AIR-CT5508-100-K9 includes 100 access point licenses and delivers superior 802.11n/ac performance that optimized up to nine times wireless performance of 802.11a/g networks. It supports up to 500 access points and 7000 clients with necessary licenses.
Quick Specs
Figure 1 shows the appearance of AIR-CT5508-100-K9.
Table 1 shows the Quick Specs.
|
Product Code |
AIR-CT5508-100-K9 |
|
Access points |
100 licenses include (500 licenses max) |
|
Device Type |
Wireless controller |
|
Ports |
8 x SFP uplinks |
|
Console ports |
10/100/1000 RJ-45 |
|
Wireless standards |
802.11a/b/g/d/e/h/k/n/r/u/w/ac |
|
Dimensions (W x D x H) |
44 x 53.9 x 4.45 cm |
Product Details
Figure 2 shows the front panel of AIR-CT5508-100-K9.
Note??/p>
|
??/p> |
Service port (RJ-45) |
??/p> |
Console port (Mini USB Type B) |
|
??/p> |
Console port (RJ-45) |
??/p> |
SFP distribution ports |
|
??/p> |
Redundant port (RP) for future use (RJ-45) |
??/p> |
Management port LEDs |
|
??/p> |
USB ports 0 and 1 (Type A) |
??/p> |
Expansion module (EM) slot |
· You can use only one console port (either RJ-45 or mini-USB). When you connect to one console port, the other is disabled.
Figure 3 shows the back panel of AIR-CT5508-100-K9.
Note:
|
??/p> |
Power supply PS1 |
??/p> |
Power supply PS2 slot with blank cover |
|
??/p> |
Power supply PS1 on/off switch |
??/p> |
Fan tray |
|
??/p> |
Power supply PS1 AC cable connection |
Compare to Similar Items
Table 3 shows the comparison of similar items.
|
Models |
AIR-CT5508-100-K9 |
||
|
Access Points Licenses |
25 access points licenses |
50 access points licenses |
100 access points licenses |
|
Max Access Points |
500 |
500 |
500 |
|
Max Client Support |
7000 |
7000 |
7000 |
|
Ports |
8 x SFP uplinks |
8 x SFP uplinks |
8 x SFP uplinks |
Get more information
Do you have any question about the AIR-CT5508-100-K9
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited AIR-CT5508-100-K9 Specification
AIR-CT5508-100-K9 Specifications |
|
|
Wireless |
IEEE 802.11a, 802.11b, 802.11g, 802.11d, WMM/802.11e, 802.11h, 802.11k, 802.11n, 802.11r, 802.11u, 802.11w, 802.11ac. |
|
Wired/Switching/Routing |
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX specification, 1000BASE-T. 1000BASE-SX, 1000-BASE-LH, IEEE 802.1Q Vtagging, and IEEE 802.1AX Link Aggregation. |
|
Data Request For Comments (RFC) |
  RFC 768 UDP
  RFC 791 IP
  RFC 2460 IPv6 (pass through Bridging mode only)
  RFC 792 ICMP
  RFC 793 TCP
  RFC 826 ARP
  RFC 1122 Requirements for Internet Hosts
  RFC 1519 CIDR
  RFC 1542 BOOTP
  RFC 2131 DHCP
  RFC 5415 CAPWAP Protocol Specification
  RFC 5416 CAPWAP Binding for 802.11
|
|
Security Standards |
  WPA
  IEEE 802.11i (WPA2, RSN)
  RFC 1321 MD5 Message-Digest Algorithm
  RFC 1851 The ESP Triple DES Transform
  RFC 2104 HMAC: Keyed Hashing for Message Authentication
  RFC 2246 TLS Protocol Version 1.0
  RFC 2401 Security Architecture for the Internet Protocol
  RFC 2403 HMAC-MD5-96 within ESP and AH
  RFC 2404 HMAC-SHA-1-96 within ESP and AH
  RFC 2405 ESP DES-CBC Cipher Algorithm with Explicit IV
  RFC 2406 IPsec
  RFC 2407 Interpretation for ISAKMP
  RFC 2408 ISAKMP
  RFC 2409 IKE
  RFC 2451 ESP CBC-Mode Cipher Algorithms
  RFC 3280 Internet X.509 PKI Certificate and CRL Profile
