The HKShanhai Group Limited OSX070003 Optical Transceiver is a reliable SFP+ module designed for high-speed data transmission applications. Operating at wavelengths of 1491nm, it supports data rates ranging from 9.95 to 11.1Gb/s. With an output power range from 0dBm to 4dBm and a receiving sensitivity of -23dBm, it is well-suited for long-haul communication over single-mode fiber up to a distance of 70 kilometers. The LC duplex connector ensures easy integration with existing network systems.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | OSX070003 |
| Transceiver Type | SFP+ |
| Wavelength | 1491nm |
| Data Rate | 9.95 – 11.1Gb/s |
| Transmission Distance | 70km |
Product Features
- ??High transmission data rate: Supports between 9.95 to 11.1Gb/s
- ??Extended reach: Capable of distances up to 70km on single-mode fiber
- ??Wavelength: Operates at 1491nm for optimal performance
- ??High Power Output: Delivers 0dBm to 4dBm
- ??LC Duplex Connector: Easy integration into existing network setups
Product Applications
- ??Long-distance optical communications between data centers
- ??Telecommunications networks requiring high-speed, high-reliability links
- ??Campus networks for extended reach without repeaters
Supported Options
| Accessory | Model |
| Patch Cable | PTC-LC-LC-10M |
| Optical Attenuator | ATT-3DB-SC |
| Transceiver Evaluation Board | EB-TRX-SFP+ |
Compare to Similar Items
| Model | Differences |
| HKShanhai Group Limited XS070002 | Shorter distance of 40km, 1310nm wavelength |
| HKShanhai Group Limited XS070001 | Lower power output of 0dBm maximum |
| HKShanhai Group Limited XS070004 | Wider data rate range, 1495nm wavelength |
Get more information
For further information about the HKShanhai Group Limited OSX070003 and its pricing, please contact us via Live Chat or email at sales@router-switch.com. Check HKShanhai Group Limited OSX070003 price and OSX070003 datasheet, buy HKShanhai Group Limited OSX070003 Optical Transceiver with the best price and fast shipping. Free Live Chat is supported.
HKShanhai Group Limited OSX070003 Specification
OSX070003 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model Number | OSX070003 |
| Product Type | Optical Transceiver |
| Form Factor | SFP+ |
| Transmission Distance | 70 km |
| Wavelength | 1491 nm |
| Data Rate | 9.95 ~ 11.1 Gb/s |
| Transmitter Power | 0 dBm ~ 4 dBm |
| Receiver Sensitivity | -23 dBm |
| Connector Type | LC |
| Fiber Type | Single Mode (SM) |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Power Supply Voltage | 3.3 V |
| Max Voltage | 3.6 V |
| Protocol Standards | IEEE 802.3ae, SFF-8431, SFF-8472 |
| Compatibility | Compatible with various networking equipment for data centers and enterprise infrastructure |
| MTBF | Over 1 million hours |
| Digital Diagnostic Monitoring | Supported |
| Applications | 10G Ethernet, 10G Fiber Channel, SONET, SDH |
| Compliance | RoHS, MSA Compliant |
