The Alcatel-Lucent OS6855-14D is an enterprise-class switch tailored for demanding industrial and rugged Ethernet deployments. As part of Alcatel-Lucent’s robust networking portfolio, the OS6855-14D addresses the stringent requirements of enterprise networks operating in harsh conditions. Its managed capabilities, rack-mountable 1U footprint, and advanced security mechanisms—including multifactor authentication and encryption algorithms—make it a standout among industrial switches. Engineered with rugged Ethernet connectivity in mind, it is especially suitable for mission-critical environments where resilient infrastructure is necessary. The device provides not only flexible port options with a blend of copper and optical SFP slots but also supports Ethernet optical transceivers for uplink and extended transmission. Its comprehensive QoS, VLAN, DHCP, and IPv6-ready software stack cater to complex enterprise architectures, delivering optimized traffic management and integrity for digital operations. The OS6855-14D enhances network longevity and stability, demonstrated by its compliance with multiple international standards such as MIL-STD 810F and UL 60950. Whether deployed in factories, transport hubs, or modern corporate facilities, this switch seamlessly integrates industrial switches, rugged Ethernet design, enterprise networks scalability, and support for Ethernet optical transceivers—delivering secure, high-availability switching for global business needs.
Product Highlights
Product Applications Scenarios
Product Features Comparison
|
|
|
|
|
|
| Model | OS6855-14D | C9300-24UB-E | OS6900-X20D-R | R8Q67A |
| Port Configuration | 12 x 10/100/1000 + 2 x SFP | 24 Cisco UPOE | 20 x 1/10GbE SFP+ | 24x 10/100/1000BASE-T, 4x 1G/10G SFP |
| Switching Capacity | n/a | 208 Gbps | 640 Gbps | 128 Gbps |
| Forwarding Rate | n/a | 154.76 Mpps | 480 Mpps | 95.2 Mpps |
| PoE Budget | n/a | 830W | n/a | n/a |
| Stacking Capability | n/a | 480 Gbps Stacking BW | Stackable | Up to 8 members |
Optional Add-ons
| Model Number | Description |
| 3HE04823AAAA | Alcatel-Lucent SFP 1000Base-LX optical transceiver for OS6855 Series |
| 3HE04821AAAA | Alcatel-Lucent SFP 1000Base-SX optical module, ideal for short-range connections |
| 3HE04830AAAA | Alcatel-Lucent power supply spare unit for OS6855 series industrial switches |
Alcatel-Lucent OS6855-14D Specification
| Model | OS6855-14D |
| Brand | Alcatel-Lucent |
| Device Type | Switch – 12 ports – Managed |
| Enclosure Type | Rack-mountable 1U |
| Ports | 12 x 10/100/1000 + 2 x SFP |
| Interfaces | 12 x 1000Base-T RJ-45, 2 x SFP (mini-GBIC) |
| Subtype | Gigabit Ethernet |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+, LDAP |
| Encryption Algorithm | MD5, PKI |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, HTTPS, SSH |
| Routing Protocol | RIP-2, SAP, IGMPv2, IGMP, DVMRP, OSPFv2, PIM-SM, static IP routing, PIM-DM, IGMPv3, RIPng |
| Features | DHCP support, MDI/MDI-X switch, auto-negotiation, BOOTP support, VLAN support, port mirroring, manageable, Broadcast Storm Control, IPv6 support, software flow control, Quality of Service (QoS), SSH support, DHCP server, static IP mode |
| Status Indicators | Power, link/activity |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Installed Size | 1 |
| Compliant Standards | MIL-STD 810F, MIL-STD 901D, EN 61000-3-2, IEC 61000-4-3, NOM, EN 61000-3-3, UL 60950, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 61000-4-8, UL 60950-1, CSA C22.2 No. 60950-1-03, UL-AR |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 5 – 90% |
| Height | 26 cm |
| Width | 21.6 cm |
| Depth | 4.4 cm |
| Version | Original |
| OS6855-14D | OS6855-14D |
