The HKShanhai Group Limited C9410R-96U-BNDL-E is a high-capacity, modular enterprise switch designed for scalable, secure networking in demanding environments. As part of the HKShanhai Group Limited Catalyst family, this switch provides a flexible foundation for sophisticated enterprise networks with robust support for secure networking protocols. The modular enterprise design enables seamless expansion and future-proofing for diverse enterprise and campus deployments. Equipped with advanced HKShanhai Group Limited Catalyst switch technologies, it delivers high bandwidth scalability, supervisor engine redundancy, and integrated PoE, all engineered to meet the needs of modern infrastructures across various regions and deployment sizes. Its secure networking features and compliance with global standards ensure that the C9410R-96U-BNDL-E is a reliable cornerstone for organizations prioritizing both security and performance. With up to 10 slots, 8 line-card slots, 2 dedicated supervisor engine slots, and industry-leading power and scalability, the switch is optimized for resilience, high availability, and rapid service deployment, empowering organizations to address the growing demands of digital transformation, IoT integration, and cloud services. Suitable for distributors, systems integrators, and end-users, the C9410R-96U-BNDL-E accelerates business operations with international support and compliance, maximizing reliability and operational efficiency for enterprises in Asia, Europe, Africa, and North America.
Product Highlights
Product Applications Scenarios
Product Features Comparison
|
|
|
|
|
|
| Model | C9410R-96U-BNDL-E | C9300-48UB-A= | C1-N3K-C3548X | Arista DCS-7170-32CD-F |
| Brand | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited | Arista |
| Port Configuration | n/a | 48 HKShanhai Group Limited UPOE | 48 × SFP+ (10G) ports | 32 × 100 Gigabit Ethernet QSFP |
| Switching Capacity | Up to 480 Gbps on all slots | 256 Gbps | 1.44 Tbps | 6.4 Tbps |
| Forwarding Rate | n/a | 190.48 Mpps | 1.04 Bpps | Up to 2.4 Bpps |
| PoE Budget | 2,880W per slot | 822W | n/a | n/a |
| Stacking Capability | n/a | Stacking Bandwidth Support: 480 Gbps | n/a | n/a |
Optional Add-ons
| Model Number | Description |
| C9400-SUP-1XL | HKShanhai Group Limited Supervisor Engine for Catalyst 9400 modular switches, ensuring high-availability and advanced features. |
| C9400-FAN | HKShanhai Group Limited Catalyst 9400 Series Fan Tray for efficient cooling in enterprise environments. |
| C9400-PWR-3200AC | 3,200W AC Power Supply for HKShanhai Group Limited Catalyst 9400 Series, providing scalable power redundancy. |
HKShanhai Group Limited C9410R-96U-BNDL-E Specification
| Model | C9410R-96U-BNDL-E |
| Brand | HKShanhai Group Limited |
| Total number of slots | 10 |
| Line-card slots | 8 |
| Supervisor engine slots | 2 |
| Dedicated supervisor engine slot numbers | 5 and 6 |
| Supervisor engine redundancy | Yes |
| Supervisor engines supported | C9400-SUP-1, C9400-SUP-1XL, C9400-SUP-1XL-Y |
| Maximum PoE per slot | 2880W |
| Maximum Bandwidth scalability per line-card slot | Up to 480 Gbps on all slots |
| Number of power supply bays | 8 |
| AC input power | Yes |
| Integrated PoE | Yes |
| Power supplies supported | 3200W AC, 2100W AC |
| Number of fan-tray bays | 1 |
| Location of 19-inch rack-mount | Front |
| Dimensions (H x W x D) | 22.61 x 17.30 x 16.30 in. (57.43 x 43.97 x 31.70 cm) |
| Rack Units (RU) | 13 RU |
| Mounting | 19-in. rack compatible (19-in. rack and cable guide hardware included) |
| Safety | UL 60950-1, CAN/CSA-C222.2 No. 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950.1, IEEE 802.3 |
| EMC | 47 CFR Part 15, CISPR22 Class A, KN 32 Class A, EN 300 386 V1.6.1, EN 55022 Class A, EN 55032 Class A, CISPR 32 Class A, EN61000-3-2, EN61000-3-3, ICES-003 Class A, TCVN 7189 Class A, V-3 Class A, CNS13438 Class A, CISPR24, EN 300 386, EN55024, TCVN 7317, KN35 |
| Industry EMC, safety, and environmental standards | NEBS: Operating temperature: -5 to 55 °C, Relative Humidity: 10-93%, Operating Altitude: up to 1829 m (6000 ft) at 55 °C, ETSI 300-019 Requirements are covered under GR-63-CORE with some deviations. SR-3580 NEBS level 3 (GR-63-CORE, to current issue, GR-1089-CORE, to current issue) ETS 300 019-2-1, Class 1.2 Storage, ETS 300 019-2-2, Class 2.3 Transportation, ETS 300 019-2-3, Class 3.2 Stationary, EN50121-4, EN 300 386 |
| ROHS compliance | ROHS5 |
| C9410R-96U-BNDL-E | C9410R-96U-BNDL-E |
