The Alcatel-Lucent OS10K-XNI-U16L is a high-performance network interface card designed to enhance the capabilities of your networking infrastructure. This robust card includes 8 unpopulated 10G SFP+ ports and 8 unpopulated 1G SFP+ ports, with the option to upgrade 1G ports to 10G via a simple license upgrade. Its versatility and advanced support for L2, L3, and ACL policies make it a reliable choice for handling complex networking tasks. Additionally, it is MPLS ready, making it a future-proof solution for scalable network environments.
Quick Spec
| Brand | Alcatel-Lucent |
| Model | OS10K-XNI-U16L |
| 10G SFP+ Ports | 8 (unpopulated) |
| 1G SFP+ Ports | 8 (unpopulated, upgradeable to 10G) |
| MPLS Support | Yes |
Product Features
- 8 unpopulated 10G SFP+ ports for high-speed connectivity.
- 8 unpopulated 1G SFP+ ports, upgradeable to 10G through a license.
- Supports standard tables for Layer 2 (L2) and Layer 3 (L3).
- Advanced support for Access Control Lists (ACL) policies.
- MPLS ready for future-proof scalable networking.
Product Applications
- Data centers requiring high-speed 10G connectivity and scalability.
- Corporate networks in need of upgradable port speeds and advanced security policies.
- Service providers looking to implement MPLS for large-scale, versatile network solutions.
Supported Options
| Accessory | Model |
| 10G SFP+ Transceiver | SFP-10G-SR |
| 1G SFP Transceiver | SFP-1G-LX |
| License Upgrade for 1G to 10G | UPG-1G-10G-LIC |
Compare to Similar Items
| Model | Difference |
| OS10K-XNI-U8L | Includes 4 unpopulated 10G SFP+ ports, 4 unpopulated 1G SFP+ ports |
| OS6K-XNI-U16L | Designed for smaller networks; includes fewer ports |
| OS10K-XNI-U32L | Includes 16 unpopulated 10G SFP+ ports, 16 unpopulated 1G SFP+ ports |
Get more information
Check Alcatel-Lucent OS10K-XNI-U16L price and OS10K-XNI-U16L datasheet, buy Alcatel-Lucent OS10K Series with best price and fast shipping. Free Live Chat are supported. Contact us through Live Chat or sales@router-switch.com for further information about the product and its price.
Alcatel-Lucent OS10K-XNI-U16L Specification
OS10K-XNI-U16L Specifications |
|
| Brand | Alcatel-Lucent |
| Model | OS10K-XNI-U16L |
| Port Configurations | 8 unpopulated 10G SFP+ ports, 8 unpopulated 1G SFP+ ports |
| Upgradeable Ports | 1G ports can be updated to 10G through license upgrade |
| Layer 2 Support | Yes, supports standard tables for L2 |
| Layer 3 Support | Yes, supports standard tables for L3 |
| ACL Policies | Supports standard ACL policies |
| MPLS Ready | Yes |
| Form Factor | Plug-in module |
| Operating Temperature | 0 C to 45 C |
| Storage Temperature | -40 C to 70 C |
| Power Consumption | Typical: 30W, Maximum: 50W |
| Dimensions (HxWxD) | 30 x 200 x 300 mm |
| Compliance | CE, RoHS, WEEE |
| MTBF | 1,000,000 hours |
| Warranty | 1 year |
| Management | CLI, SNMP, RMON |
| Layer 2 Switching | 802.1Q VLAN, STP, RSTP, MSTP |
| Layer 3 Routing | OSPF, BGP, RIP |
| Security | Port security, SSH, SSL |
