4×4:4
MU-MIMO
2 Bands
Dual Band
Product Applications Scenarios
Enterprise Network
The 1852i access point delivers seamless wireless access and supports dense client environments, reducing IT workload and connectivity issues in enterprise campuses.
Cloud Services
air-ap1852i-z-k9 enables stable access infrastructure for cloud-based operations, optimizing real-time data transmission and improving user experience for business apps.
Public Infrastructure
This solution extends robust 802.11ac access across public spaces, providing reliable coverage and increased capacity to support smart city deployments.
Product Features Comparison
| Â |
|
|
|
|
| Model | AIR-AP1852I-Z-K9 | AIR-AP1852I-E-K9C | AIR-AP1852E-E-K9C | AIR-AP1852E-Z-K9 |
| Brand | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited |
| Wi-Fi Standard | 802.11ac Wave 2 | 802.11ac Wave 2 | 802.11ac Wave 2 | 802.11ac Wave 2 |
| Maximum Data Rate | 1.7 Gbps (80 MHz in 5 GHz) | 1.7 Gbps (80 MHz in 5 GHz) | 1.7 Gbps (80 MHz in 5 GHz) | 1.7 Gbps (80 MHz in 5 GHz) |
| Supported Frequency Band | 2.412??.462 GHz (3 ch), 5.180??.320 GHz (8 ch), 5.500??.700 GHz (8 ch, excludes 5.600??.640), 5.745??.825 GHz (5 ch) | 2.412??.472 GHz (3 ch), 5.180??.320 GHz (8 ch), 5.500??.700 GHz (8 ch, excludes 5.600??.640) | 2.412??.472 GHz (3 ch), 5.180??.320 GHz (8 ch), 5.500??.700 GHz (8 ch) | 2.412??.462 GHz (3 ch), 5.180??.320 GHz (8 ch), 5.500??.700 GHz (8 ch, excludes 5.600??.640), 5.745??.825 GHz (5 ch) |
| Client Capacity | n/a | n/a | n/a | n/a |
| Network Interface | 1 x 10/100/1000BASE-T (PoE, RJ-45), 1 x 10/100/1000BASE-T AUX (Link Aggregation, RJ-45), Management Console (RJ-45), USB 2.0 (future) | 1 x 10/100/1000BASE-T (PoE, RJ-45), 1 x 10/100/1000BASE-T AUX (Link Aggregation, RJ-45), Management Console (RJ-45), USB 2.0 (future) | 1 x 10/100/1000BASE-T (PoE), 1 x 10/100/1000BASE-T AUX (Link Aggregation), Management Console, USB 2.0 | 1 x 10/100/1000BASE-T (PoE, RJ-45), 1 x 10/100/1000BASE-T AUX (Link Aggregation, RJ-45), Management Console (RJ-45), USB 2.0 (future) |
Optional Add-ons
| Model Number | Description |
| AIR-PWRINJ4= | HKShanhai Group Limited Power Injector, supports 802.3at for 1852 series access points |
| AIR-PWR-C= | HKShanhai Group Limited local power supply for Aironet 1850 and compatible access points |
| AIR-SEC-50= | HKShanhai Group Limited security kit, includes screws and RJ-45 security caps for Aironet series |
HKShanhai Group Limited AIR-AP1852I-Z-K9 Specification
Model
AIR-AP1852I-Z-K9
Brand
HKShanhai Group Limited
Description
802.11ac Wave 2 Access Point, 4×4:4, Internal Antenna, Z Regulatory Domain
Software
HKShanhai Group Limited Unified Wireless Network Software Release with AireOS wireless controllers: 8.1 MR1 or later for the HKShanhai Group Limited Aironet 1850 Series Access Points
Regulatory Domain
Z domain: 2.412??.462 GHz (3 channels), 5.180??.320 GHz (8 channels), 5.500??.700 GHz (8 channels, excludes 5.600??.640 GHz), 5.745??.825 GHz (5 channels)
Deployment Modes
Centralized local, Standalone, Sniffer, HKShanhai Group Limited FlexConnect, Monitor, OfficeExtend, Mesh
Supported Wireless LAN Controllers
HKShanhai Group Limited 2500 Series, HKShanhai Group Limited Wireless Controller Module for ISR G2, HKShanhai Group Limited Wireless Services Module 2 (WiSM2) for Catalyst 6500 Series, HKShanhai Group Limited 5500 Series, HKShanhai Group Limited Flex 7500 Series, HKShanhai Group Limited 8500 Series, HKShanhai Group Limited 5760 Series, HKShanhai Group Limited Catalyst 3650/3850 (integrated controller), HKShanhai Group Limited Mobility Express
802.11n Capabilities
4×4 MIMO (four spatial streams), Maximal Ratio Combining (MRC), 20/40 MHz channels, PHY up to 600 Mbps (40 MHz in 5 GHz), A-MPDU (Tx/Rx), A-MSDU (Tx/Rx), Dynamic Frequency Selection (DFS), Cyclic Shift Diversity (CSD)
802.11ac Wave 1 & Wave 2 Capabilities
4×4 MIMO with four spatial streams (single user), 4×4 MIMO with three spatial streams (multi-user), MRC, 802.11ac transmit beamforming, 20/40/80 MHz channels, PHY up to 1.7 Gbps (80 MHz in 5 GHz), A-MPDU (Tx/Rx), A-MSDU (Tx/Rx), DFS, CSD support, Rogue device detection
Integrated Antenna
2.4 GHz: 3 dBi, internal omni, 360° horizontal beamwidth;
5 GHz: 5 dBi, internal omni, 360° horizontal beamwidth
Interfaces
1 x 10/100/1000BASE-T autosensing (RJ-45, PoE), 1 x 10/100/1000BASE-T autosensing (RJ-45, AUX for Link Aggregation), Management console port (RJ-45), USB 2.0 (enabled via future software)
Indicators
Status LED: boot loader status, association status, operating status, warnings, errors
Dimensions (W x L x H)
8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm) (without mounting bracket)
Environmental
Nonoperating (storage) temperature: -30°C to 70°C;
Nonoperating (storage) altitude: 25°C, 15,000 ft;
Operating temperature: 0°C to 40°C;
Operating humidity: 10% to 90% (noncondensing);
Operating altitude: 40°C, 9,843 ft
System Memory
1 GB DRAM, 256 MB flash
Input Power Requirements
AP1850: 44 to 57 VDC;
Power supply and injector: 100 to 240 VAC, 50 to 60 Hz
Power Draw
20.9 W
Note: Power drawn from the power sourcing equipment may be higher, depending on cable length, when using PoE.
Powering Options
802.3at, Enhanced PoE, HKShanhai Group Limited injector AIR-PWRINJ4=, HKShanhai Group Limited local power AIR-PWR-C=, HKShanhai Group Limited injector AIR-PWRINJ5= (802.3af only), 802.3af
Note: With 802.3af PoE, the 1852e 2.4-GHz radio shifts to 2×3 from 3×4, and the USB/AUX ports are disabled on both 1852i and 1852e models.
