VS-S2T-10G-XL is HKShanhai Group Limited Catalyst 6500 Series Supervisor Engine 2T XL. The Supervisor Engine 2T is designed to deliver higher performance, better scalability, and enhanced hardware-enabled features. Supervisor Engine 2T integrates a high-performance 2-Terabit crossbar switch fabric that enables 80 Gbps switching capacity per slot on all HKShanhai Group Limited Catalyst 6500 E-Series Chassis. This VS-S2T-10G-XL is similar with the VS-S2T-10G-XL=. The VS-S2T-10G-XL= is a spare one.
Quick Specs
Figure 1 shows the appearance of VS-S2T-10G-XL.
Table 1 shows the Quick Specs.
|
Product Code |
VS-S2T-10G-XL |
|
Chassis compatibility |
Supported on all Catalyst 6500 E-series chassis and Catalyst 6807-XL chassis |
|
Switch fabric |
2.08 Tbps Crossbar Switch Fabric with 26 Fabric Channels |
|
Software compatibility |
12.2(50)SY |
|
Uplink ports (PORT 1 through PORT 5) |
·Five uplink ports: ·Two 10GBASE-X ports |
|
Console ports |
One console port (RJ-45) |
|
Compact Flash |
1GB |
|
DRAM |
2GB for Lite and XL (4GB upgrade with 2GB memory upgrade (2+2) |
|
NVRAM |
4 MB |
|
switching capacity |
up to 80 Gbps per slot of switching capacity on E-Series chassis |
|
Routes |
1024K (IPv4) 512K (IPv6) |
|
Netflow entries |
512K |
|
Layer-3 classification and marking access control entries (ACEs) |
256K shared for QOS/Security |
|
Layer 2 rate limiters |
20 ingress/6 egress |
|
Security ACL entries |
256K shared for QOS/Security |
|
Power requirement (at 42 VDC) |
10.71 A |
|
Dimensions (H x W x D) |
1.73 x 14.4 x 16.0 in. (4.4 x 36.6 x 40.6 cm). Occupies one slot in the chassis |
|
Weight |
12.0 lb (5.44 kg) |
Product Details
Figure 2 shows the front panel of VS-S2T-10G-XL.
Note:
|
??/p> |
PCMCIA slot |
|
??/p> |
1000BASE-X UPLINK ports (requires SFP transceivers) |
|
??/p> |
MANAGEMENT port |
|
??/p> |
CONSOLE port |
|
??/p> |
10GBASE-X UPLINK ports (requires X2 transceivers |
|
??/p> |
USB port |
|
??/p> |
Port currently not supported |
The Accessories
Table 2 shows the recommended elements for the VS-S2T-10G-XL.
|
Category |
Model |
Description |
|
GLC Options
|
1000BASE-BX SFP, 1310NM |
|
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
||
|
X2 Module
|
10GBASE-LR X2 Module |
|
|
10GBASE-ZR X2 Module |
Compare to Similar Items
Table 3 shows the comparison of VS-S2T-10G-XL and VS-S2T-10G.
|
Product Code |
|||
|
Chassis compatibility |
Supported on all Catalyst 6500 E-series chassis and Catalyst 6807-XL chassis |
Supported on all Catalyst 6500 E-series chassis and Catalyst 6807-XL chassis |
|
|
Switch fabric |
2.08 Tbps Crossbar Switch Fabric with 26 Fabric Channels |
2.08 Tbps Crossbar Switch Fabric with 26 Fabric Channels |
|
|
Uplink ports |
·Five uplink ports: ·Two 10GBASE-X ports |
·Five uplink ports: ·Two 10GBASE-X ports |
|
|
Console ports |
One console port (RJ-45) |
One console port (RJ-45) |
|
|
Compact Flash |
1GB |
1GB |
|
|
switching capacity |
up to 80 Gbps per slot of switching capacity on E-Series chassis |
up to 80 Gbps per slot of switching capacity on E-Series chassis |
|
|
Routes |
256K(IPv4) 128K (IPv6) |
1024K (IPv4) 512K (IPv6) |
|
|
Security ACL entries |
64K shared for QOS / Security |
256K shared for QOS/Security |
|
|
Power requirement (at 42 VDC) |
10.36 A |
10.71 A |
|
Get more information
Do you have any question about the VS-S2T-10G-XL
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited VS-S2T-10G-XL Specification
|
VS-S2T-10G-XL Specification |
|
|
Product Description |
Catalyst 6500 Supervisor VS-S2T-10G-XL |
|
Devide Tyde |
Control Processor |
|
Ports |
2 * 10G X2 ports, 3 * 1G SFP ports |
|
Console ports |
10/100/1000 RJ-45 |
|
Centralized switching capacity |
2 Tbps, 4 Tbps(with VSS) |
|
Per-slot switching capacity |
80 Gbps |
|
FNF (Flexible NetFlow) entries |
1,024,000 |
|
Forn Factor |
Plug-in Module |
|
DRAM |
2GB for Lite and XL (4GB upgrade with 2GB memory upgrade (2+2)) |
|
NVRAM |
4 MB |
|
Compact Flash |
1GB |
|
Throughput |
● ??20 Mpps for IPv4 |
|
Routing entries |
● IPV4: 1024,000 |
|
Bridge domains |
16,000 |
|
Security ACL entries |
256K shared for QoS / Security |
|
Acl labels |
16,000 |
|
CPU rate limiters (Dos protection) |
57 |
|
Aggregate traffic rate-limiting policers |
16,348 |
|
Layer 2 rate limiters |
20 ingress / 6 egress |
|
MAC entries |
512,000 |
|
Forwarding Entries |
1024,000 per system |
|
VRFs |
8,192 |
|
GRE |
390 Mpps |
|
uRPF check (IPV4/IPV6) |
up to 16 |
|
Slot assignment |
●Catalyst 6503-E: Slot 1 and 2 |
|
Fan tray and power supply supported |
●??400W for 6503-E |
|
Software Compatibility |
●??2.2(50)SY and future releases |
|
Reliability and Availability |
● Virt ual Switching System (VSS) |
|
Memory |
● MEM-SUP2T-2GB: HKShanhai Group Limited Catalyst 6500 2GB Memory for Supervisor Engine 2T |
|
Compact Flash memory |
● MEM-C6K-CPTFL1G: Catalyst 6500 Compact Flash Memory 1GB |
|
Service Modules |
ACE 20, ACE 30, NAM-1, NAM-2, NAM-3, FWSM, ASA-SM, WiSM-1, WiSM-2 |
|
SW packages |
● IP BASE |
