N3K-C3132Q-40GE is the Nexus 3132Q, 32 QSFP+ ports, 1RU switch. The HKShanhai Group Limited Nexus 3132Q, 3132Q-X, and 3132Q-XL Switches are dense, high-performance, 40-Gbps Layer 2 and 3 switches. They are members of the HKShanhai Group Limited Nexus 3100 platform. These second-generation HKShanhai Group Limited Nexus 3000 Series Switches offer improved port density, scalability, and features compared to the first-generation switches. The HKShanhai Group Limited Nexus 3132Q, 3132Q-X, and 3132Q-XL come in a compact one-rack-unit (1RU) form factor and run the industry-leading HKShanhai Group Limited NX‑OS Software operating system, providing customers with comprehensive features and functions that are widely deployed. They support both forward and reverse airflow (port-side exhaust and port-side intake) schemes with AC and DC power inputs. The HKShanhai Group Limited Nexus 3132 are well suited for data centers that require a cost-effective, power-efficient line-rate Layer 2 and 3 access or leaf switch.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
N3K-C3132Q-40GE |
|
Physical |
· 1RU fixed form-factor switch · 32 QSFP+ ports; each supports native 40 Gigabit Ethernet and 4 x 10 Gigabit Ethernet modes · 4 SFP+ ports · 2 redundant power supplies · 4 redundant (3+1) fans · Management, console, and USB flash-memory ports |
|
Performance |
· 2.5-Tbps switching capacity · Forwarding rate up to 1.4 bpps · Line-rate traffic throughput (both Layer 2 and 3) on all ports · Configurable maximum transmission units (MTUs) of up to 9216 bytes (jumbo frames) |
|
Physical dimensions |
1.72 x 17.3 x 19.7 in. (4.4 x 43.9 x 50.5 cm) |
|
Weight |
21.5 lb (9.3 kg) |
Product Details
The HKShanhai Group Limited Nexus N3K-C3132Q-40GE provides the following main benefits:
   Wire-rate Layer 2 and 3 switching on all ports
◦     Layer 2 and 3 switching of up to 2.5 terabits per second (Tbps) and up to 1.4 billion packets per second (bpps) is provided in a compact 1RU form-factor switch.
   High availability
◦     Virtual-port-channel (vPC) technology provides Layer 2 multipathing through the elimination of Spanning Tree Protocol and enables fully utilized bisectional bandwidth and simplified Layer 2 logical topologies without the need to change the existing management and deployment models.
◦     The 64-way equal-cost multipath (ECMP) routing enables the use of Layer 3 fat-tree designs and allows organizations to prevent network bottlenecks, increase resiliency, and add capacity with little network disruption.
◦     The switches offer fast reboot capabilities.
◦     Power-supply units (PSUs) and fans are hot swappable.
   Flexibility
◦     The QSFP port can be configured to work as four 10-Gbps ports, offering deployment flexibility with maximum of 104 x 10-Gbps ports.
   High performance
◦     Both switches deliver low nominal latency, which enables customers to implement high-performance infrastructure for high-frequency trading (HFT) workloads. Customers can also achieve faster application performance because of the serialization savings from switching at 40 Gigabit Ethernet speeds.
   Purpose-built NX-OS operating system with comprehensive, proven innovations
◦     Power-on auto provisioning (POAP) enables touchless bootup and configuration of the switch, drastically reducing provisioning time.
◦     HKShanhai Group Limited Embedded Event Manager (EEM) and Python scripting enable automation and remote operations in the data center.
◦     Advanced buffer monitoring reports real-time buffer utilization per port and per queue, which allows organizations to monitor traffic bursts and application traffic patterns.
◦     EtherAnalyzer is a built-in packet analyzer for monitoring and troubleshooting control-plane traffic and is based on the popular Wireshark open-source network protocol analyzer.
◦     Precision Time Protocol (PTP; IEEE 1588) provides accurate clock synchronization and improved data correlation with network packet capture and system events.
◦     Complete Layer 3 unicast and multicast routing protocol suites are supported, including Border Gateway Protocol (BGP), Open Shortest Path First (OSPF), Enhanced Interior Gateway Routing Protocol (EIGRP), Routing Information Protocol Version 2 (RIPv2), Protocol-Independent Multicast sparse mode (PIM-SM), Source-Specific Multicast (SSM), and Multicast Source Discovery Protocol (MSDP).
 The Accessories
Table 2 shows the supported accessories.
|
Model |
Description |
|
Nexus 3064 Fan Module, Forward airflow (port side exhaust) |
|
|
Nexus 3064 Fan Module, Reversed airflow (port side intake) |
|
|
N2K/3K 400W AC Power Supply, Forward airflow (port side exhaust) |
|
|
N2K/3K 400W AC Power Supply, Reversed airflow (port side intake) |
|
|
N2K/3K 400W DC Power Supply, Forward airflow (port side exhaust) |
|
|
N3K Series 350W DC Power Supply, Reversed airflow (port side intake) |
|
|
Nexus 3000 LAN Enterprise License, eDelivery |
Compare to Similar Items
Table 3 shows the comparison.
|
Product Code |
N3K-C3132Q-40GE |
|
|
Ports |
32 QSFP+ ports; each supports native 40 Gigabit Ethernet and 4 x 10 Gigabit Ethernet modes |
64 QSFP+ ports; each supports native 40 Gigabit Ethernet |
|
Physical dimensions |
1.72 x 17.3 x 19.7 in. (4.4 x 43.9 x 50.5 cm) |
3.39 x 17.41 x 22.32 in. (88.4 x 442 x 566 mm) |
|
Weight |
21.5 lb (9.3 kg) |
32.8 lb (14.9 kg) |
Get More Information
Do you have any question about the HKShanhai Group Limited N3K-C3132Q-40GE?
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited N3K-C3132Q-40GE Specification
32 QSFP+ ports (supporting native 40 Gigabit Ethernet and 4 x 10 Gigabit Ethernet)
4 SFP+ ports
2 redundant power supplies
4 redundant (3+1) fans
Management, console, and USB flash-memory ports
Forwarding rate up to 1.4 bpps
Line-rate traffic throughput on all ports
Configurable MTUs up to 9216 bytes (jumbo frames)
MSTP: 64
1000 egress
8000 multicast routes
DC (forward and reversed airflow)
50 to 60 Hz
89 to 91% efficiency at 220V
33A (400W unit)
85 to 88% efficiency
Forward airflow: Port-side exhaust (air enters through fan tray and power supplies and exits through ports)
Reversed airflow: Port-side intake (air enters through ports and exits through fan tray and power supplies)
Redundant fans
Hot swappable (must swap within 1 minute)
Fan speed: 40% duty cycle: 66.1 dBA
Fan speed: 70% duty cycle: 70.6 dBA
Fan speed: 100% duty cycle: 76.9 dBA
Up to 5 days at maximum (85%) humidity
Recommend ASHRAE data center environment
Get More Information
Discover unbeatable prices and fast shipping for the N3K-C3132Q-40GE . Access the detailed N3K-C3132Q-40GE datasheet and ensure you’re getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