  RFC 3602 The AES-CBC Cipher Algorithm and Its Use with IPsec
  RFC 3686 Using AES Counter Mode with IPsec ESP
  RFC 4347 Datagram Transport Layer Security
  RFC 4346 TLS Protocol Version 1.1
|
|
Encryption |
  WEP and TKIP-MIC: RC4 40, 104 and 128 bits (both static and shared keys)
  AES: CBC, CCM, CCMP
  DES: DES-CBC, 3DES
  SSL and TLS: RC4 128-bit and RSA 1024- and 2048-bit
  DTLS: AES-CBC
  IPSec: DES-CBC, 3DES, AES-CBC
|
|
Authentication, Authorization, and Accounting (AAA) |
  IEEE 802.1X
  RFC 2548 Microsoft Vendor-Specific RADIUS Attributes
  RFC 2716 PPP EAP-TLS
  RFC 2865 RADIUS Authentication
  RFC 2866 RADIUS Accounting
  RFC 2867 RADIUS Tunnel Accounting
  RFC 2869 RADIUS Extensions
  RFC 3576 Dynamic Authorization Extensions to RADIUS
  RFC 5176 Dynamic Authorization Extensions to RADIUS
  RFC 3579 RADIUS Support for EAP
  RFC 3580 IEEE 802.1X RADIUS Guidelines
  RFC 3748 Extensible Authentication Protocol
  Web-based authentication
  TACACS support for management users
|
|
Management |
  SNMP v1, v2c, v3
  RFC 854 Telnet
  RFC 1155 Management Information for TCP/IP-Based Internets
  RFC 1156 MIB
  RFC 1157 SNMP
  RFC 1213 SNMP MIB II
  RFC 1350 TFTP
  RFC 1643 Ethernet MIB
  RFC 2030 SNTP
  RFC 2616 HTTP
  RFC 2665 Ethernet-Like Interface types MIB
  RFC 2674 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and Virtual Extensions
  RFC 2819 RMON MIB
  RFC 2863 Interfaces Group MIB
  RFC 3164 Syslog
  RFC 3414 User-Based Security Model (USM) for SNMPv3
  RFC 3418 MIB for SNMP
  RFC 3636 Definitions of Managed Objects for IEEE 802.3 MAUs
  HKShanhai Group Limited private MIBs
|
|
Management Interfaces |
  Web-based: HTTP/HTTPS
  Command-line interface: Telnet, Secure Shell (SSH) Protocol, serial port
  HKShanhai Group Limited Wireless Control System (WCS)
|
|
Interfaces and Indicators |
  Uplink: 8 (5508) 1000BaseT, 1000Base-SX and 1000Base-LH transceiver slots
  Small Form-Factor Pluggable (SFP) options (only HKShanhai Group Limited SFPs supported): GLC-T, GLC-SX-MM, GLC-LH-SM
  LED indicators: link
  Service Port: 10/100/1000 Mbps Ethernet (RJ45)
  Service Port: 10/100/1000 Mbps Ethernet (RJ45) For High Availability for future use
  LED indicators: link
  Utility Port: 10/100/1000 Mbps Ethernet (RJ45)
  LED indicators: link
  Expansion Slots: 1 (5508)
  Console Port: RS232 (DB-9 male/RJ-45 connector included), mini-USB
  Other Indicators: Sys, ACT, Power Supply 1, Power Supply 2
|
|
Physical and Environmental |
  Dimensions (WxDxH): 17.30 x 21.20 x 1.75 in. (440 x 539 x 44.5 mm)
  Weight: 20 lbs (9.1 kg) with 2 power supplies
  Temperature: Operating temperature: 32 to 104°F (0 to 40°C); Storage temperature: -13 to 158°F (??5 to 70°C)
  Humidity: Operating humidity: 10 95%, noncondensing. Storage humidity: up to 95%
  Input power: 100 to 240 VAC; 50/60 Hz; 1.05 A at 110 VAC, 115W Maximum; 0.523 A at 220 VAC, 115W Maximum; Test Conditions: Redundant Power Supplies, 40C, Full Traffic
  Heat Dissipation: 392 Btu/hour at 110/220 VAC Maximum
|
|
Regulatory Compliance |
CE Mark Safety: Â Â UL 60950-1:2003
  EN 60950:2000
  EMI and susceptibility (Class A)
  U.S.: FCC Part 15.107 and 15.109
  Canada: ICES-003
  Japan: VCCI
  Europe: EN 55022, EN 55024
|
