The Dahua SD22204T-GN is a robust and versatile 2MP 4x PTZ Network Camera, designed to deliver exceptional video quality and advanced surveillance features. This high-performance camera offers precise control, zoom capabilities, and reliable network performance, making it an ideal solution for various indoor and outdoor security applications.
Quick Spec
| Resolution | 2MP |
| Optical Zoom | 4x |
| Lens | 2.7-11mm |
| Pan/Tilt Range | 355 Pan / -2~90 Tilt |
| IR Distance | 30 meters |
Product Features
- 2 Megapixel high-resolution video quality.
- 4x optical zoom for detailed viewing.
- Built-in IR LEDs for clear night vision up to 30 meters.
- Wide Dynamic Range (WDR) for optimal performance in diverse lighting.
- IP66 weather-resistant rating for outdoor use.
Product Applications
- Ideal for monitoring large indoor spaces such as warehouses and retail stores with its PTZ capabilities.
- Effective for outdoor perimeter surveillance in parking lots and industrial sites.
- Suitable for monitoring public areas in cities, providing high-resolution images and broad coverage.
Supported Options
| Mount Bracket | PFA100 |
| Junction Box | PFA101 |
| Power Supply | DH-PFM321D-US |
Compare to Similar Items
| Model | Difference |
| Dahua SD49225T-HN | Higher optical zoom (25x), larger IR distance (100 meters) |
| Dahua SD22204-GC | Lower resolution (1.3MP), shorter zoom range (3x) |
| Dahua SD22404T-GN | Similar resolution, integrated microphone for audio recording |
Get more information
For further information about the Dahua SD22204T-GN, including pricing and detailed specifications, please contact us through Live Chat or at sales@router-switch.com. Check ‘Dahua SD22204T-GN’ price and ‘SD22204T-GN datasheet, buy ‘Dahua SD22204T-GN Camera’ with the best price and fast shipping. Free Live Chat is supported.
Dahua SD22204T-GN Specification
SD22204T-GN Specifications |
|
| Brand | Dahua |
| Model | SD22204T-GN |
| Camera Type | PTZ Network Camera |
| Image Sensor | 1/2.7�� 2 Megapixel CMOS |
| Effective Pixels | 1920 (H) x 1080 (V) |
| Zoom | 4x Optical Zoom |
| Lens | 2.7 mm ~ 11 mm |
| Max. Aperture | F1.6 ~ F3.0 |
| Angle of View | H: 112�� ~ 30�� |
| Pan Range | 0�� ~ 350�� |
| Tilt Range | -2�� ~ 90��, auto flip 180�� |
| Night Vision | IR distance up to 30 m |
| Video Compression | H.265 / H.264 / MJPEG |
| Max. Frame Rate | 25/30 fps @ 1080P |
| Audio Interface | 1/1 channel In/Out |
| Memory Card Slot | MicroSD, up to 128 GB |
| Network Interface | 1 RJ-45 (10/100 Base-T) |
| Power Supply | DC12V/PoE (802.3af) |
| Power Consumption | 8 W |
| Operating Conditions | -30��C ~ +60��C / Less than 95% RH |
| Ingress Protection | IP66 |
| Dimensions | ��160 mm x 295 mm |
| Housing | Metal |
