The Alcatel-Lucent OS6860E-48 is an advanced enterprise switch engineered for high-performance connectivity and reliable network operations. Featuring 48 high-density RJ45 ports, it serves as a robust backbone for enterprise switch applications and data center deployment, offering seamless scalability and flexibility for mid-to-large-size environments. With comprehensive Layer 3 managed capabilities, this switch ensures efficient data traffic handling, intelligent load balancing, and enhanced security features. Its stackable design supports up to 8 units per stack, allowing for network growth as business demands evolve. The OS6860E-48 is tailored for organizations seeking to maximize data center deployment effectiveness, supporting mission-critical workloads through high switching capacity of 264 Gbps and a forwarding rate of 190.6 Mpps. Built-in redundant power supply options ensure continuous operation and optimal uptime, protecting infrastructure from unexpected outages. The unit supports advanced authentication, encryption, remote management protocols, and routing features, making it suitable for dynamic, secure deployments. As enterprises and integrators adapt to growing demands, the OS6860E-48 delivers agile performance, consistent operation, and streamlined management for a wide range of professional network environments.
Product Highlights
Product Applications Scenarios
Product Features Comparison
| Â |
|
|
|
|
| Model | OS6860E-48 | OS6860E-48D | OS6860-P48 | OS6450-48X |
| Port Configuration | 48 x 10/100/1000Base-T RJ-45, 4 x 10 Gigabit Ethernet SFP+, 1 x Gigabit Ethernet SFP+ | 48 x 10/100/1000 + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ | 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ | 48 x 10/100/1000Base-T + 2 x 1G/10G SFP+ |
| Switching Capacity | 264 Gbps | 264 Gbps | 264 Gbps | n/a |
| Forwarding Rate | 190.6 Mpps | 190.6 Mpps | 190.6 Mpps | n/a |
| PoE Budget | n/a | n/a | 920 W | n/a |
| Stacking Capability | Max 8 units per stack | 8 | Up to 8 units in a stack | 8 |
Optional Add-ons
| Model Number | Description |
| OS6860E-BP | Alcatel-Lucent backup power supply for OS6860E series, enhances redundancy |
| OS6860E-FAN | Cooling fan module for OS6860E series, maintains optimal operating temperatures |
| SFP-GIG-LX | Alcatel-Lucent SFP Gigabit LX transceiver, allows long-range fiber uplink connectivity |
Alcatel-Lucent OS6860E-48 Specification
| Model | OS6860E-48 |
| Brand | Alcatel-Lucent |
| Device Type | Switch – 48 ports – Layer 3 – Managed – Stackable |
| Subtype | Gigabit Ethernet |
| Ports | 48 x 10/100/1000Base-T RJ-45, 4 x 10 Gigabit Ethernet SFP+, 1 x Gigabit Ethernet SFP+ |
| Stacking | Max 8 units per stack |
| Interfaces | 48 x 1000Base-T RJ-45, 2 x QSFP+ for stacking, 1 x USB management, 4 x SFP+, 1 x console management, 1 x serial (RS-232) management |
| Rack Mounting Kit | Included |
| Remote Management Protocols | SNMP v1, SNMP v2, SNMP v2c, SNMP v3, RMON, Telnet, HTTP, HTTPS, TFTP, CLI |
| Authentication Methods | SSH, RADIUS, TACACS+, SSH v2, LDAP, Extensible Authentication Protocol (EAP) |
| Encryption Algorithm | MD5, PKI |
| Routing Protocols | IS-IS, RIP-1, RIP-2, IGMP, IGMPv2, IGMPv3, VRRP, VRRPv2, static IP routing, GRE, PIM-SSM, MLD, MLDv2, Bidirectional Forwarding Detection (BFD), CIDR |
| Performance | Switching capacity: 264 Gbps; Throughput (64-byte packet size): 190.6 Mpps |
| Capacity | IPv4 routes: 64,000; Virtual interfaces (VLANs): 4,000; MAC address table size: 48K entries |
| RAM | 2 GB |
| Flash Memory | 2 GB |
| Jumbo Frame Support | 9216 bytes |
| Status Indicators | Power, Status, RPS (Redundant Power Supply), Link/Activity |
| Features | Flow control, BOOTP support, ARP support, load balancing, VLAN support, IGMP snooping, Syslog support, port mirroring, DiffServ support, IPv6 support, deep inspection, Dying Gasp support, Spanning Tree Protocol (STP), Rapid Spanning Tree Protocol |
| Power Device | Internal power supply, hot-plug |
| Power Consumption | 60 W (operational) |
| Power Redundancy | Optional, 1+1 with optional power supply |
| Cables Included | 1 x micro-USB to USB adapter |
| Installed Size | 1 unit |
| Max Supported Qty | 2 units |
| MTBF | 336,101 hours |
| Enclosure Type | Front to back airflow, rack-mountable, 1U |
| Dimensions (W x D x H) | 44 cm x 35 cm x 4.4 cm |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 85 °C |
| Humidity Range Operating | 5% to 95% (non-condensing) |
| Humidity Range Storage | 5% to 95% (non-condensing) |
| Voltage Required | AC 120/230 V |
| Compliant Standards | BSMI, EN 61000-3-2, EN55022, GS, EN 61000-3-3, EN55024, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, CCC, EN 61000-4-5, EN 61000-4-11, RoHS, EN 61000-4-8, UL 60950-1, IEC 60950-1, KCC, WEEE, FCC CFR47, ANATEL, UL-AR, EN 60825-1, AS/NZS 3548 Clause |
| Version | Original |
| OS6860E-48 | OS6860E-48 |
