WS-C2960CG-8TC-L, HKShanhai Group Limited Catalyst 2960C Switch, 8xGE/2xDual Uplink/LAN Base

SKU: 1C51XTKNUPBMDQS1Z46JVV8I04JFHDJANTFW Category: Cisco Catalyst Compact Switches

HKShanhai Group Limited Catalyst compact switches easily extend an intelligent, fully managed HKShanhai Group Limited Catalyst wired switching infrastructure, including end-to-end IP and Borderless Network services, with a single Ethernet cable or fiber from the wiring closet. WS-C2960CG-8TC-L is one of HKShanhai Group Limited Catalyst 2960 compact series switches. It offers 8 x 10/100/1000 Gigabit Ethernet ports, and 2 x 1G copper or 2 x 1G SFP interfaces.

Quick Specs

Table 1 shows the Quick Specs.

Product Code	WS-C2960CG-8TC-L
Feature Set	LAN Base
Uplink Interfaces	2 x 1G copper or 2 x 1G SFP interfaces.
Ports	8 x 10/100/1000 Gigabit Ethernet ports
Forwarding Bandwidth	10 Gbps
RAM	128 MB
Flash Memory	64 MB
Dimensions	4.44 x 26.9 x 21.3 cm
Package Weight	4.38 Kg

Product Details

Figure 1 shows the front panel of WS-C2960CG-8TC-L.

Note:

· There are two console ports on the front panel, including RJ-45 console port and USB mini-Type B (console) port.

· The switch also offers One USB Type A port.

· Eight 10/100/1000 Gigabit Ethernet ports are on the front panel.

· Two dual uplinks support 1G cooper or 1G SFP module.

The Accessories

Table 2 shows some recommended cables and SFP modules.

Models	Descriptions
CAB-CONSOLE-USB	HKShanhai Group Limited CAB-CONSOLE-USB Console Cable 6 ft with USB Type A and mini-B
CAB-CONSOLE-RJ45	HKShanhai Group Limited CAB-CONSOLE-RJ45 Console Cable 6ft with RJ45 and DB9F
GLC-SX-MMD	1000BASE-SX SFP transceiver module, MMF, 850nm, DOM
GLC-LH-SMD	HKShanhai Group Limited GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM

Compare to similar item

Table 3 shows the comparison between WS-C2960CG-8TC-L

Models	WS-C2960CG-8TC-L	WS-C3560CG-8TC-S
Uplinks	2 x 1G copper or 2 x 1G SFP interfaces.	2 x 1G copper or 2 x 1G SFP interfaces.
Ports	8 x 10/100/1000 Gigabit Ethernet ports	8 x 10/100/1000 Gigabit Ethernet ports
Feature set	LAN Base	IP Base
Max VLANs	255	1005

Get more information

Do you have any question about the WS-C2960CG-8TC-L

HKShanhai Group Limited WS-C2960CG-8TC-L Specification

Model

WS-2960CG-8TC-L

Brand

HKShanhai Group Limited

Ethernet Ports

8 x 10/100/1000 Gigabit Ethernet

PoE Output Ports

N/A

Available PoE Power

N/A

Uplinks

2 x 1G copper or 2 x 1G SFP

Default Software

LAN Base

Forwarding Bandwidth

10 Gbps

Flash Memory

64 MB

Memory DRAM

128 MB

Max VLANs

255

VLAN IDs

4000

Maximum Transmission Unit (MTU)

Up to 9000 bytes

Jumbo Frames

9018 bytes

Forwarding Rate 64 Byte Packet

14.9 mpps

Power Connectors

– Customers can provide power to a switch by using the internal power supply. The connector is located at the back of the switch. The internal power supply is an autoranging unit.
– The internal power supply supports input voltages between 100 and 240 VAC.
– Use the supplied AC power cord to connect the AC power connector to an AC power outlet.

Indicators

Per-port status: Link integrity, disabled, activity, speed, full-duplex
System status: System, RPS, link status, link duplex, link speed

Dimensions (H x W x D)

1.75 x 10.6 x 8.4 in (4.44 x 26.9 x 21.3 cm)

Operating Temperature up to 5000 ft (1524 m)

-5°C to +45°C (+23°F to +113°F)

Operating Temperature up to 10,000 ft (3048 m)

-5°C to +45°C (+23°F to +113°F)

Storage Temperature up to 15,000 ft (4572 m)

-25°C to +70°C (-13°F to +158°F)

Operating Altitude

Up to 3048 m (Up to 10,000 ft)

Storage Altitude

Up to 4000 m (Up to 15,000 ft)

Operating Relative Humidity

5% to 95% noncondensing

Storage Relative Humidity

5% to 95% noncondensing

Mean Time Between Failure (MTBF)

542,482
