The Alcatel-Lucent OS-XNI-U12E is a high-performance optional module designed for the OS6900 series of switches. It is equipped with 12 SFP+ ports supporting both 1Gig and 10Gig Ethernet speeds, as well as 2Gig/4Gig/8Gig Fibre Channel (FC) speeds. This module is ideal for expanding the capability of your OS6900 series switch, ensuring seamless connectivity and superior network performance. Note that the OS6900-SW-DC license is required for utilizing the ports in FC mode.
Quick Spec
| Brand | Alcatel-Lucent |
| Product Name | OS-XNI-U12E |
| Compatibility | OS6900 series switches |
| Port Speed | 1Gig/10Gig Ethernet, 2Gig/4Gig/8Gig FC |
| Number of Ports | 12 SFP+ |
| Licensing Requirement | OS6900-SW-DC license for FC mode |
Product Features
- Supports both Ethernet and Fibre Channel speeds.
- Equipped with 12 versatile SFP+ ports.
- Seamless integration with OS6900 series switches.
- High performance and low latency.
- Requires OS6900-SW-DC license for FC mode operation.
Product Applications
- Data centers requiring high-speed Ethernet or Fibre Channel connectivity.
- Enterprise networks looking to enhance their existing OS6900 series switch capabilities.
- Scenarios where mixed Ethernet and Fibre Channel environments are present.
Supported Options
| Accessory | Model |
| SFP+ Copper Module | OS-XNI-SFP+ |
| 10GBASE-SR SFP Module | OS-10G-SR |
| FC 8G Short Range SFP+ Module | OS-FC-8G-SR |
Compare to Similar Items
| Feature | Alcatel-Lucent OS-XNI-U12E | Model A | Model B |
| Part Number | OS-XNI-U12E | Model A-OSX12 | Model B-OSX8 |
| Port Type | SFP+ | SFP | SFP+ |
| Port Speed | 1Gig/10Gig Ethernet, 2Gig/4Gig/8Gig FC | 1Gig/10Gig Ethernet | 1Gig/10Gig Ethernet, 2Gig FC |
| Number of Ports | 12 | 8 | 12 |
| Licensing Requirement | OS6900-SW-DC for FC mode | None needed | FC license required |
Get more information
For further details about the Alcatel-Lucent OS-XNI-U12E, please contact us through Live Chat or sales@router-switch.com. Check Alcatel-Lucent OS-XNI-U12E price and OS-XNI-U12E datasheet, buy Alcatel-Lucent OS-XNI-U12E OS6900 Series with the best price and fast shipping. Free Live Chat support is available.
Alcatel-Lucent OS-XNI-U12E Specification
OS-XNI-U12E Specifications |
|
| Brand | Alcatel-Lucent |
| Model | OS-XNI-U12E |
| Compatible Series | OS6900 series |
| Port Type | SFP+ |
| Number of Ports | 12 |
| Ethernet Speed | 1Gig/10Gig |
| Fibre Channel Speed | 2Gig/4Gig/8Gig |
| License Requirement | OS6900-SW-DC required for FC mode |
| Supported Ethernet Standards | IEEE 802.3, IEEE 802.3ae |
| Power Consumption | Varies with configuration |
| Operating Temperature | 0C to 50C (32F to 122F) |
| Storage Temperature | -20C to 70C (-4F to 158F) |
| Humidity | 10% to 90% non-condensing |
| Dimensions | Plug-in module |
| MTBF | 1,200,000 hours |
| Compliance | RoHS, CE |
| Management | Web, SNMP |
| Performance | Line rate on all ports |
| Cooling | Fan module required |
| Warranty | 1 year limited warranty |
