The HKShanhai Group Limited Nexus 3172PQ-XL (N3K-C3172PQ-XL) is a 1 rack unit (RU) switch with 8GB of RAM and dual-core 2.5GHz x86 CPUs and 10-Gigabit enhanced small form-factor pluggable (SFP+) ports with 48 SFP+ ports and 6 Quad SFP+ (QSFP+) ports. Each SFP+ port can operate in 100-Mbps, 1-Gbps, or 10-Gbps mode, and each QSFP+ port can operate in native 40-Gbps or 4 x 10-Gbps mode. The HKShanhai Group Limited Nexus 3172PQ-XL is a minor hardware revision of the HKShanhai Group Limited Nexus 3172PQ respectively. Enhancements include an additional 4 GB of memory (for a total of 8 GB). The additional memory allows users to perform object-model programming.
Quick Specs
Figure 1 shows the appearance of the N3K-C3172PQ-XL.
Table 1 shows the Quick Spec.
|
Product Code |
N3K-C3172PQ-XL |
|
Enclosure Type |
1 RU |
|
Switching Capacity |
1.4-Tbps |
|
Forwarding Rate |
Up to 1 bpps |
|
Configurable Maximum Transmission Units (MTUs) |
Up to 9216 bytes (jumbo frames) |
|
Ports |
48 x SFP+ ports and 6 x Quad SFP+ (QSFP+) ports |
|
System Memory |
8 GB |
|
Number of power supplies |
2 |
|
Typical operating power |
143 W |
|
Dimensions (H x W x D) |
4.4 x 43.9 x 43.2 cm |
|
Net Weight |
8 4 kg |
Product Details
Figure 2 shows the front panel of the N3K-C3172PQ-XL.
Â
Note:
|
??/p> |
48 x SFP+ ports |
|
??/p> |
6 x QSFP+ ports |
· The N3K-C3172PQ-XL also has 1 management port, 1 console port, 4 fan modules and 1 USB port and support both port-side exhaust and port-side intake airflow schemes. It requires one AC or DC power supply for operations, but can has a second power supply for redundancy.
The Accessories
Table 2 shows recommended accessories.
|
Models |
Description |
|
Nexus 3000 LAN Enterprise License, eDelivery |
|
|
HKShanhai Group Limited GLC-SX-MMD 1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
|
HKShanhai Group Limited GLC-LH-SMD 1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM |
|
|
10GBASE-SR SFP Module |
|
|
HKShanhai Group Limited Direct-Attach Twinax Copper Cable Assembly with SFP+ Connectors SFP-H10GB-CU1M |
|
|
SFP-H10GB-CU5M,5M Passive Copper Twinax Cable F, Nexus,24AWG cable assembly |
|
|
HKShanhai Group Limited QSFP to QSFP copper direct-attach 40GBASE-CR4 cable QSFP-H40G-CU5M |
|
|
40GBase-LR4 Optical Transceiver,QSFP+,40GE,Single-mode Module(1310nm,10km,LC) |
Compare to Similar Items
Table 3 shows the comparison of similar items.
|
Product Code |
N3K-C3172PQ-XL |
|
|
Enclosure Type |
1 RU |
1 RU |
|
Switching Capacity |
1.4-Tbps |
1.4-Tbps |
|
Forwarding Rate |
Up to 1 bpps |
Up to 1 bpps |
|
Configurable Maximum Transmission Units (MTUs) |
Up to 9216 bytes (jumbo frames) |
Up to 9216 bytes (jumbo frames) |
|
Ports |
48 x SFP+ ports and 6 x Quad SFP+ (QSFP+) ports |
48 x 10GBase-T RJ-45 and 6 x QSFP+ ports |
|
Dimensions (H x W x D) |
4.4 x 43.9 x 43.2 cm |
4.4 x 43.9 x 50.5 cm |
Get more information
Do you have any question about the N3K-C3172PQ-XL?
