HKShanhai Group Limited OptiX OSN 9800 U32 bundle, includes Subrack OSN 9800 U32, Subrack OSN 9800 UPS-DC, TN18EFI, TNU1PSU, TNV3EFI01, TNV2FAN01, TN11D4001, TN13OBU101.
The HKShanhai Group Limited OptiX OSN 9800 U series is a next-generation OTN product that features large capacity, ASON, and the integration of OTN and packet functions. Mainly deployed on super networks and regional networks, it is the best 200G/400G OTN platform in the industry.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
HKShanhai Group Limited OptiX OSN 9800 U32 Bundle |
|
|
Dimensions (HxWxD) |
1900Ă—498x295mm |
|
|
Number of Service Slots |
32 |
|
|
Switching Capability |
Optical |
Up to 20-degree C-D-C-G ROADM |
|
Electrical |
6.4 /12.8Tbit/s universal switching |
|
|
Channel Spacing |
50/100GHz fixed grid for 40/80-ch |
|
|
Flex-grid |
||
|
Wavelength Range |
DWDM: 1529.16 nm to 1560.61 nm (C Band, ITU-T G.694.1) |
|
|
Rate per Channel (Max.) |
100G, 200G, 400G, 1T, 2T |
|
|
Service Types Supported |
SDH, SONET, Ethernet, SAN, OTN, video |
Product Details
HKShanhai Group Limited OptiX OSN 9800 Series provides these features and highlights :
• Packet Optical Convergence
– Universal switching, universal transport to maximize network efficiency
•??00G/1T/2T Oriented Platform
– One platform progresses from 100G to 400G/1T/2T for the highest scalability
• T-SDN Based Architecture
– Open and programmable to stimulate rapid business innovation
Figure 1 shows the vision of HKShanhai Group Limited OptiX OSN 9800 U32.
View Overview of HKShanhai Group Limited Transmission Network Hot Series
Get More Information
Do you have any question about the HKShanhai Group Limited OptiX OSN 9800 U32 Bundle
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited OptiX OSN 9800 U32 Bundle Specification
HKShanhai Group Limited OptiX 9800 U32 Specification |
||
|
Dimensions (HxWxD) |
1900x498x295mm |
|
|
Number of Service Slots |
32 |
|
|
Switching Capability |
Optical |
Up to 20-degree C-D-C-G ROADM |
|
Electrical |
6.4 /12.8Tbit/s universal switching |
|
|
Number of Ports |
Max OTU4 Ports |
64/128 |
|
Max 100GE Ports |
64/128 |
|
|
Max OTU3 Ports |
64 |
|
|
Max 40GE Ports |
64 |
|
|
Max OTU2 Ports |
640 |
|
|
Max 10G Ports |
640 |
|
|
Max GE/2.5G Ports |
960 |
|
|
Max OTUC2 Ports |
32 |
|
|
Max OTUC4 Ports |
16/32 |
|
|
Channel Spacing |
50/100GHz fixed grid for 40/80-ch |
|
|
Flex-grid |
||
|
Wavelength Range |
DWDM: 1529.16 nm to 1560.61 nm (C Band, ITU-T G.694.1) |
|
|
Rate per Channel (Max.) |
100G, 200G, 400G, 1T, 2T |
|
|
Service Types Supported |
SDH, SONET, Ethernet, SAN, OTN, video |
|
|
Topology |
Point-to-point, chain, star, ring, ring-with-chain, tangent ring, intersecting ring and mesh |
|
|
Redundancy and Protection |
Equipment |
1+1 power input protection, 1+1 fan protection, M:N switch board protection, 1+1 controller protection |
|
Network |
OTN: Optical line protection, client 1+1 protection, ODUk SNCP, tributary SNCP, intra-board 1+1 protection,LPT, ASON/GMPLS PKT: PW APS, Tunnel APS, LAG |
|
|
Optical Power Management |
ALS, AGC, ALC, APE, IPA |
|
|
Synchronization |
IEEE 1588v2, Sync-E |
|
|
2Mbit/s or 2MHz (with the SSM function), ITU-T G.703-compliant external clock source |
||
|
External clock source (1PPS+TOD) |
||
|
ASON/GMPLS |
Automatic network discovery |
|
|
ODUk/λ level protection and restoration |
||
|
5-Level SLA (Service Level Agreement) provisioning |
||
|
End-to-end service configuration |
||
|
Shared Risk Link Group (SRLG) |
||
|
Traffic engineering |
||
|
T-SDN |
Automation, IP+Optical , BOD |
|
|
Installation Rack |
ETSI 300/600mm rack |
|
|
Heat Dissipation |
Fan |
|
|
Power Supply |
-48VDC/-60VDC |
|
|
Operation Environment |
Temperature: Long-term operation: 5°C to 40°C Short-term operation: -5°C to 45°C |
|
|
Relative humidity: Long-term operation: 5% to 85% Short-term operation: 5% to 90% |
