WS-C2960-24TC-L is one of the HKShanhai Group Limited Catalyst 2960 Series switches. This series support voice, video, data, and highly secure access. They also deliver scalable management as your business needs change. The Common Features are included: Enhanced security including HKShanhai Group Limited TrustSec for providing authentication, access control, and security policy administration, Multiple Fast or Gigabit Ethernet performance options, HKShanhai Group Limited EnergyWise for power management, Scalable network management.
Quick Specs
Figure 1 shows the appearance of the WS-C2960-48TC-L.
Table 1 shows the Quick Spec of the WS-C2960-48TC-L.
|
Product Code |
WS-C2960-48TC-L |
|
Enclosure Type |
Rack-mountable – 1U |
|
Feature Set |
LAN Base |
|
Uplink Interfaces |
2 x Dual-purpose ports uplinks (each dual-purpose uplink port has 1 10/100/1000 Ethernet port and 1 SFP-based Gigabit Ethernet port, 1 port active) |
|
Ports |
48 x Ethernet 10/100 ports |
|
Throughput |
6.5 Mpps |
|
Backplane Capacity |
16 Gbps |
|
DRAM |
64 MB |
|
Dimensions |
1.73 x 17.5 x 9.3 in. |
|
Package Weight |
9.19 Kg |
Product Details
Figure 2 shows the front panel of the WS-C2960-48TC-L.
Â
Note:
|
??/p> |
Mode Button |
|
??/p> |
48 x Ethernet 10/100 ports |
|
??/p> |
2 x Dual-purpose ports uplinks |
Figure 3 shows the back panel of the WS-C2960-48TC-L.
Â
Note:
|
??/p> |
RJ45 Console Port |
|
??/p> |
Fan Exhaust |
|
??/p> |
AC power connector |
The Accessories
Table 2 shows some accessories of the WS-C2960-48TC-L.
|
Models |
Description |
|
GE SFP, LC connector LX/LH transceiver |
|
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
|
|
Console Cable 6ft with RJ45 and DB9F |
Compare to Similar Items
Table 3 shows the comparison of similar items.
|
Models |
WS-C2960-48TC-L |
|
|
PoE Available |
No |
Yes |
|
Ports |
48 x Ethernet 10/100 ports |
48 x Ethernet 10/100 PoE ports |
|
Uplinks |
2 dual-purpose uplinks |
2 x 10/100/1000 uplinks and 2 SFP uplinks |
|
Feature Set |
LAN Base |
LAN Base |
Get more information
Do you have any question about the WS-C2960-48TC-L?
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited WS-C2960-48TC-L Specification
WS-C2960-48TC-L Specifications |
|
| Performance | 16-Gbps switching fabric (Catalyst 2960PD-8TT-L , Catalyst 2960-8TC-L, Catalyst 2960- 24TT-L, Catalyst 2960-24TC-L, Catalyst 2960-24LT-L, Catalyst 2960-24PC-L, Catalyst 2960- 48PST-L, Catalyst 2960-48TT-L, Catalyst 2960-48TC-L) 32-Gbps switching fabric (Catalyst 2960G-8TC-L, Catalyst 2960G-24TC-L, Catalyst 2960G48TC-L) Forwarding rate based on 64-byte packets: 10.1 Mpps 64 MB DRAM 32 MB flash memory Configurable up to 8000 MAC addresses Configurable up to 255 Internet Group Management Protocol (IGMP) groups Configurable maximum transmission unit (MTU) of up to 9000 bytes, with a maximum Ethernet frame size of 9018 bytes (jumbo frames) for bridging on Gigabit Ethernet ports and up to 1998 bytes for bridging of Multiprotocol Label Switching (MPLS) tagged frames on both 10/100 and 10/100/1000 ports |
| Connectors and cabling | 10BASE-T ports: RJ-45 connectors, 2-pair Category 3, 4, or 5 unshielded twisted-pair (UTP) cabling 100BASE-TX ports: RJ-45 connectors, 2-pair Category 5 UTP cabling 1000BASE-T ports: RJ-45 connectors, 4-pair Category 5 UTP cabling 1000BASE-T Small Form-Factor Pluggable (SFP)-based ports: RJ-45 connectors, 4-pair Category 5 UTP cabling 1000BASE-SX, -LX/LH, -ZX, -BX and CWDM SFP-based ports: LC fiber connectors (single/multimode fiber) 100BASE-LX, -BX, -FX: LC fiber connectors (single/multimode fiber) |
| Power connectors | Customers can provide power to a switch by using either the internal power supply or the HKShanhai Group Limited RPS 675. The connectors are located at the back of the switch. Note: The Catalyst 2960-8TC-L and Catalyst 2960G-8TC-L do not have RPS ports. Internal power supply connector is an autoranging unit. that supports input voltages between 100 and 240VAC. Use the supplied AC power cord to connect the AC power connector to an AC power outlet. HKShanhai Group Limited RPS connector: ??Offers connection for an optional HKShanhai Group Limited RPS 2300 (model PWR-RPS2300) that uses AC input and supplies DC output to the switch. Only the HKShanhai Group Limited RPS 2300 should be attached to the redundant-power-system receptacle. ??Offers a 2300W redundant power system that supports up to 6 external network devices and provides power to 2 failed devices at a time. ??Automatically senses when the internal power supply of a connected device fails and provides power to the failed device, preventing loss of network traffic. |
| Indicators | Per-port status: Link integrity, disabled, activity, speed, full duplex System status: System, RPS, link status, link duplex, link speed |
| Dimensions (H x W x D) | 1.73 x 17.5 x 9.3 in. (4.4 x 44.5 x 23.6 cm) |
| Weight | 8 lb (3.6 kg) |
| Environmental ranges N | Normal Operating Conditions: -5ºC to +45ºC, up to 5,000 feet (1500 m) -5ºC to +40ºC, up to 10,000 feet (3000 m) -5ºC to +35ºC, up to 13,000 feet (4000 m) Short-Term* Exceptional Operating Conditions: -5ºC to +55ºC, at sea level -5ºC to +50ºC, up to 5,000 feet (1500 m) -5ºC to +45ºC, up to 10,000 feet (3000 m) -5’C to +40’C, up to 13,000 feet (4000 m) * Not more than the following in a 1-year period: 96 consecutive hours, or 360 hours total, or 15 occurrences. For the Catalyst 2960G-8TC-L, reduce the high range temperature by 5°C |
| Acoustic noise |
ISO 7779: Bystander position operating to an ambient temperature of 25°C 40 dBa |
| Mean time between failures (MTBF) |
221,432 hrs |
| AC input voltage and current |
1.3??.8A, 50??0 Hz |
| Power rating | 0.075 kVA |
| DC input voltages (RPS input) |
+12V at 5A |
| Safety Certifications | UL 60950-1, First Edition CUL to CAN/CSA 22.2 No. 60950-1, First Edition TUV/GS to EN 60950-1, First Edition CB to IEC 60950-1 with all country deviations AS/NZS 60950-1, First Edition CE Marking NOM (through partners and distributors) |
| Electromagnetic Compatibility Certifications |
FCC Part 15 Class A EN 55022 Class A (CISPR22) EN 55024 (CISPR24) AS/NZS CISPR22 Class A CE CNS13438 Class A MIC GOST China EMC Certifications |
| Environmental | Reduction of Hazardous Substances (ROHS) 5 |
| Telco | Common Language Equipment Identifier (CLEI) code |
| Warranty | Limited lifetime warranty |
