The HKShanhai Group Limited OSC120N01 is a high-performance optical transceiver designed to meet the demands of modern networking. Offering eSFP compatibility, this transceiver operates at a wavelength of 1511nm and supports data rates up to 155.52Mbps. With a transmission power range of 0.5~5.0dBm and a sensitivity of -41.0dBm, it is capable of reaching distances up to 150km, making it ideal for long-distance communications. The use of LC connectors further enhances its reliability and performance.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | OSC120N01 |
| Form Factor | eSFP |
| Wavelength | 1511nm |
| Data Rate | 155.52Mbps |
| Transmission Distance | 150km |
Product Features
- High-performance optical transceiver for stable network connectivity.
- Supports eSFP form factor for versatile applications.
- Operates at 1511nm wavelength for optimal performance over long distances.
- Data rate support up to 155.52Mbps, ideal for various data transmission needs.
- Exceptional transmission distance up to 150km, suitable for long-haul communications.
Product Applications
- Long-distance fiber optic communication networks.
- Telecommunication infrastructure in rural and remote areas.
- High-capacity enterprise network backbones and data centers.
Supported Options
| Accessory | Model |
| LC to LC Fiber Patch Cable | HU-LCPC-3M |
| Environmental Protection Cap | EP-CAP |
| 15dB Attenuator | ATT15DB |
Compare to Similar Items
| Model | Primary Difference |
| HKShanhai Group Limited OSC120N02 | Higher data rate of 1.25Gbps |
| HKShanhai Group Limited OSC125N01 | Shorter transmission distance of 80km |
| HKShanhai Group Limited OSC100N01 | Lower sensitivity of -30dBm |
Get more information
For further information about the HKShanhai Group Limited OSC120N01, including pricing and availability, please contact us via Live Chat or email at sales@router-switch.com. Check HKShanhai Group Limited OSC120N01 price and OSC120N01 datasheet, buy HKShanhai Group Limited OSC120N01 with the best price and fast shipping. Free Live Chat is available for support.
HKShanhai Group Limited OSC120N01 Specification
OSC120N01 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | OSC120N01 |
| Type | Optical Transceiver |
| Form Factor | eSFP |
| Wavelength | 1511nm |
| Data Rate | 155.52Mbps |
| Transmit Power | 0.5~5.0dBm |
| Receive Sensitivity | -41.0dBm |
| Connector Type | LC |
| Maximum Reach | 150km |
| Operating Temperature Range | -20°C to 85°C |
| Compatibility | SFP MSA Compliant Equipment |
| Power Supply Voltage | 3.3V |
| Protocol | SDH |
| DDM/DOM Support | Yes |
| Hot Swappable | Yes |
| Laser Safety | Class 1 |
| RoHS Compliant | Yes |
| EMI Standards | FCC Part 15 Class B |
| Warranty | 1 Year |
