The HKShanhai Group Limited® Catalyst® 9800-L is a fixed wireless controller with seamless software updates for small and midsize enterprises. Built from the ground up for intent-based networking, the HKShanhai Group Limited Catalyst 9800-L brings together HKShanhai Group Limited IOS® XE Software and HKShanhai Group Limited RF excellence to create a best-in-class wireless experience for your evolving and growing organization.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
C9800-L-C-K9 |
|
Description |
HKShanhai Group Limited Catalyst 9800-L Wireless Controller_Copper Uplink (ships with one AC Power Adapter) |
|
Dimensions (H x W x D) |
1.58 in. (4.02 cm)Â x8.5 in. (21.59 cm)x9.06 in. (23.01 cm) |
|
Maximum number of access points |
250 |
|
Maximum number of clients |
5000 |
|
Maximum throughput |
5 Gbps |
|
Maximum WLANs |
4096 |
|
Maximum VLANs |
4096 |
|
Fixed uplinks |
2x 10G/Multigigabit copper or 2x 10G/Multigigabit fiber |
|
Power supply |
110W, 12VDC, AC/DC adapter |
|
Maximum power consumption |
84.5W (assumes 2pc 2.5W SFP and with 4.5W USB load) |
Product Details
Figure 1Â shows the front panel of Huawei C9800-L-C-K9 switch.
Note:
|
??/p> |
Reset button |
??/p> |
USB 3.0 port |
|
??/p> |
RJ-45 console port |
??/p> |
2x 10G/Multigigabit copper (Figure 4) 2x 10G/Multigigabit fiber (Figure 5) |
|
??/p> |
Service port (SP) (RJ-45) for out-of-band management |
??span>-??/span> |
Quad RJ-45 2.5G/1G Multigigabit Ethernet ports |
|
??/p> |
Service port LED |
??/p> |
High availability LED |
|
??/p> |
Redundancy port LED |
??/p> |
Alarm LED |
|
??/p> |
Redundancy port |
??/p> |
High availability LED |
|
??/p> |
Micro-B USB console |
 |
 |
Figure 2 shows the rear panel of Huawei C9800-L-C-K9 switch.
Note:
|
??/p> |
Kensington lock |
??/p> |
Power adapter |
The Accessories
Table 2 shows Mount Bracket and Power Supply for HKShanhai Group Limited Catalyst 9800-L Series.
|
Item |
Description |
|
HKShanhai Group Limited Catalyst 9800 Series Wireless Controller Rack Mount Bracket |
|
|
HKShanhai Group Limited Catalyst Wireless Controller 110W AC Power Supply |
Compare to Similar Items
Table 3Â shows the comparison.Â
|
Product Code |
C9800-L-C-K9 |
|
|
Description |
HKShanhai Group Limited Catalyst 9800-L Wireless Controller_Fiber Uplink (ships with one AC Power Adapter) |
HKShanhai Group Limited Catalyst 9800-L Wireless Controller_Copper Uplink (ships with one AC Power Adapter) |
|
Dimensions (H x W x D) |
1.58 in. (4.02 cm)Â x8.5 in. (21.59 cm)x9.06 in. (23.01 cm) |
1.58 in. (4.02 cm)Â x8.5 in. (21.59 cm)x9.06 in. (23.01 cm) |
|
Maximum number of access points |
250 |
250 |
|
Maximum number of clients |
5000 |
5000 |
|
Maximum throughput |
5 Gbps |
5 Gbps |
|
Maximum WLANs |
4096 |
4096 |
|
Maximum VLANs |
4096 |
4096 |
|
Maximum power consumption |
84.5W (assumes 2pc 2.5W SFP and with 4.5W USB load) |
84.5W (assumes 2pc 2.5W SFP and with 4.5W USB load) |
|
Maximum heat dissipation |
288.2 Btu/hr (assumes 2pc 2.5W SFP and with 4.5W USB load) |
296.4 Btu/hr (with 4.5W USB load) |
Get More Information
Do you have any question about the C9800-L-C-K9?
