The Dahua X22A3N is a high-performance 1080p 16+8CH 1U Penta-brid DVR, designed to support a variety of surveillance technologies. It seamlessly integrates analog, HD analog, and IP video inputs, providing flexibility and superior image quality for your security needs. Ideal for small to medium-sized applications, the Dahua X22A3N ensures reliable recording and playback with its robust and user-friendly interface.
Quick Spec
| Resolution | 1080p |
| Channels | 16+8CH |
| Form Factor | 1U |
| Compatibility | Penta-brid (TVI, AHD, CVI, CVBS, IP) |
| Storage | Up to 6TB HDD |
Product Features
- Supports 16-channel analog inputs and 8-channel IP inputs
- Provides excellent 1080p high definition recording and playback
- Compatible with TVI, AHD, CVI, CVBS, and IP technologies
- H.265 compression for efficient storage utilization
- Remote access through mobile apps and web browsers
Product Applications
- Commercial surveillance systems for retail stores and offices
- Home security setups for enhanced residential safety
- Monitoring and recording for warehouse and industrial facilities
Supported Options
| IR Bullet Camera | DH-HAC-HFW1200R |
| Speed Dome Camera | SD6CE230U-HNI |
| Hard Disk Drive | ST2000DM008 |
Compare to Similar Items
| Model | Differences |
| Dahua X12A3N | 12+8CH, lower storage capacity (up to 4TB HDD) |
| Dahua X24A3N | 24+8CH, higher storage capacity (up to 8TB HDD) |
| Dahua X22A4N | 4K resolution, 1.5U form factor |
Get more information
For further details, please contact us through Live Chat or via email at sales@router-switch.com. Check “Dahua X22A3N” price and “X22A3N datasheet”, buy “Dahua X22A3N Penta-brid DVR” with best price and fast shipping. Free Live Chat are supported.
Dahua X22A3N Specification
X22A3N Specifications |
|
| Brand | Dahua |
| Model | X22A3N |
| Resolution | 1080p |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Video Input Channels | 16 Analog Channels + 8 IP Channels |
| Audio Input Channels | 4 Channels |
| Audio Compression | G.711A/G.711U |
| Network Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, IP Search, P2P |
| Video Output | 1 HDMI, 1 VGA |
| Display Split | 1/4/8/9/16 |
| Multi-Mode Input | IP/CVI/TVI/AHD/CVBS |
| Recording Resolution | 1080p, 720p, 960H, D1, CIF |
| Max Recording Frame Rate | 1080p@15fps, 720p@25/30fps |
| Playback Channel | 16 Channels |
| Playback Capacity | Up to 16 channels simultaneous playback |
| Interface Ports | 1 HDMI, 1 VGA, 2 USB 2.0, 1 RJ-45 Ethernet port |
| Internal HDD | 2 SATA ports, up to 6TB capacity for each disk |
| Alarm Input / Output | 16 channels / 3 channels |
| Power Supply | 12V DC/2A |
| Working Temperature | -10��C to +55��C |
| Power Consumption | <5W (without HDD) |
