The Hikvision DS-3E0105P-E/M(B) is a dependable 4 Port Fast Ethernet Unmanaged POE Switch. Designed to offer robust network connectivity and power supply over Ethernet, it is ideal for small to medium-sized businesses seeking a cost-effective networking solution. With its ability to supply power to up to four devices simultaneously, this Hikvision switch ensures efficient and streamlined network operations.
Quick Spec
| Brand | Hikvision |
| Model | DS-3E0105P-E/M(B) |
| Ports | 4 |
| Type | Unmanaged |
| Speed | Fast Ethernet (100Mbps) |
Product Features
- Supports IEEE 802.3af/at Power over Ethernet (PoE)
- 4 Fast Ethernet Ports with PoE capability
- Plug and play setup with no configuration needed
- Provides up to 58W total PoE power budget
- Compact and sturdy design for easy installation
Product Applications
- Small and Medium-sized Business Networks
- IP Surveillance Systems
- VoIP Phone Deployments
Supported Options
| Accessory | Model |
| Power Adapter | DS-PA50 |
| Mounting Kit | DS-MK01 |
| PoE Injector | DS-PI01 |
Compare to Similar Items
| Model | Differences |
| DS-3E0109P-E/M | Offers 8 Ports, higher power budget |
| DS-3E0105P-S | Managed switch, higher feature set |
| DS-3E0105P-E | No mounting kit included |
Get more information
For further details about the Hikvision DS-3E0105P-E/M(B) including pricing and datasheet, contact us through Live Chat or email us at sales@router-switch.com. Check Hikvision DS-3E0105P-E/M(B) price and DS-3E0105P-E/M(B) datasheet, buy Hikvision DS-3E0105P-E/M(B) with best price and fast shipping. Free Live Chat is supported.
Hikvision DS-3E0105P-E/M(B) Specification
DS-3E0105P-E/M(B) Specifications |
|
| Brand | Hikvision |
| Model | DS-3E0105P-E/M(B) |
| Number of Ports | 4 Fast Ethernet Ports |
| Type | Unmanaged POE Switch |
| POE Ports | 4 |
| Uplink Port | 1 Ethernet Uplink Port |
| Network Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Transmission Method | Store-and-Forward |
| MAC Address | 2K |
| Switching Capacity | 1 Gbps |
| Packet Forwarding Rate | 0.744 Mpps |
| Power Supply | DC 48V/0.8A |
| PoE Standards | IEEE 802.3af |
| PoE Power Budget | 58W |
| Operating Temperature | -10��C to 55��C |
| Storage Temperature | -40��C to 70��C |
| Operating Humidity | 10% to 90% |
| Storage Humidity | 5% to 90% |
| Dimensions | 100 x 100 x 26 mm |
| Installation | Desktop, Wall-Mountable |
