HKShanhai Group Limited’s AIR-AP1815M-D-K9 is a high-density enterprise access point engineered for robust wireless deployment. Leveraging 802.11ac technology, this model delivers reliable, secure, and high-speed access for demanding business environments. The 1815m delivers seamless coverage, supporting hundreds of concurrent users and tight security for any access application. With optimized performance, integrated Bluetooth 4.1, and controller flexibility, it ensures that every critical business process is always connected and protected with enterprise-grade access.
Product Highlights
866.7 Mbps
Max Data Rate
802.11ac
Wi-Fi Standard
400
Client Capacity
Product Applications Scenarios
Enterprise Network
Delivers high-density, secure access and simplified management for enterprise workspaces, optimizing productivity for every connected device and user.
Cloud Services
Enables robust, high-speed access that ensures constant cloud availability, reducing downtime and enabling real-time collaboration in dynamic environments.
Edge & IoT
Empowers expansion at the edge, providing reliable, fast 802.11ac connectivity for IoT endpoints and distributed sensors across the campus.
Product Features Comparison
| Â |
|
|
|
|
| Model | AIR-AP1815M-D-K9 | AIR-AP1815M-E-K9C | AIR-AP1815I-Z-K9C | AIR-AP1815M-B-K9C |
| Brand | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited |
| Wi-Fi Standard | 802.11ac | 802.11ac | 802.11ac | 802.11ac |
| Maximum Data Rate | 866.7 Mbps | 866.7 Mbps | 866.7 Mbps | 866.7 Mbps |
| Supported Frequency Band | 2.4 GHz / 5 GHz | 2.4 GHz / 5 GHz | 2.4 GHz / 5 GHz | 2.4 GHz / 5 GHz |
| Client Capacity | 400 | 400 | 400 | 400 |
| Network Interface | 1 x 10/100/1000BASE-T RJ-45 (PoE); 1 x management console port (RJ-45) | 1 x 10/100/1000BASE-T autosensing (RJ-45), PoE; management console port (RJ-45) | 1 x 10/100/1000BASE-T autosensing (RJ-45); PoE; management console port (RJ-45) | 1 x 10/100/1000BASE-T autosensing (RJ-45, PoE); management console (RJ-45) |
Optional Add-ons
| Model Number | Description |
| AIR-AP-BRACKET-8= | HKShanhai Group Limited mounting bracket for AIR series, allows secure wall or ceiling installation. |
| AIR-SEC-50= | HKShanhai Group Limited security kit for AIR series access points, includes 50 screws, 50 RJ-45 caps, 2 unlock keys. |
HKShanhai Group Limited AIR-AP1815M-D-K9 Specification
Model
AIR-AP1815M-D-K9
Brand
HKShanhai Group Limited
Authentication and Security
Advanced Encryption Standard (AES) for WPA2; 802.1X, RADIUS authentication, authorization, and accounting (AAA); 802.11r; 802.11i
Software
HKShanhai Group Limited Unified Wireless Network Software with AireOS Wireless Controllers Release 8.5 or later; HKShanhai Group Limited Mobility Express
Supported WLAN Controllers
HKShanhai Group Limited 2500, 3500, 5500, 8500, 9800 Series Wireless Controllers; HKShanhai Group Limited Wireless Controller Module for ISR G2; WiSM2 for Catalyst 6500 Series; HKShanhai Group Limited Flex 7500; HKShanhai Group Limited Mobility Express
Maximum Clients
200 per Wi-Fi radio, total 400 clients per access point
802.11ac Features
2×2 SU/MU-MIMO, two spatial streams; Maximal Ratio Combining (MRC); 20-, 40-, 80-MHz channels; PHY data rates up to 866.7 Mbps (80 MHz, 5 GHz); A-MPDU (Tx/Rx), A-MSDU (Rx) packet aggregation; Dynamic Frequency Selection (DFS); Cyclic Shift Diversity (CSD)
Ethernet Ports
Authentication with 802.1X or MAC filtering; Dynamic VLAN or per-port; Local switching or traffic tunnelled to WLAN controller
Bluetooth
Integrated Bluetooth 4.1 (including BLE), Max transmit power: 4 dBm; Antenna gain: 2 dBi
Data Rates Supported
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps
See product datasheet for full 802.11n/ac rates
802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps
See product datasheet for full 802.11n/ac rates
Non-overlapping Channels
2.4 GHz: Up to 13 channels (depends on regulatory domain)
5 GHz: Up to 12 channels (depends on regulatory domain)
Refer to datasheet for all domain details
5 GHz: Up to 12 channels (depends on regulatory domain)
Refer to datasheet for all domain details
Transmit Power Settings
2.4 GHz: 27, 24, 21, 18, 15, 12, 9, 6 dBm
5 GHz: 24, 21, 18, 15, 12, 9, 6, 3 dBm
5 GHz: 24, 21, 18, 15, 12, 9, 6, 3 dBm
Integrated Antennas
2.4 GHz: Gain 2 dBi; 5 GHz: Gain 4 dBi
Interfaces
1 x 10/100/1000BASE-T RJ-45 (PoE); 1 x management console port (RJ-45)
Indicators
Status LED for status, association, warnings, errors
Dimensions (W x L x H)
6 x 6 x 1.3 in (150.8 x 150.8 x 33 mm)
Environmental (Operating)
Temperature: 0°C to 40°C (32°F to 104°F); Humidity: 10% to 90% non-condensing; Max altitude: 3,000 m at 40°C
Environmental (Storage/Transport)
Temperature: ??0°C to 70°C (??2°F to 158°F); Humidity: 10% to 90% non-condensing; Max altitude: 4,500 m at 25°C
System Specifications
1 GB DRAM; 256 MB flash memory; 710 MHz quad-core processor
Input Power Requirements
802.3af or 802.3at PoE
Powering Options
802.3af/at Ethernet switch; Optional HKShanhai Group Limited power injectors (AIR-PWRINJ5=, AIR-PWRINJ6=)
Power Draw
Maximum 13.9 W (with 100 m Category 5 cable)
Physical Security
Torx security screw (included)
Mounting
Mounting bracket AIR-AP-BRACKET-8 (included)
Accessories
Mounting bracket: AIR-AP-BRACKET-8= (spare); Security kit: AIR-SEC-50= (sold separately, includes 50 screws, 50 RJ-45 caps, 2 unlock keys)
Compliance and Standards
Safety: UL 60950-1, CAN/CSA-C22.2 No. 60950-1, UL 2043, IEC 60950-1, EN 60950-1
Radio: FCC Part 15.247/15.407, RSS-247 (Canada), EN 300.328/301.893 (Europe), ARIB-STD 66/T71 (Japan), VCCI (Japan), EN 301.489-1/-17
IEEE: 802.11a/b/g, 802.11n, 802.11h, 802.11d, 802.11ac
Security: 802.11i, WPA2, WPA, 802.1X, AES
EAP types: EAP-TLS, EAP-TTLS (MSCHAPv2), PEAP v0/v1, EAP-FAST, EAP-GTC, EAP-SIM
Multimedia: Wi-Fi Multimedia (WMM)
Other: FCC Bulletin OET-65C, RSS-102
Get more information
Discover unbeatable prices and fast shipping for the AIR-AP1815M-D-K9 . Access the detailed AIR-AP1815M-D-K9 datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