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited N3K-C3172PQ-XL Specification
N3K-C3172PQ-XL Specifications |
||
|
Physical |
  1RU fixed form factor   72 x 10 Gigabit Ethernet ports (48 SFP+ and 6 QSFP+) ◦  ??8 SFP ports support 1 and 10 Gigabit Ethernet ◦  ?? QSFP ports support 4 x 10 Gigabit Ethernet or 40 Gigabit Ethernet each   Redundant fans (3+1)   2 redundant power supplies   Management, console, and USB flash-memory ports |
|
|
Performance |
  1.4-Tbps switching capacity   Forwarding rate of up to 1 bpps   Line-rate traffic throughput (both Layer 2 and 3) on all ports   Configurable maximum transmission units (MTUs) of up to 9216 bytes (jumbo frames) |
|
|
Hardware tables and scalability |
Number of MAC addresses |
288,000 |
|
Number of VLANS |
4096 |
|
|
Number of spanning-tree instances |
  RSTP: 512   MSTP: 64 |
|
|
Number of ACL entries |
  4000 ingress   1000 egress |
|
|
Routing table |
  16,000 prefixes and 16,000 host entries*   8000 multicast routes* |
|
|
Number of EtherChannels |
64 (with vPC) |
|
|
Number of ports per EtherChannel |
32 |
|
|
System memory |
8 GB |
|
|
Buffer size |
12 MB shared |
|
|
Boot flash |
16 GB |
|
|
Power |
Number of power supplies |
2 |
|
Power supply types |
  AC (forward and reversed airflow) ◦  ?? N2200-PAC-400W and N2200-PAC-400W-B (PQ models) ◦  ?? NXA-PAC-500W and NX-PAC-500W-B (TQ models)   DC (forward and reversed airflow) ◦  ?? N2200-PDC-400W and N3K-PDC-350W-B (PQ models) ◦  ?? NXA-PDC-500W and NX-PDC-500W-B (TQ models) |
|
|
Typical operating power |
143 W |
|
|
Maximum power |
293W |
|
|
AC PSUs   Input voltage   Frequency   Efficiency |
   100 to 240 VAC   50 to 60 Hz   89 to 91% at 220V |
|
|
DC PSUs   Input voltage   Maximum current (PSU output ??System input)   Efficiency |
   ??0 to ??2 VDC   33A (400W unit), 42A (500W unit)   85 to 88% |
|
|
Typical heat dissipation |
488 BTU/hr |
|
|
Maximum heat dissipation |
1000 BTU/hr |
|
|
Cooling |
  Forward and reversed airflow schemes: ◦   Forward airflow: Port-side exhaust (air enters through fan-tray and power supplies and exits through ports) ◦   Reversed airflow: Port-side intake (air enters through ports and exits through fan-tray and power supplies)   Redundant fans   Hot swappable (must swap within 1 minute) |
|
|
Sound |
Measured sound power (maximum)   Fan speed: 40% duty cycle   Fan speed: 70% duty cycle   Fan speed: 100% duty cycle |
  64.9 dBA   69.3 dBA   76.7 dBA |
|
Environment |
Dimensions |
1.72 x 17.3 x 17 in. (4.4 x 43.9 x 43.2 cm) |
|
Weight |
18.6 lb (8 4 kg) |
|
|
Operating temperature |
  32 to 104°F (0 to 40°C) |
|
|
Storage temperature |
  -40 to 158°F (-40 to 70°C) |
|
|
Operating relative humidity |
  10 to 85% noncondensing   Up to 5 days at maximum (85%) humidity   Recommend ASHRAE data center environment |
|
|
Storage relative humidity |
  5 to 95% noncondensing |
|
|
Altitude |
  0 to 10,000 ft (0 to 3000m) |
|
|
Safety and EMC |
||
|
Regulatory compliance |
