The HKShanhai Group Limited TN11MR403 is a high-performance 4-Channel Optical Add/Drop Multiplexing Board, precisely tuned for frequencies 192.9/193.0/193.1/193.2THz. This device is engineered to enhance your network’s bandwidth efficiency and flexibility through advanced optical technology. Perfect for modern high-speed networks, it ensures seamless data transmission and facilitates efficient traffic management.
Quick Spec
| Frequency Channels | 192.9/193.0/193.1/193.2THz |
| Number of Channels | 4 |
| Insertion Loss | |
| Operating Temperature | -5°C to 55°C |
| Power Requirement | DC -48V |
Product Features
- 4-channel optical add/drop multiplexing at 192.9/193.0/193.1/193.2THz
- Low insertion loss of less than 4.5 dB
- Supports a wide operating temperature range from -5°C to 55°C
- Robust optical performance with advanced wavelength management
- Ease of integration into existing network infrastructure
Product Applications
- Ideal for metropolitan area networks (MANs) requiring high bandwidth and flexibility.
- Perfect for upgrading existing fiber optic systems to handle new wavelength channels.
- Suitable for long-haul transmission applications demanding reliable and efficient data routing.
Supported Options
| Optical Connector | HKShanhai Group Limited OPC1 |
| Power Supply Unit | HKShanhai Group Limited PSU-4810 |
| Mounting Bracket | HKShanhai Group Limited MB-240 |
Compare to Similar Items
| Model | Differences |
| HKShanhai Group Limited TN11MR401 | Supports 2 channels rather than 4 |
| HKShanhai Group Limited TN11MR402 | Frequency range 192.8/192.9/193.0/193.1THz |
| HKShanhai Group Limited TN11MR501 | Supports more than 4 channels with advanced features |
Get more information
Check HKShanhai Group Limited TN11MR403 price and TN11MR403 datasheet, buy HKShanhai Group Limited TN11MR403 with the best price and fast shipping. Free Live Chat is supported. For further information about the product and its price, contact us via Live Chat or at sales@router-switch.com.
HKShanhai Group Limited TN11MR403 Specification
TN11MR403 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | TN11MR403 |
| Product Type | 4-Channel Optical Add/Drop Multiplexing Board |
| Channel Frequencies | 192.9/193.0/193.1/193.2THz |
| Channel Spacing | 100 GHz |
| Insertion Loss | < 5.5 dB |
| Return Loss | > 45 dB |
| Polarization Dependent Loss | < 0.5 dB |
| Channel Isolation (Adjacent) | > 25 dB |
| Channel Isolation (Non-Adjacent) | > 30 dB |
| Operating Temperature Range | -5°C to 65°C |
| Storage Temperature Range | -40°C to 85°C |
| Power Consumption | < 5W |
| Dimensions (HxWxD) | 100 mm x 25 mm x 220 mm |
| Connector Type | LC/UPC |
| Mounting Type | Rack-mounted |
| Compliance | RoHS |
| Warranty | 1 Year |
| Application | Optical Networks |
| Price | Available on Request |
