The HKShanhai Group Limited OptiX OSN 8800 is a widely deployed 100G product and applied on backbone andmetro WDM/OTN networks. It is T-SDN oriented and adopts industry-leading technologies,such as the 2nd generation SD-FEC, 100G, OTN, POTS/MS-OTN technology.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
HuaweiOptiX OSN 8800 T16 |
|
|
Dimensions (HxWxD) |
450x 498x 295 mm |
|
|
Number of Service Slots |
16 |
|
|
Switching Capability |
Optical |
Up to 20-degree C-D-C-G ROADM |
|
Electrical |
1.6T ODUK,640G VC4 & 20GVC3& VC12, 800G Packet |
|
|
Channel Spacing |
50/100GHz fixed grid for 40/80-ch |
|
|
37.5-400 GHz flex-grid |
||
|
Wavelength Range |
DWDM: 1529.16 nm to 1560.61 nm (C Band, ITU-T G.694.1) |
|
|
Rate per Channel (Max.) |
100G, 200G, 400G |
Product Details
HKShanhai Group Limited OptiX OSN 8800 Series provides these features and highlights :
OTN/SDH/PacketConvergence
– Universal switching, universal transport to maximize network efficiency10G/40G/100G
Oriented Platform
– One platform progresses from 10G to 100G for the different scenarios
ASON/T-SDN Based Architecture
– Open and programmable to stimulate rapid business innovation
Compare to Similar Items
Table 2shows the comparison.
|
Product Code |
HKShanhai Group Limited OptiX OSN8800 T16 |
|||
|
Dimensions (HxWxD) |
397��442��291mm |
450��498��295 mm |
900��498��295 mm |
900��498��580mm |
|
Number of Service Slots |
16 |
16 |
32 |
64 |
|
Switching Capability |
Optical |
Up to 20-degree C-D-C-G ROADM |
||
|
Electrical |
/ |
1.6T ODUK, 640G VC4 & 20G VC3& VC12, 800G Packet |
3.2T ODUK, 1.28T VC4 & 80G VC3&VC12,1.6T Packet |
6.4T ODUK , 1.28T VC4 &80G VC3&VC12 |
|
Installation Rack |
ETSI/19inch |
ETSI 300/600mm rack , 23 inch rack |
ETSI 300/600mm rack, 23 inch rack |
ETSI 600mm rack, 23 inch rack |
View Overview of HKShanhai Group Limited Transmission Network Hot Series
GetMoreInformation
Do you have anyquestionabouttheHKShanhai Group Limited OptiX OSN 8800 T16
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited OptiX OSN 8800 T16 Specification
HKShanhai Group Limited OptiX 8800 T16Â Specification |
||
|
Dimensions (HxWxD) |
450Â x 498Â x 295 mm |
|
|
Number of Service Slots |
16 |
|
|
Switching Capability |
Optical |
Up to 20-degree C-D-C-G ROADM |
|
Electrical |
1.6T ODUK,640G VC4 & 20GÂ VC3& VC12, 800G Packet |
|
|
Channel Spacing |
50/100GHz fixed grid for 40/80-ch |
|
|
37.5-400 GHz flex-grid |
||
|
Wavelength Range |
DWDM: 1529.16 nm to 1560.61 nm (C Band, ITU-T G.694.1) |
|
|
Rate per Channel (Max.) |
100G, 200G, 400G |
|
|
Service Types Supported |
SDH, SONET, Ethernet, SAN, OTN, video |
|
|
Topology |
Point-to-point, chain, star, ring, ring-with-chain, tangent ring, intersecting ring and mesh |
|
|
Redundancy and Protection |
Equipment |
Cross-connect 1+1 backup, control board 1+1 backup and power 1+1 backup, clock 1+1 backup |
|
Network |
OTN: Optical line protect, optical channel protect, ODUk SNCP protection, ODUk SPRing protection, OWSP*,ASON SDH: linear 1+1/1:N/ring MSP, SNCP, TOA, DNI, DLAG&LAG and Fiber Shared-virtual Path Protection, ASON PKT: PW APS, Tunnel APS, MSTP, LAG, LPT, MC LAG |
|
|
Optical Power Management |
ALS, AGC, ALC, APE, IPA |
|
|
Synchronization |
IEEE 1588v2, Sync-E |
|
|
2 Mbit/s or 2 MHz (with the SSM function) |
||
|
External clock source (1PPS+TOD) |
||
|
ASON/GMPLS |
Automatic network discovery |
|
|
ODUk/λ level protection and restoration |
||
|
5-Level SLA (Service Level Agreement) provisioning |
||
|
End-to-end service configuration |
||
|
Shared Risk Link Group (SRLG) |
||
|
Traffic engineering |
||
|
T-SDN |
Automation, IP+Optical , BOD |
|
|
Installation Rack |
ETSI 300/600mm rack , 23 inch rack |
|
|
Heat Dissipation |
Fan |
|
|
Power Supply |
-48VDC/-60VDC |
|
|
Operation Environment |
Temperature: Long-term operation: 5°C to 45°C Short-term operation: -5°C to 50°C |
|
|
Relative humidity: Long-term operation: 5% to 85% Short-term operation: 5% to 95% |
