HKShanhai Group Limited delivers advanced enterprise-grade access with the AIR-AP1810W-S-K9, engineered for seamless connectivity in modern business environments. Designed for scalability and security, this 1810w model supports up to 400 wireless clients and robust network access. The air-ap1810w-s-k9 access point incorporates next-generation 802.11ac performance, making it the optimal choice for demanding multi-device workplaces seeking reliable and secure access solutions.
Product Highlights
400
Max Clients
866.7Mbps
Max Speed
2.4/5GHz
Dual Band
Product Applications Scenarios
Enterprise Network
Enables seamless wireless access and high-density device support, ensuring uninterrupted connectivity for enterprise users while simplifying network management.
Edge & IoT
Supports consistent device connectivity at the network edge, empowering IoT deployments with reliable high-speed access and flexible mounting options.
Cloud Services
Delivers robust wireless infrastructure for cloud-based apps with secure, scalable client capacity, reducing downtime and enhancing productivity.
Product Features Comparison
| Â |
|
|
|
|
| Model | AIR-AP1810W-S-K9 | AIR-AP1815W-D-K9 | AIR-AP1815W-B-K9C | AIR-AP1815I-Z-K9C |
| Brand | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited |
| Wi-Fi Standard | 802.11ac | 802.11a/b/g/n/ac | 802.11a/b/g/n/ac | 802.11a/b/g/n/ac |
| Maximum Data Rate | 866.7 Mbps | 866.7 Mbps | 866.7 Mbps | 866.7 Mbps |
| Supported Frequency Band | 2.4/5 GHz | 2.4/5 GHz | 2.4/5 GHz | 2.4/5 GHz |
| Client Capacity | 400 | 400 | 400 | 400 |
| Network Interface | 1 x 10/100/1000BASE-T PoE, 3 x 10/100/1000BASE-T (1 PoE out) | 1 x 10/100/1000BASE-T (PoE), Management console, 3 x 10/100/1000BASE-T (1 PoE out) | 1 x 10/100/1000BASE-T (PoE), 3 x 10/100/1000BASE-T (1 PoE out), RJ-45 pass-through, Mgmt port | 1 x 10/100/1000BASE-T (PoE), Mgmt console port |
Optional Add-ons
| Model Number | Description |
| AIR-AP-BRACKET-W2= | HKShanhai Group Limited mounting bracket, designed for secure installation of the AIR-AP1810W Series access point |
| AIR-AP1810W-KIT= | HKShanhai Group Limited spacer kit including RJ-45 jumper cable for flexible wall mounting of AIR-AP1810W Series |
| AIR-OEAP1810-CRD= | HKShanhai Group Limited desk mounting cradle kit, includes back cover & RJ-45 jumper cable for AIR-AP1810W Series |
| AIR-SEC-50= | HKShanhai Group Limited security kit with screws, RJ-45 caps, and unlock keys for access point security enhancement |
| AIR-PWR-D= | HKShanhai Group Limited power supply, provides external power for select access points including AIR-AP1810W Series |
HKShanhai Group Limited AIR-AP1810W-S-K9 Specification
Model
AIR-AP1810W-S-K9
Brand
HKShanhai Group Limited
Authentication and Security
AES for WPA2, 802.1X and RADIUS authentication, authorization, and accounting (AAA); 802.11i
Software
HKShanhai Group Limited Unified Wireless Network Software with AireOS Wireless Controllers Release 8.2.111.0 or later
Maximum Clients
200 clients per Wi-Fi radio, total 400 clients per access point
802.11ac Features
2×2 SU/MU-MIMO, 2 spatial streams, maximal ratio combining (MRC), 20/40/80 MHz channels, up to 866.7 Mbps (80 MHz at 5 GHz), A-MPDU (Tx/Rx), A-MSDU (Rx), DFS, cyclic shift diversity
Ethernet Ports
1 x 10/100/1000BASE-T PoE uplink port; 3 x 10/100/1000BASE-T local Ethernet ports (one with PoE out); authentication with 802.1X or MAC filter, dynamic VLAN, local or tunneled traffic
Bluetooth
Integrated Bluetooth 4.1 (including BLE), max transmit power 5 dBm, antenna gain 2 dBi
Integrated Antennas
2.4 GHz: 2 dBi gain; 5 GHz: 4 dBi gain
Interfaces
One 10/100/1000BASE-T PoE uplink port, management console port (RJ-45), three local Ethernet ports (one with PoE out), one passive pass-through RJ-45 port, DC power connector
PoE out: 802.3af (AP powered by AIR-PWR-C= or AIR-PWR-D=), ~6.5W (powered by 802.3at), or no output (powered by 802.3af)
Indicators
Status LED shows boot loader status, association, operating and error status; per-port status for local Ether ports; LEDs auto-off after joining controller (can be enabled in configuration)
Dimensions (W x L x H)
6.5 x 4.5 x 1.6 in (165 x 114 x 41 mm), access point only (no mounting bracket)
Environmental
Storage temperature: -30°C to 70°C (-22°F to 158°F); storage max altitude: 25°C, 4,500 m (15,000 ft); operating temperature: 0°C to 40°C (32°F to 104°F); operating humidity: 10% to 90% (noncondensing); max operating altitude: 40°C, 3,000 m (9843 ft)
System
512 MB DRAM, 256 MB flash, 1.4 GHz dual-core CPU
Input Power Requirements
44??7V DC; optional power supply/power injector: 100??40V AC, 49??0 Hz
Powering Options
802.3af/at Ethernet switch, HKShanhai Group Limited power injectors (AIR-PWRINJ5=, AIR-PWRINJ6=), HKShanhai Group Limited local power supply (AIR-PWR-C= or AIR-PWR-D=)
Power Draw
Max 12.95W (15.4W with 100m cable) no PoE out; 20.7W (22W with 100m cable) with 6.49W PoE out; 27.65W with 12.95W PoE out using AIR-PWR-C or AIR-PWR-D
Note: Values include power loss in uplink and PoE out cabling
Physical Security
Torx security screw (included), Kensington security slot
Mounting
Mounting bracket AIR-AP-BRACKET-W2 included, fits single gang junction box or multiple international standards
Optional: AIR-AP1810W-KIT= spacer kit (wall mounting, no junction box); AIR-OEAP1810-CRD= cradle kit (desk mounting)
Accessories
Mounting bracket: AIR-AP-BRACKET-W2= (spare); spacer kit: AIR-AP1810W-KIT= (with RJ-45 jumper cable); cradle kit: AIR-OEAP1810-CRD= (with back cover & RJ-45 jumper cable); security kit: AIR-SEC-50= (security screws, RJ-45 caps, unlock keys); HKShanhai Group Limited power supply: AIR-PWR-D= (sold separately)