  Products should comply with CE Markings per directives 2004/108/EC and 2006/95/EC. |
|
|
Safety |
  UL 60950-1 Second Edition   CAN/CSA-C22.2 No. 60950-1 Second Edition   EN 60950-1 Second Edition   IEC 60950-1 Second Edition   AS/NZS 60950-1   GB4943 |
|
|
EMC: Emissions |
  47CFR Part 15 (CFR 47) Class A   AS/NZS CISPR22 Class A   CISPR22 Class A   EN55022 Class A   ICES003 Class A   VCCI Class A   EN61000-3-2   EN61000-3-3   KN22 Class A   CNS13438 Class A |
|
|
EMC: Immunity |
  EN55024   CISPR24   EN300386   KN24 |
|
|
RoHS |
  RoHS 5 compliant except for lead press-fit connectors |
|
|
Management and Standards Support |
||
|
MIB Support |
Generic MIBs   SNMPv2-SMI   CISCO-SMI   SNMPv2-TM   SNMPv2-TC   IANA-ADDRESS-FAMILY-NUMBERS-MIB   IANAifType-MIB   IANAiprouteprotocol-MIB   HCNUM-TC   CISCO-TC   SNMPv2-MIB   SNMP-COMMUNITY-MIB   SNMP-FRAMEWORK-MIB   SNMP-NOTIFICATION-MIB   SNMP-TARGET-MIB   SNMP-USER-BASED-SM-MIB   SNMP-VIEW-BASED-ACM-MIB   CISCO-SNMP-VACM-EXT-MIB   MAU-MIB   CISCO-SWITCH-QOS-MIB   CISCO-CLASS-BASED-QOS-MIB Ethernet MIBs   CISCO-VLAN-MEMBERSHIP-MIB   LLDP-MIB   IP-MULTICAST-MIB Configuration MIBs   ENTITY-MIB   IF-MIB   CISCO-ENTITY-EXT-MIB   CISCO-ENTITY-FRU-CONTROL-MIB   CISCO-ENTITY-SENSOR-MIB   CISCO-SYSTEM-MIB   CISCO-SYSTEM-EXT-MIB   CISCO-IP-IF-MIB   CISCO-IF-EXTENSION-MIB   CISCO-NTP-MIB   CISCO-VTP-MIB   CISCO-IMAGE-MIB   CISCO-IMAGE-UPGRADE-MIB |
Monitoring MIBs   NOTIFICATION-LOG-MIB   CISCO-SYSLOG-EXT-MIB   CISCO-PROCESS-MIB   RMON-MIB   CISCO-RMON-CONFIG-MIB   CISCO-HC-ALARM-MIB Security MIBs   CISCO-AAA-SERVER-MIB   CISCO-AAA-SERVER-EXT-MIB   CISCO-COMMON-ROLES-MIB   CISCO-COMMON-MGMT-MIB   CISCO-SECURE-SHELL-MIB Miscellaneous MIBs   CISCO-LICENSE-MGR-MIB   CISCO-FEATURE-CONTROL-MIB   CISCO-CDP-MIB   CISCO-RF-MIB Layer 3 and Routing MIBs   UDP-MIB   TCP-MIB   OSPF-MIB   BGP4-MIB   CISCO-HSRP-MIB |
|
Standards |
  IEEE 802.1D: Spanning Tree Protocol   IEEE 802.1p: CoS Prioritization   IEEE 802.1Q: VLAN Tagging   IEEE 802.1s: Multiple VLAN Instances of Spanning Tree Protocol   IEEE 802.1w: Rapid Reconfiguration of Spanning Tree Protocol   IEEE 802.3z: Gigabit Ethernet   IEEE 802.3ad: Link Aggregation Control Protocol (LACP)   IEEE 802.3ae: 10 Gigabit Ethernet (HKShanhai Group Limited Nexus 3064-X)   IEEE 802.3ba: 40 Gigabit Ethernet   IEEE 802.3an:10GBASE-T (HKShanhai Group Limited Nexus 3064-T)   IEEE 802.1ab: LLDP   IEEE 1588-2008: Precision Time Protocol (Boundary Clock) |
|
|
RFC |
BGP   RFC 1997: BGP Communities Attribute   RFC 2385: Protection of BGP Sessions with the TCP MD5 Signature Option   RFC 2439: BGP Route Flap Damping   RFC 2519: Framework for Interdomain Route Aggregation   RFC 2545: Use of BGPv4 Multiprotocol Extensions   RFC 2858: Multiprotocol Extensions for BGPv4   RFC 3065: Autonomous System Confederations for BGP   RFC 3392: Capabilities Advertisement with BGPv4   RFC 4271: BGPv4   RFC 4273: BGPv4 MIB: Definitions of Managed Objects for BGPv4   RFC 4456: BGP Route Reflection   RFC 