SD6AL233XA-HNR, Dahua SD6AL Series Network Camera, 2MP 33x Zoom/Laser IR/AI PTZ

Camera

Image Sensor

1/1.8″ CMOS

Max. Resolution

1920 (H) x 1080 (V)

Effective Pixels

2MP

ROM

4GB

RAM

1GB

Electronic Shutter Speed

1/3??/30000 s

Scanning System

Progressive

Min. Illumination

Color: 0.001Lux@F1.5
B/W: 0.0001Lux@F1.5
0Lux (IR light on)

IR Distance

550m ( 1804ft )

IR On/Off Control

Zoom Prio/Manual/SmartIR

IR LEDs Number

Laser Module

Wiper

Support

Lens

Focal Length

5.8 mm??91.4 mm

Max. Aperture

F1.5–F4.8

Field of View

H: 60.1°??.2°; V: 35.3° ??.8°; D: 67.9°??.7°

Optical Zoom

33x

Focus Control

Auto/Semi-Auto/Manual

Close Focus Distance

0.1 m?? m (0.33 ft??.28 ft)

Iris Control

Auto/Manual

DORI Distance

Detect

Observe

Recognize

Identify

1655 m
(5429.80ft)

622 m
(2040.68ft)

331 m
(1085.96ft)

165 m
(541.34 ft)

PTZ

Pan/Tilt Range

Pan: 0°??60°
Tilt: -20°??90°

Manual Control Speed

Pan: 0.1°/s??00°/s
Tilt: 0.1°/s??20°/s

Preset Speed

Pan: 240°/s
Tilt: 200°/s

Presets

300

Tour

8 (up to 32 presets per tour)

Pattern Number

5

Scanning Number

5

Speed Adjustment

Support

Power-off Memory

Support

Idle Motion

Preset/Tour/Pattern/Scanning

Protocol

DH-SD
Pelco-P/D (auto recognition)

Artifical Intelligence

Video Metadata

Support human, motor vehicle and non-motor vehicle image capture.

Perimeter Protection

Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc.

SMD Plus

Support

Auto Tracking

Support

Face Detection

Support

General Intelligence

Event Trigger

Motion detection, video tampering, scene changing, network disconnection, IP address conflict, illegal access, and storage anomaly.

General IVS

Object Abandoned/Missing

Video

Compression

H.265/H.265+/H.264+/H.264/MJPEG (sub stream)

Streaming Capability

3 streams

Resolution

1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)

Frame Rate

Main stream: 1080P/1.3M/720P (1??0/60fps)
Sub stream 1: D1/CIF (1??5/30fps)
Sub stream 2: 1080P/1.3M/720P/D1/CIF (1??5/30fps)

Bit Rate Control

Variable Bit Rate/Constant Bit Rate

Bit Rate

H.265/H.264: 3 kbps??0480 kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Support

WDR

120 dB

HLC

Support

White Balance

Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street lamp

Gain Control

Auto/Manual

Noise Reduction

2D/3D

Motion Detection

Support

Region of Interest

Support

Electronic Image Stabilization

Support

Defog

Support

Digital Zoom

16x

Flip

0°/180°

Privacy Masking

Up to 24 areas

Audio

Compression

G.711A; G.711Mu; G.726; AAC; G.722.1; G.723; G.729; PCM; MPEG2-Layer2

Certification

Certifications

CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB,ANSI C63.4-2014

Port

Audio In

1 (LINE IN; bare wire)

Audio Out

1 (LINE OUT; bare wire)

Alarm Port

7/2

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3(MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP

Interoperability

ONVIF Profile S&G; CGI

Streaming Method

Unicast/Multicast

User/Host

20 (Total bandwidth 48M)

Edge Storage

FTP; Micro SD card (256G); P2P

Browser

IE7 and newer versions
Chrome 42 and older versions
Firefox 52 and older versions
Safari

Management Software

Smart Player; Smart PSS; DSS; Easy4ip

Smart Phone

IOS/Android

Power

Power Supply

AC24V/3A±25%
Hi-PoE

Power Consumption

20W
33W (Laser on)

Environment

Operating Temperature

-40°C to +70°C (-40°F to +158°F)

Operating Humidity

??5%RH

Ingress Protection

IP67; TVS 8000V lightning proof; surge protection

Structure

Casing

Metal

Dimensions

Φ240 mm x 382 mm (9.45″ × 15.04″)

Net Weight

6.75 kg (14.88 lb)

Gross Weight

10.1 kg (22.27 lb)
