S5720-52X-PWR-LI-AC – HKShanhai Group Limited S5700 Series Switches. S5720-52X-PWR-LI-AC (48 Ethernet 10/100/1000 ports, 4 10 Gig SFP+, PoE+,370W POE AC 110/220V)
Quick Specs
Table 1 shows the Quick Specs.
|
Memory (RAM) |
512 MB |
|
Flash |
240 MB |
|
Mean time between failures (MTBF) |
38 years |
|
Mean time to repair (MTTR) |
2 hours |
|
Availability |
> 0.99999 |
|
Service port surge protection |
Common mode: 7 kV |
|
Power supply surge protection |
6 kV in differential mode, 6 kV in common mode |
|
Dimensions (W x D x H) |
442.0 mm x 310.0 mm x 43.6 mm (17.4 in. x 12.2 in. x 1.72 in.) |
|
Weight (including packaging materials) |
5.9 kg (13.01 lb) |
|
Stack ports |
Forty-eight 10/100/1000BASE-T ports and four 10G SFP+ ports |
|
RTC |
Not supported |
|
RPS |
Supported |
|
PoE |
Supported |
|
Rated voltage range |
100 V AC to 240 V AC, 50/60 Hz |
|
Maximum voltage range |
90 V AC to 264 V AC, 47 Hz to 63 Hz |
|
Maximum power consumption (100% throughput, full speed of fans) |
|
|
Typical power consumption (30% of traffic load)
|
42.2 W |
|
Storage temperature |
-40°C to +70°C (-40F to +158F) |
|
Noise under normal temperature (27°C, sound power) |
less than 48.3 dB |
|
Relative humidity |
5% to 95%, noncondensing |
|
Operating altitude |
0-5000 m (0-16404 ft.) |
Get more information
Do you have any question about the S5720-52X-PWR-LI-AC?
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited S5720-52X-PWR-LI-AC Specification
S5720-52X-PWR-LI-AC Specification |
|
|
Memory (RAM) |
512 MB |
|
Flash |
240 MB |
|
Mean time between failures (MTBF) |
38 years |
|
Mean time to repair (MTTR) |
2 hours |
|
Availability |
> 0.99999 |
|
Service port surge protection |
Common mode: ±7 kV |
|
Power supply surge protection |
±6 kV in differential mode, ±6 kV in common mode |
|
Dimensions (W x D x H) |
442.0 mm x 310.0 mm x 43.6 mm (17.4 in. x 12.2 in. x 1.72 in.) |
|
Weight (including packaging materials) |
5.9 kg (13.01 lb) |
|
Stack ports |
Forty-eight 10/100/1000BASE-T ports and four 10G SFP+ ports |
|
RTC |
Not supported |
|
RPS |
Supported |
|
PoE |
Supported |
|
Rated voltage range |
100 V AC to 240 V AC, 50/60 Hz |
|
Maximum voltage range |
90 V AC to 264 V AC, 47 Hz to 63 Hz |
|
Maximum power consumption (100% throughput, full speed of fans) |
|
|
Typical power consumption (30% of traffic load)
|
42.2 W |
|
Storage temperature |
-40°C to +70°C (-40°F to +158°F) |
|
Noise under normal temperature (27°C, sound power) |
less than 48.3 dB |
|
Relative humidity |
5% to 95%, noncondensing |
|
Operating altitude |
0-5000 m (0-16404 ft.) |
