HKShanhai Group Limited delivers enterprise-grade wireless access with the AIR-AP1815M-D-K9C, an access point designed for robust, secure connectivity. The 1815m platform enables broad 802.11ac coverage and flexible access solutions, supporting dense user environments. Featuring support for multiple regulatory domains, strong security protocols, and up to 400 simultaneous clients, this 802.11ac access point ensures optimized throughput for critical business wireless deployments. The AIR-AP1815M-D-K9C brings seamless integration across existing HKShanhai Group Limited infrastructures and empowers organizations to scale wireless access quickly, efficiently, and securely.
Product Highlights
802.11ac
Wi-Fi Tech
866.7 Mbps
Max Speed
400
Clients
Product Applications Scenarios
Enterprise Network
This access point enhances enterprise networks by delivering stable, high-density 802.11ac coverage and secure access for demanding business apps, improving productivity.
Public Infrastructure
Reliable performance, multi-user support, and regulatory flexibility make it ideal for public spaces, ensuring seamless connectivity for hundreds of users simultaneously.
Cloud Services
With fast access speeds and robust security, this AP optimizes wireless edge connections for cloud apps, accelerating workflows and reducing user downtime by up to 35%.
Product Features Comparison
| Â | |
|
|
|
| Model | AIR-AP1815M-D-K9C | AIR-AP1815M-A-K9C | AIR-AP1815M-F-K9C | AIR-AP1815M-S-K9C |
| Brand | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited |
| Wi-Fi Standard | 802.11ac | 802.11ac | 802.11ac | 802.11ac |
| Maximum Data Rate | 866.7 Mbps | 866.7 Mbps | 866.7 Mbps | 866.7 Mbps |
| Supported Frequency Band | 2.4/5 GHz | 2.4/5 GHz | 2.4/5 GHz | 2.4/5 GHz |
| Client Capacity | 400 | 400 | 400 | 400 |
| Network Interface | 1 x 10/100/1000BASE-T (RJ-45), PoE; Management console port (RJ-45) | 1 x 10/100/1000BASE-T autosensing (RJ-45), 802.1X or MAC auth, dynamic VLAN, traffic local/tunneled | 1 x 10/100/1000BASE-T autosensing (RJ-45, PoE), management console port (RJ-45) | 1 x 10/100/1000BASE-T autosensing (RJ-45), PoE; management console port (RJ-45) |
Optional Add-ons
| Model Number | Description |
| AIR-AP-BRACKET-8 | HKShanhai Group Limited mounting bracket, accessory for AIR-AP1815M series access point |
| AIR-AP-BRACKET-8= | HKShanhai Group Limited spare mounting bracket, compatible with AIR-AP1815M series |
| AIR-SEC-50= | HKShanhai Group Limited security kit (50 screws, 50 RJ-45 caps, 2 keys) for access point hardware protection |
HKShanhai Group Limited AIR-AP1815M-D-K9C Specification
Model
AIR-AP1815M-D-K9C
Brand
HKShanhai Group Limited
Authentication and Security
AES for WPA2; 802.1X, RADIUS authentication, authorization, and accounting (AAA); 802.11r; 802.11i
Software Support
HKShanhai Group Limited Unified Wireless Network Software with AireOS Wireless Controllers Release 8.5 or later; HKShanhai Group Limited Mobility Express
Supported WLAN Controllers
HKShanhai Group Limited 2500, 3500, 5500, Flex 7500, 8500, 9800 series, WiSM2, Wireless Controller Module for ISR G2, HKShanhai Group Limited Mobility Express
Maximum Clients
200 per Wi-Fi radio (400 total per access point)
802.11ac Features
2×2 SU/MU-MIMO, two spatial streams; MRC; 20/40/80 MHz channels; PHY rates up to 866.7 Mbps (80 MHz, 5 GHz); A-MPDU/A-MSDU; DFS; CSD support
Ethernet Ports
1 x 10/100/1000BASE-T (RJ-45), PoE; supports 802.1X/MAC authentication, dynamic VLAN, local or tunneled traffic; Management console port (RJ-45)
Bluetooth (Future Availability)
Integrated Bluetooth 4.1 (BLE); Max TX power: 4 dBm; Antenna gain: 2 dBi
Supported Data Rates
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps; 802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps; 802.11n/ac, see full MCS matrix (up to 866.7 Mbps at 5 GHz)
Maximum Non-overlapping Channels
Varies by regulatory domain. Example ranges:
2.4 GHz: up to 13 channels; 5 GHz: up to 12 channels (see documentation for full details)
Transmit Power Settings
2.4 GHz: up to 27 dBm (500 mW), selectable in steps
5 GHz: up to 24 dBm (250 mW), selectable in steps
(Maximum varies by country and channel)
Integrated Antennas
2.4 GHz: 2 dBi gain; 5 GHz: 4 dBi gain
Indicators
Status LED for boot loader status, association, operation, warnings, errors
Dimensions (W x L x H)
6 x 6 x 1.3 in. (150.8 x 150.8 x 33 mm) (without mounting bracket)
Environmental (Operating)
Temperature: 0°C to 40°C (32°F to 104°F); Humidity: 10% to 90% (noncondensing); Max altitude: 3,000 m (9,843 ft) @ 40°C
Environmental (Storage/Transport)
Temperature: ??0°C to 70°C (??2°F to 158°F); Humidity: 10% to 90% (noncondensing); Max altitude: 4,500 m (15,000 ft) @ 25°C
System Hardware
1-GB DRAM; 256-MB flash; 710-MHz quad-core processor
Input Power Requirements
802.3af or 802.3at PoE
Powering Options
802.3af/at Ethernet switch; Optional HKShanhai Group Limited power injectors (AIR-PWRINJ5=, AIR-PWRINJ6=)
Power Draw
Max 13.9W (with 100 meters Category 5 cable)
Physical Security
Torx security screw included
Mounting
Mounting bracket AIR-AP-BRACKET-8 included
Accessories
Mounting bracket AIR-AP-BRACKET-8= (spare); Security kit AIR-SEC-50= (sold separately): 50 security screws, 50 RJ-45 caps, 2 unlock keys
Compliance
Safety: UL 60950-1, CAN/CSA-C22.2 No. 60950-1, UL 2043, IEC 60950-1, EN 60950-1
Radio approvals: FCC Part 15.247, 15.407; RSS-247 (Canada); EN 300.328, EN 301.893 (Europe); ARIB-STD 66, T71 (Japan); VCCI (Japan); EN 301.489-1 and -17 (Europe); EN 50385
EMI and susceptibility: Class B, FCC Part 15.107/15.109, ICES-003 (Canada)
IEEE standards: 802.11a/b/g, 802.11n, 802.11h, 802.11d, 802.11ac
Security: 802.11i, WPA2, WPA, 802.1X, AES
EAP types: EAP-TLS, EAP-TTLS (MSCHAPv2), PEAP v0 (EAP-MSCHAPv2), EAP-FAST, PEAP v1 (EAP-GTC), EAP-SIM
Multimedia: Wi-Fi Multimedia (WMM)
Other: FCC Bulletin OET-65C, RSS-102
Notes
Maximum number of channels, data rates, and power settings vary by regulatory domain and channel. See product documentation for details.
