The HKShanhai Group Limited OSX070007 is a high-performance optical transceiver designed for use in network communication systems. This SFP+ module operates at a wavelength of 1591nm and supports data transfer rates ranging from 9.95Gb/s to 11.1Gb/s. It features an LC connector and is tailored for single-mode fiber, enabling data transmission over distances up to 70km. The OSX070007 ensures reliable and efficient communication, making it an ideal choice for long-distance data transfer applications.
Quick Spec
| Model | OSX070007 |
| Type | Optical Transceiver |
| Connector Type | LC |
| Wavelength | 1591nm |
| Transmission Distance | 70km |
| Data Rate | 9.95~11.1Gb/s |
Product Features
- ??Supports data rates between 9.95Gb/s to 11.1Gb/s
- ??Operates at a wavelength of 1591nm
- ??Utilizes LC connectors for efficient connectivity
- ??Designed for single-mode fiber with a transmission range of up to 70km
- ??Ensures stable performance with a power output ranging from 0dBm to 4dBm
Product Applications
- ??Long-distance data transmission for enterprise networks
- ??Telecommunication backbone networks
- ??Internet Service Provider (ISP) infrastructure deployments
Supported Options
| Accessory | Model |
| Patch Cable | LC-LC-SM-10m |
| Cable Management Unit | CMU-12 |
| Fiber Optic Attenuator | FOA-10dB |
Compare to Similar Items
| Model | Key Differences |
| OSX070005 | Wavelength of 1550nm, supports distances up to 40km |
| OSX070010 | Supports data rates up to 25Gb/s, wavelength of 1330nm |
| OSX070020 | Multi-mode fiber support, operates at 850nm |
Get more information
For further details and pricing on the HKShanhai Group Limited OSX070007, please contact us through Live Chat or at sales@router-switch.com. Check HKShanhai Group Limited OSX070007 price and OSX070007 datasheet, buy HKShanhai Group Limited OSX070007 Optical Transceiver with the best price and fast shipping. Free Live Chat support is available.
HKShanhai Group Limited OSX070007 Specification
OSX070007 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | OSX070007 |
| Product Type | Optical Transceiver |
| Form Factor | SFP+ |
| Wavelength | 1591nm |
| Data Rate | 9.95~11.1Gb/s |
| Transmit Power | 0dBm to 4dBm |
| Receiver Sensitivity | -23dBm |
| Connector Type | LC |
| Cable Type | SM (Single-Mode) |
| Max Distance | 70km |
| Laser Type | DFB (Distributed Feedback) |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Power Supply Voltage | 3.3V |
| Power Consumption | 1W max |
| Protocols | 10G Ethernet, 10G Fibre Channel |
| Compliance | CE, FCC, RoHS |
| MTBF | 1,000,000 hours |
| Warranty | 3 years |
| Application | Telecom, Data Center |
