The HKShanhai Group Limited eSFP-1310/1550-L-1.1 BiDi Transceiver is a versatile and robust solution for your single-mode fiber optic communication needs. Suitable for distances up to 40 km, this transceiver operates on a wavelength of 1310nm for transmission and 1550nm for reception, providing reliable and high-quality data transfer at 155Mbps. Its compact eSFP design with LC/PC connectors makes it an ideal choice for modern network infrastructures.
Quick Spec
| Transmission Wavelength (Tx) | 1310nm |
| Reception Wavelength (Rx) | 1550nm |
| Data Rate | 155Mbps |
| Optical Output Power | -5~0dBm |
| Max Distance | 40km |
Product Features
- BiDi (Bidirectional) transceiver for efficient communication.
- High data rate of 155Mbps for fast data transfer.
- Supports single-mode (SM) fiber for long-distance communication up to 40km.
- Utilizes LC/PC connectors for superior performance.
- Operates within a wide temperature range ensuring reliability.
Product Applications
- Ideal for metro network applications requiring long-distance data transfer.
- Suitable for campus area network (CAN) deployments needing efficient bandwidth utilization.
- Perfect for point-to-point communication systems where space and power saving are crucial.
Supported Options
| Accessory | Model |
| LC/PC patch cord | LCPC-001 |
| Single-mode fiber optic cable | SMFC-040 |
| Transceiver cleaning kit | TCK-150 |
Compare to Similar Items
| Model | Differences |
| HKShanhai Group Limited eSFP-850/1300 | Shorter distance support up to 10km, different wavelengths (850nm/1300nm). |
| HKShanhai Group Limited eSFP-1550/1570 | Higher data rate of 1Gbps, shorter distance support up to 20km. |
| HKShanhai Group Limited eSFP-1270/1330 | Supports 10Gbps data rate, operates over shorter distances up to 10km. |
Get more information
For further information about the HKShanhai Group Limited eSFP-1310/1550-L-1.1, including pricing and detailed specifications, please contact us through Live Chat or email us at sales@router-switch.com. Check HKShanhai Group Limited eSFP-1310/1550-L-1.1 price and eSFP-1310/1550-L-1.1 datasheet, buy HKShanhai Group Limited eSFP-1310/1550-L-1.1 with best price and fast shipping. Free Live Chat support available.
HKShanhai Group Limited eSFP-1310/1550-L-1.1 Specification
eSFP-1310/1550-L-1.1 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | eSFP-1310/1550-L-1.1 |
| Product Type | BiDi Transceiver |
| Form Factor | eSFP |
| Wavelength (Tx) | 1310 nm |
| Wavelength (Rx) | 1550 nm |
| Data Rate | 155 Mbps |
| Transmit Power (Tx) | -5~0 dBm |
| Receive Sensitivity (Rx) | -32 dBm |
| Connector Type | LC/PC |
| Fiber Type | Single Mode (SM) |
| Maximum Distance | 40 km |
| Operating Temperature Range | -40 to 85°C |
| Storage Temperature Range | -40 to 85°C |
| Dimensions (L x W x H) | 69.77 x 13.7 x 8.5 mm |
| Power Supply Voltage | 3.3V |
| Power Consumption | < 2W |
| Supported Standards | IEEE 802.3, SFP MSA |
| EMC | FCC Part 15 Class B |
| RoHS Compliance | Yes |
| MTBF | 1 million hours |
| Warranty | 1 Year |