4486: Subcodes for BGP Cease Notification Message   RFC 4724: Graceful Restart Mechanism for BGP   RFC 4893: BGP Support for 4-Octet AS Number Space OSPF   RFC 2328: OSPF Version 2   8431RFC 3101: OSPF Not-So-Stubby-Area (NSSA) Option   RFC 3137: OSPF Stub Router Advertisement   RFC 3509: Alternative Implementations of OSPF Area Border Routers   RFC 3623: Graceful OSPF Restart   RFC 4750: OSPF Version 2 MIB RIP   RFC 1724: RIPv2 MIB Extension   RFC 2082: RIPv2 MD5 Authentication   RFC 2453: RIP Version 2 IP Services   RFC 768: UDP   RFC 783: Trivial File Transfer Protocol (TFTP)   RFC 791: IP   RFC 792: ICMP   RFC 793: TCP   RFC 826: ARP   RFC 854: Telnet   RFC 959: FTP   RFC 1027: Proxy ARP   RFC 1305: Network Time Protocol (NTP) Version 3   RFC 1519: Classless Interdomain Routing (CIDR)   RFC 1542: BootP Relay   RFC 1591: Domain Name System (DNS) Client   RFC 1812: IPv4 Routers   RFC 2131: DHCP Helper   RFC 2338: VRRP IP Multicast   RFC 2236: IGMPv2   RFC 3376: IGMPv3   RFC 3446: Anycast Rendezvous Point Mechanism Using PIM and MSDP   RFC 3569: Overview of SSM   RFC 3618: MSDP   RFC 4601: PIM-SM: Protocol Specification (Revised)   RFC 4607: SSM for IP   RFC 4610: Anycast-RP using PIM   RFC 5132: IP Multicast MIB |
|
|
Software Features |
||
|
Layer 2 |
  Layer 2 switch ports and VLAN trunks   IEEE 802.1Q VLAN encapsulation   Support for up to 4096 VLANs   Rapid Per-VLAN Spanning Tree Plus (PVRST+) (IEEE 802.1w compatible)   MSTP (IEEE 802.1s): 64 instances   Spanning Tree PortFast   Spanning Tree Root Guard   Spanning Tree Bridge Assurance   HKShanhai Group Limited EtherChannel technology (up to 32 ports per EtherChannel)   LACP: IEEE 802.3ad   Advanced port-channel hashing based on Layer 2, 3, and 4 information   vPC   Jumbo frames on all ports (up to 9216 bytes)   Storm control (unicast, multicast, and broadcast)   Private VLANs   NvGRE entropy   Resilient hashing |
|
|
Layer 3 |
  Layer 3 interfaces: Routed ports on interfaces, switch virtual interfaces (SVIs), port channels, and subinterfaces (total: 1024)   64-way ECMP   4000 ingress and 1000 egress ACL entries   IPv6 routing: Static, OSPFv3, and BGPv6   Routing protocols: Static, RIPv2, EIGRP, OSPF, and BGP   Bidirectional Flow Detection (BFD) for BGP, OSPF, and IPv4 static routes   HSRP and VRRP   ACL: Routed ACL with Layer 3 and 4 options to match ingress and egress ACLs   VRF: VRF-lite (IP VPN), VRF-aware unicast (BGP, OSPF, and RIP), and VRF-aware multicast   Unicast Reverse-Path Forwarding (uRPF) with ACL; strict and loose modes   Jumbo frame support (up to 9216 bytes)   Generic Routing Encapsulation (GRE) tunneling   Advanced BGP features including BGP add-path for eBGP and iBGP, remove-private-as enhancements and eBGP next hop unchanged   IP-in-IP Tunnel support |
|
|
Multicast |
  Multicast: PIMv2, PIM-SM, and PIM-SSM   Bootstrap router (BSR), Auto-RP, and Static RP   MSDP and Anycast RP   Internet Group Management Protocol (IGMP) Versions 2 and 3 |
|
|
