VS-S2T-10G is HKShanhai Group Limited Catalyst 6500 Series Supervisor Engine 2T. The Supervisor Engine 2T is designed to deliver higher performance, better scalability, and enhanced hardware-enabled features. Supervisor Engine 2T integrates a high-performance 2-Terabit crossbar switch fabric that enables 80 Gbps switching capacity per slot on all HKShanhai Group Limited Catalyst 6500 E-Series Chassis. This VS-S2T-10G is similar with the VS-S2T-10G=. The VS-S2T-10G= is a spare one.
Quick Specs
Figure 1 shows the appearance of VS-S2T-10G.
Table 1 shows the Quick Specs.
|
Product Code |
VS-S2T-10G |
|
Chassis compatibility |
 Supported on all Catalyst 6500 E-series chassis and Catalyst 6807-XL chassis |
|
Switch fabric |
2.08 Tbps Crossbar Switch Fabric with 26 Fabric Channels |
|
Software compatibility |
12.2(50)SY |
|
Uplink ports (PORT 1 through PORT 5) |
·Supervisor Engine 2T has five uplink ports:  ·Two 10GBASE-X ports |
|
Console ports |
One console port (RJ-45) |
|
Compact Flash |
1GB |
|
DRAM |
 2GB for Lite and XL (4GB upgrade with 2GB memory upgrade (2+2) |
|
NVRAM |
4 MB |
|
switching capacity |
up to 80 Gbps per slot of switching capacity on E-Series chassis |
|
Routes |
256K(IPv4) 128K (IPv6) |
|
Netflow entries |
512K |
|
Layer-3 classification and marking access control entries (ACEs) |
64K shared for QOS / Security |
|
Layer 2 rate limiters |
20 ingress/6 egress |
|
Security ACL entries |
64K shared for QOS / Security |
|
Power requirement (at 42 VDC) |
10.36 A |
|
Dimensions (H x W x D) |
1.73 x 14.4 x 16.0 in. (4.4 x 36.6 x 40.6 cm). Occupies one slot in the chassis |
|
Weight |
12.0 lb (5.44 kg) |
Product Details
Figure 2 shows the front panel of VS-S2T-10G.
Note:
|
??/p> |
PCMCIA slot |
|
??/p> |
1000BASE-X UPLINK ports (requires SFP transceivers) |
|
??/p> |
MANAGEMENT port |
|
??/p> |
CONSOLE port |
|
??/p> |
10GBASE-X UPLINK ports (requires X2 transceivers |
|
??/p> |
USB port |
|
??/p> |
Port currently not supported |
The Accessories
Table 2 shows the recommended elements for the VS-S2T-10G.
|
Category |
Model |
Description |
|
GLC Options  |
1000BASE-BX SFP, 1310NM |
|
|
1000BASE-SX SFP transceiver module, MMF, 850nm, DOM |
||
|
X2 Module  |
10GBASE-LR X2 Module |
|
|
10GBASE-ZR X2 Module |
Compare to Similar Items
Table 3 shows the comparison of VS-S2T-10G and VS-S2T-10G-XL.
|
Product Code |
VS-S2T-10G |
|
|
Chassis compatibility |
 E-Series only: HKShanhai Group Limited Catalyst 6503-E, 6504-E, 6506-E, 6509-E, 6509-V-E, 6513E |
 E-Series only: HKShanhai Group Limited Catalyst 6503-E, 6504-E, 6506-E, 6509-E, 6509-V-E, 6513E |
|
Switch fabric |
2.08 Tbps Crossbar Switch Fabric with 26 Fabric Channels |
2.08 Tbps Crossbar Switch Fabric with 26 Fabric Channels |
|
Uplink ports |
·3 x GE SFP Ports ·2 x 10G X2 Ports ·1 x 10/100/1000 Management Port |
 ·3 x GE SFP Ports ·2 x 10G X2 Ports ·1 x 10/100/1000 Management Port |
|
Console ports |
One console port (RJ-45) |
One console port (RJ-45) |
|
Compact Flash |
1GB |
1GB |
|
DRAM |
 2GB for Lite and XL (4GB upgrade with 2GB memory upgrade (2+2) |
 2GB for Lite and XL (4GB upgrade with 2GB memory upgrade (2+2) |
|
NVRAM |
4 MB |
4 MB |
|
switching capacity |
up to 80 Gbps per slot of switching capacity on E-Series chassis |
up to 80 Gbps per slot of switching capacity on E-Series chassis |
|
Routes |
256K(IPv4) 128K (IPv6) |
1024K (IPv4) 512K (IPv6) |
|
Security ACL entries |
64K shared for QOS / Security |
256K shared for QOS/Security |
Get more information
Do you have any question about the VS-S2T-10G
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited VS-S2T-10G Specification
| Model | WS-X4724-SFP-E |
| Brand | HKShanhai Group Limited |
| Type | E-Series Gigabit Ethernet SFP Line Cards |
| Number of Ports | 24 |
| Port Speed | 1GbE/100Mbps |
| Port Type | Pluggables |
| Wire Rate | 1:1 |
| Standards | ??Gigabit Ethernet: IEEE 802.3z, IEEE 802.3x, IEEE 802.3ab, IEEE 803.3at, IEEE 802.3af, IEEE 802.3az??1000BASE-X (GBIC), 1000BASE-SX, 1000BASE-LX/LH, 1000BASE-ZX, CWDM |
| EtherChannel Technology | ??Gigabit EtherChannel: All 1000 Mbps ports??10 Gigabit EtherChannel: All 10Gbps ports??IEEE 802.3ad (Link Aggregation Control Protocol): All 1000 Mbps ports??Port Aggregation Protocol (PagP): Yes??Number of ports per tuple: 8??EtherChannel and IEEE 802.3ad technology across line cards: Yes |
| Physical Dimensions | ??Occupies one slot in the HKShanhai Group Limited Catalyst 4500 Series platform??Dimensions (H x W x D): 1.2 x 14.25 x 10.75 in. (3.0 x 36.2 x 27.3 cm) |
| Environmental Conditions | ??Operating temperature: 32°F to 104°F (0°C to 40°C)??Storage temperature: -40°F to 167°F (-40°C to 75°C)??Relative humidity: 10 to 90%, noncondensing??Operating altitude: -60 to 3000m |
| Safety Conditions | Fiber optic lasers: Class 1 laser products |
| Safety Certifications | ??UL 1950??EN 60950??CSA-C22.2 no 950??IEC 950??IEC 60950-1, 2nd Ed. EN 60950-1, 2nd Ed. UL 60950-1, 2nd Ed. CAN/CSA-C22.2 No. 60950-1 2nd Ed.11 |
| Electromagnetic Emissions Certifications | ??FCC 15J Class A??VCCI Class A??CE Marking??EN 55022 Class A??EN 55024 Class A??CISPR 22 Class A??AS/NZ 3548??NEBS Level 3 (GR-1089-CORE, GR-63-CORE)??ETSI ETS-300386-2??EN 50121-4 |
| ROHS Compliance | ROHS5 |
| Max Rated Power (W) | 40 |
| Rated MTBF (Hours) | 1,139,510 |
