OS6855-P14, Alcatel-Lucent OS6855 Switch, 12x1G PoE RJ-45/2x1G SFP/Fanless

The Alcatel-Lucent OS6855-P14 is an enterprise-grade switch engineered for robust Layer 3 managed environments. As a leading Alcatel-Lucent switch, it is specifically crafted to deliver high-efficiency connectivity across enterprise, transportation, and industrial networking demands. Featuring 12 versatile 10/100/1000 ports with strong Gigabit Ethernet capability, it provides excellent throughput for modern applications. Its intelligent fanless design ensures completely silent operation, making it optimal for noise-sensitive deployments such as offices, security installations, and high-density equipment rooms. With comprehensive Power over Ethernet (PoE) support, the OS6855-P14 can seamlessly power connected devices such as IP phones, surveillance cameras, and wireless access points, simplifying infrastructure and reducing operational costs. PoE optimizes the deployment flexibility required in converged edge and access networks. The switch supports advanced network protocols, VLAN, DHCP server capability, and management through SNMP and SSH, offering secure and granular control suitable for distributed IT environments. Designed for challenging conditions, it operates reliably in extreme temperatures from -40°C to 70°C and tolerates high humidity, broadening its applicability across varied climates in Asia, Europe, Africa, and North America. Whether for distributors, SMB integrators, or end users demanding reliable, scalable gigabit switching, the Alcatel-Lucent OS6855-P14 combines energy efficiency, security, and resilience, making it a future-proof choice for growing business networks.

Product Highlights

12 PoE

PoE+ Ports

Fanless

Silent Design

-40~70°C

Wide Temp.

Product Applications Scenarios

Enterprise Network

Multiple PoE ports with Gigabit Ethernet ensure high network availability and streamline power for pivotal business devices, minimizing infrastructure complexity and operating expenses.

Edge & IoT

Fanless design and extended temperature range allow use in industrial IoT and edge locations, improving reliability for sensors and smart endpoints in demanding climates.

Public Infrastructure

Delivers silent, robust connectivity for surveillance, transportation, or campus deployments, powering vital PoE devices and reducing downtime in high-demand public settings.

Product Features Comparison


Model	OS6855-P14	C9300L-24UXG-4X-A	Arista CCS-720XP-48Y6-F	C9300-48UXM-E
Brand	Alcatel-Lucent	Cisco	Arista	Cisco
Port Configuration	12 x 10/100/1000 (PoE) + 2 x SFP (mini-GBIC)	48 PoE+ 12xmGig	48 x 10/100/1000 Mbps Ethernet PoE RJ-45 (802.3af/at, up to 30W per port), 6 x 25 Gbps SFP28	48
Switching Capacity	n/a	392 Gbps	198 Gbps (396 Gbps FDX Throughput)	480 Gbps
Forwarding Rate	n/a	291.66 Mpps	294 Mpps	360 Mpps
PoE Budget	Yes	675W	982W (with 1 x 1050W AC PSU), 1850W (with 2 x 1050W AC PSU), 1110W (with dual 650W AC), 857W (with dual 500W DC)	n/a
Stacking Capability	n/a	StackWise-320	n/a	n/a

Optional Add-ons

Model Number	Description
SFP-GIG-LX	Alcatel-Lucent Gigabit SFP LX Module for extended optical connections
PS-AC-OS6855	Original Alcatel-Lucent AC Power Supply Unit for OS6855 Series Switch
RCKMT-6855	Alcatel-Lucent Rack Mount Kit for OS6855 Series installation

Alcatel-Lucent OS6855-P14 Specification

Model	OS6855-P14
Brand	Alcatel-Lucent
Device Type	Switch – 12 ports – Layer 3 – Managed
Enclosure Type	Rack-mountable 1U
Ports	12 x 10/100/1000 (PoE) + 2 x SFP (mini-GBIC)
Interfaces	12 x 1000Base-T RJ-45 PoE, 2 x SFP (mini-GBIC)
Power over Ethernet (PoE)	Yes
Power Device	Internal power supply
Power Consumption	30 Wh operational
Voltage Required	AC 120/230 V (50/60 Hz)
Compliant Standards	IEEE 802.1D, 802.1Q, 802.3ab, 802.1p, 802.3af, 802.3ad (LACP), 802.1w, 802.1x, 802.3ae, 802.3ac, 802.1s, 802.1z
Subtype	Gigabit Ethernet
Features	DHCP support, MDI/MDI-X switch, auto-negotiation, BOOTP support, VLAN support, port mirroring, manageable, Broadcast Storm Control, IPv6 support, software flow control, Quality of Service (QoS), SSH support, DHCP server, static IP mode, fanless
Remote Management Protocol	SNMP 1, SNMP 2, SNMP 3, RMON 1/2/3/9, HTTPS, SSH
Routing Protocols	RIP-2, SAP, IGMPv2, IGMP, DVMRP, OSPFv2, PIM-SM, static IP routing, PIM-DM, IGMPv3, RIPng
Status Indicators	Power, link/activity
Installed Size	1
Rack Mounting Kit	Included
Dimensions (W x H x D)	21.6 cm x 26 cm x 4.4 cm
Version	Original
Operating Temperature	-40°C to 70°C
Storage Temperature	-40°C to 85°C
Operating Humidity	0 – 95% (non-condensing)
Storage Humidity	0 – 95% (non-condensing)
