The HKShanhai Group Limited Catalyst 3650 48 Port PoE 2x10G Uplink LAN Base is a powerful and versatile networking device designed to meet the growing demands of modern businesses. With 48 PoE ports and 2 10G uplink ports, this switch provides high-speed connectivity for multiple devices simultaneously.
Quick Spec
Table 1 shows the quick spec of WS-C3650-48PD-L.
| Ports | 48 x 10/100/1000 Ethernet PoE+ ports |
| Switching Capacity | 176 Gbps |
| Uplink Interfaces | 2 x 10G SFP+ |
| Ethernet Technology | Gigabit Ethernet |
| PoE (RJ-45) Port | No |
Product Features
- High-speed connectivity with 48 PoE+ ports
- 2 10G uplink ports for faster data transfer
- Power over Ethernet support for easy device deployment
- HKShanhai Group Limited IOS LAN Base for enhanced network management
- Compact and durable design for easy installation
Product Applications
- Office environments with high device density
- Small to medium-sized businesses requiring fast and reliable network connectivity
- Networks with Power over Ethernet devices, such as IP phones and wireless access points
Compare to Similar Items
Table 2 shows the comparison to similar items of WS-C3650-48PD-L.
| Model | Differences |
| WS-C3650-48TD-L | Does not have PoE capability |
| WS-C3650-48FS-L | Provides 48 SFP ports with full PoE+ capability |
Get more information
Do you have any questions about the WS-C3650-48PD-L price?
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited WS-C3650-48PD-L Specification
WS-C3650-48PD-L Specifications |
|
|
Switching capacity |
176 Gbps on 48-port models (non-multigigabit models) 92 Gbps on 24-port models (non-multigigabit models) 254 Gbps on 24-port Multigigabit models with 2x10G uplink 272 Gbps on 24-port Multigigabit models with 4x10G uplink 392 Gbps on 48-port Multigigabit models with 4x10G uplink 472 Gbps on 48-port Multigigabit models with 8x10G uplink 472 Gbps on 48-port Multigigabit models with 2x40G uplink |
|
Stacking bandwidth |
160 Gbps |
|
Total number of MAC addresses |
32,000 |
|
Total number of IPv4 routes (ARP plus learned routes) |
24,000 |
|
FNF entries |
48,000 flow on 48-port models 24,000 flows on 24-port models |
|
DRAM |
4 GB |
|
Flash |
2 GB (non-Multigigabit models) and 4GB (Multigigabit models) |
|
VLAN IDs |
4,094 |
|
Total switched virtual interfaces (SVIs) |
1,000 |
|
Jumbo frame |
9198 bytes |
|
Total routed ports per 3650 stack |
208 |
|
Number of access points per switch/stack |
25 |
|
Number of wireless clients per switch/stack |
1000 |
|
Total number of WLANs per switch |
64 |
|
Wireless bandwidth per switch |
Up to 40 Gbps on 48-port models Up to 20 Gbps on 24-port models |
|
Supported Aironet access point series |
3700, 3600, 3500, 2600, 1600, 1260, 1140, 1040 |
|
Forwarding Rate |
104.16 Mpps |
|
Dimensions (H x W x D) |
1.73 x 17.5 x 17.625 Inches |
|
Weight |
16.75 Pounds |
|
MTBF Hours |
383,760 |