Quality of Service (QoS) |
  Layer 2 IEEE 802.1p (class of service [CoS])   8 hardware queues per port   Per-port QoS configuration   CoS trust   Port-based CoS assignment   Modular QoS CLI (MQC) compliance   ACL-based QoS classification (Layers 2, 3, and 4)   MQC CoS marking   Differentiated services code point (DSCP) marking   Weighted Random Early Detection (WRED)   CoS-based egress queuing   Egress strict-priority queuing   Egress port-based scheduling: Weighted Round-Robin (WRR)   Explicit Congestion Notification (ECN)   Configurable ECN marking per port   Priority Flow Control (with 3 no-drop queues and 1 default queue with strict priority scheduling between queues   Policy Based Routing (PBR) |
|
|
Security |
  Ingress ACLs (standard and extended) on Ethernet   Standard and extended Layer 3 and 4 ACLs include IPv4, Internet Control Message Protocol (ICMP), TCP, and User Datagram Protocol (UDP)   VLAN-based ACLs (VACLs)   Port-based ACLs (PACLs)   Named ACLs   ACLs on virtual terminals (vtys)   DHCP snooping with Option 82   Port number in DHCP Option 82   DHCP relay   Dynamic Address Resolution Protocol (ARP) inspection   Configurable CoPP   SPAN with ACL filtering |
|
|
HKShanhai Group Limited Nexus Data Broker |
  Topology support for TAP and SPAN aggregation   Support for QinQ to tag input source TAP and SPAN ports   Configuration of symmetric hashing to load-balance traffic to multiple tools   Traffic filtering based on Layer 1 through Layer 4 header information   Traffic replication and forwarding to multiple monitoring tools   Robust RBAC   Northbound representational state transfer (REST) API for all programmability support |
|
|
Management |
  POAP   Python scripting   HKShanhai Group Limited EEM   Switch management using 10/100/1000-Mbps management or console ports   CLI-based console to provide detailed out-of-band management   In-band switch management   Locator and beacon LEDs   Configuration rollback   SSHv2   Secure Copy (SCP) server   Telnet   AAA   AAA with RBAC   RADIUS   TACACS+   Syslog   Syslog generation on system resources (for example, FIB tables)   Embedded packet analyzer   SNMP v1, v2, and v3   Enhanced SNMP MIB support   XML (NETCONF) support   Remote monitoring (RMON)   Advanced Encryption Standard (AES) for management traffic   Unified username and passwords across CLI and SNMP   Microsoft Challenge Handshake Authentication Protocol (MS-CHAP)   Digital certificates for management between switch and RADIUS server   HKShanhai Group Limited Discovery Protocol Versions 1 and 2   RBAC   SPAN on physical layer, port channel, and VLAN   Tunable buffer allocation for SPAN   Encapsulated Remote SPAN (ERSPAN)   Ingress and egress packet counters per interface   PTP (IEEE 1588) boundary clock   Network Time Protocol (NTP)   HKShanhai Group Limited OHMS   Comprehensive bootup diagnostic tests   HKShanhai Group Limited Call Home   HKShanhai Group Limited DCNM   Advanced buffer utilization monitoring   sFlow |