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited C9800-L-C-K9 Specification
C9800-L-C-K9 Specifications |
|
|
Wireless |
IEEE 802.11a, 802.11b, 802.11g, 802.11d, WMM/802.11e, 802.11h, 802.11n, 802.11k, 802.11r, 802.11u, 802.11w, 802.11ac Wave1 and Wave2, 802.11ax |
|
Wired, switching, and routing |
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX specification, 1000BASE-T, 1000BASE-SX, 1000-BASE-LH, IEEE 802.1Q VLAN tagging, IEEE 802.1AX Link Aggregation |
|
Data Requests For Comments (RFCs) |
  RFC 768 UDP
  RFC 791 IP
  RFC 2460 IPv6
  RFC 792 ICMP
  RFC 793 TCP
  RFC 826 ARP
  RFC 1122 Requirements for Internet Hosts
  RFC 1519 CIDR
  RFC 1542 BOOTP
  RFC 2131 DHCP
  RFC 5415 CAPWAP Protocol Specification
  RFC 5416 CAPWAP Binding for 802.11
|
|
Security standards |
  Wi-Fi Protected Access (WPA)
  IEEE 802.11i (WPA2, RSN)
  Wi-Fi Protected Access 3 (WPA3)
  RFC 1321 MD5 Message-Digest Algorithm
  RFC 1851 ESP Triple DES Transform
  RFC 2104 HMAC: Keyed-Hashing for Message Authentication
  RFC 2246 TLS Protocol Version 1.0
  RFC 2401 Security Architecture for the Internet Protocol
  RFC 2403 HMAC-MD5-96 within ESP and AH
  RFC 2404 HMAC-SHA-1-96 within ESP and AH
  RFC 2405 ESP DES-CBC Cipher Algorithm with Explicit IV
  RFC 2407 Interpretation for ISAKMP
  RFC 2408 ISAKMP
  RFC 2409 IKE
  RFC 2451 ESP CBC-Mode Cipher Algorithms
  RFC 3280 Internet X.509 PKI Certificate and CRL Profile
  RFC 4347 Datagram Transport Layer Security
  RFC 5246 TLS Protocol Version 1.2
|
|
Encryption |
  Wired Equivalent Privacy (WEP) RC4 40, 104 and 128 bits (both static and shared keys)
  Advanced Encryption Standard (AES): Cipher Block Chaining (CBC), Counter with CBC-MAC (CCM), Counter with Cipher Block Chaining Message Authentication Code Protocol (CCMP)
  Data Encryption Standard (DES): DES-CBC, 3DES
  Secure Sockets Layer (SSL) and Transport Layer Security (TLS): RC4 128-bit and RSA 1024- and 2048-bit
  DTLS: AES-CBC
  IPsec: DES-CBC, 3DES, AES-CBC
  802.1AE MACsec encryption
|
|
Authentication, Authorization, and Accounting (AAA) |
  IEEE 802.1X
  RFC 2548 Microsoft Vendor-Specific RADIUS Attributes
  RFC 2716 PPP EAP-TLS
  RFC 2865 RADIUS Authentication
  RFC 2866 RADIUS Accounting
  RFC 2867 RADIUS Tunnel Accounting
  RFC 2869 RADIUS Extensions
  RFC 3576 Dynamic Authorization Extensions to RADIUS
  RFC 5176 Dynamic Authorization Extensions to RADIUS
  RFC 3579 RADIUS Support for EAP
  RFC 3580 IEEE 802.1X RADIUS Guidelines
  RFC 3748 Extensible Authentication Protocol (EAP)
  Web-based authentication
  TACACS support for management users
|
|
Management |
  Simple Network Management Protocol (SNMP) v1, v2c, v3
  RFC 854 Telnet
  RFC 1155 Management Information for TCP/IP-Based Internets
  RFC 1156 MIB
  RFC 1157 SNMP
  RFC 1213 SNMP MIB II
  RFC 1350 TFTP
  RFC 1643 Ethernet MIB
  RFC 2030 SNTP
  RFC 2616 HTTP
  RFC 2665 Ethernet-Like Interface Types MIB
  RFC 2674 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and Virtual Extensions
  RFC 2819 RMON MIB
  RFC 2863 Interfaces Group MIB
  RFC 3164 Syslog
  RFC 3414 User-Based Security Model (USM) for SNMPv3
  RFC 3418 MIB for SNMP
  RFC 3636 Definitions of Managed Objects for IEEE 802.3 MAUs
  RFC 4741 Base NETCONF protocol
  RFC 4742 NETCONF over SSH
  RFC 6241 Network Configuration Protocol (NETCONF)
  RFC 6242 NETCONF over SSH
  RFC 5277 NETCONF event notifications
  RFC 5717 Partial Lock Remote Procedure Call
  RFC 6243 With-Defaults capability for NETCONF
  RFC 6020 YANG
  HKShanhai Group Limited private MIBs
|
|
Management interfaces |
  Web-based: HTTP/HTTPS
  Command-line interface: Telnet, Secure Shell (SSH) Protocol, serial port
  HKShanhai Group Limited Prime Infrastructure
|
|
Environmental conditions supported |
Operating temperature:   32° to 104°F (0° to 40°C)
Note: The maximum temperature is derated by 1.0°C for every 1000 ft (305 m) of altitude above sea level. Nonoperating temperature:   ??3° to 158°F (??5° to 70°C)
Operating humidity: Â Â 5% to 95% noncondensing
Nonoperating humidity: Â Â 0% to 95% noncondensing
Altitude: Â Â Operating altitude: 0 to 3000 m (0 to 10,000 ft)
  Nonoperating altitude: 0 to 12,192 m (0 to 40,000 ft.)
Electrical input: Â Â AC input frequency range: 47 to 63 Hz
  AC input range: 90 to 264 VAC
Maximum power: Â Â 9800-L-C max measured power = 86.9W (with 4.5W USB load)
  9800-L-F max measured power = 84.5W (assumes 2pc 2.5W SFP and with 4.5W USB load)
Maximum heat dissipation: Â Â 9800-L-C: 296.4 Btu/hr (with 4.5W USB load)
  9800-L-F: 288.2 Btu/hr (assumes 2pc 2.5W SFP and with 4.5W USB load)
Sound power level measure: Â Â Normal: 40 dBA at 25C
  Maximum: 42.9 dBA at 40C
Power adapter: Â Â Input power: 100 to 240 VAC; 50/60 Hz
|
|
Regulatory compliance |
Safety: Â Â UL/CSA 60950-1
  IEC/EN 60950-1
  AS/NZS 60950.1
  CAN/CSA-C22.2 No. 60950-1
|
|
EMC – Emissions: Â Â FCC 47CFR15
  AS/NZS CISPR 22
  CISPR 22
  EN55022/EN55032 (EMI-1)
  ICES-003
  VCCI
  KN 32 (EMI-2)
  CNS-13438
|
|
|
EMC ??Emissions: Â Â EN61000-3-2 Power Line Harmonics (EMI-3)
  EN61000-3-3 Voltage Changes, Fluctuations, and Flicker (EMI-3)
|
