NVR4816-16P-4KS2, Dahua 16 Channel 2U 16PoE 4K&H.265 Lite Network Video Recorder, Smart H.265+/H.265/Smart H.264+/H.264; Max 200Mbps Incoming Bandwidth; Up to 8MP Resolution for Preview and Playback.
Quick Specs
Table 1 shows the Quick Specs.
|
Product Code |
NVR4816-16P-4KS2 |
|
Main Processor |
Quad-core embedded processor |
|
Operating System |
Embedded LINUX |
|
IP Camera Input |
16Channel |
|
Two-way Talk |
1 Channel Input, 1 Channel Output, RCA |
|
Interface |
1 HDMI, 1 VGA |
|
Resolution
|
HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 |
|
VGA: 1920×1080, 1280×1024, 1280×720 |
|
|
Decoding Capability |
2ch@4K 30fps, 8ch@1080P 30fps |
|
Multi-screen Display |
1/4/8/9/16 |
|
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
|
Dimensions |
2U, 440mmx 450.1mmx 95mm(17.3″ x 17.7″ x3.7″) |
Product Details
TheDahua NVR4816-16P-4KS2 provides these features:
* Smart H.265+/H.265/Smart H.264+/H.264
* Max 200Mbps Incoming Bandwidth
* Up to 8MP Resolution for Preview and Playback
* Up to 2ch@4K/8ch@1080P decoding
* HDMI/VGA simultaneous video output
* Support IPC UPnP, 16PoE ports
Compare to Similar Items
Table 2shows the comparison.
|
Product Code |
NVR4816-16P-4KS2 |
||
|
Main Processor |
Quad-core embedded processor |
Quad-core embedded processor |
Quad-core embedded processor |
|
Operating System |
Embedded LINUX |
Embedded LINUX |
Embedded LINUX |
|
IP Camera Input |
16Channel |
16Channel |
16Channel |
|
Two-way Talk |
1 Channel Input, 1 Channel Output, RCA |
1 Channel Input, 1 Channel Output, RCA |
1 Channel Input, 1 Channel Output, RCA |
|
OSD |
Camera title, Time, Camera lock, Motion detection, Recording |
Camera title, Time, Camera lock, Motion detection, Recording |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
|
Interface |
1 RJ-45 Port(10/100/1000Mbps) |
2 RJ-45 Ports |
1 RJ-45 Port(10/100/1000Mbps) |
|
PoE |
16 ports (IEEE802.3af/at) |
N/A |
16 ports (IEEE802.3af/at) |
|
Internal HDD |
4 SATA III Ports, Up to 6 TB capacity for each HDD |
8 SATA III Ports, Up to 6 TB capacity for each HDD |
8 SATA III Ports, Up to 6 TB capacity for each HDD |
|
USB |
2 ports(1 USB2.0, 1 USB3.0) |
3 ports(2 USB2.0, 1 USB3.0) |
2 ports(1 USB2.0, 1 USB3.0) |
|
Power Consumption |
NVR: PoE: Max 25.5w for single port, 150w in total |
NVR: PoE: Max 25.5w for single port, 150w in total |
|
|
Dimensions |
1.5U, 440mmx 411.1mmx 76mm(17.3″ x 16.2″ x 3.0″) |
2U, 440mmx 450.1mmx 95mm(17.3″ x 17.7″ x3.7″) |
2U, 440mmx 450.1mmx 95mm(17.3″ x 17.7″ x3.7″) |
GetMoreInformation
Do you have anyquestionabouttheNVR4816-16P-4KS2
Contact us now via Live Chat or sales@router-switch.com.
Dahua NVR4816-16P-4KS2 Specification
NVR4816-16P-4KS2 Specification |
|
|
System |
|
|
Main Processor |
Quad-core embedded processor |
|
Operating System |
Embedded LINUX |
|
Audio and Video |
|
|
IP Camera Input |
16Â Channel |
|
Two-way Talk |
1 Channel Input, 1 Channel Output, RCA |
|
Display |
|
|
Interface |
1 HDMI, 1 VGA |
|
Resolution |
HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 |
|
VGA: 1920×1080, 1280×1024, 1280×720 |
|
|
Decoding Capability |
2ch@4K 30fps, 8ch@1080P 30fps |
|
Multi-screen Display |
1/4/8/9/16 |
|
OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
|
Recording |
|
|
Compression |
Smart H.265+/H.265/Smart H.264+/H.264 |
|
Resolution |
8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc. |
|
Recorde Rate |
200Mbps |
|
Bit Rate |
16Kbps ~ 20Mbps Per Channel |
|
Record Mode |
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop |
|
Record Interval |
1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
|
Video Detection and Alarm |
|
|
Trigger Events |
Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips |
|
Video Detection |
Motion Detection, MD Zones: 396 (22 x 18), Video Loss and Tampering |
|
Alarm input |
16Â Channel |
|
Relay Output |
4Â Channel |
|
Playback and Backup |
|
|
Playback |
1/4/9/16 |
|
Search Mode |
Time /Date, MD and Exact Search(accurate to second), Smart search |
|
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom |
|
Backup Mode |
USB Device/Network |
|
Third-party Support |
|
|
Third-party Support |
Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more |
|
Network |
|
|
Interface |
1 RJ-45 Port(10/100/1000Mbps) |
|
PoE |
16 ports (IEEE802.3af/at) |
|
Network Function  |
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, SNMP, IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4ip |
|
Max. User Access |
128 users |
|
Smart Phone |
iPhone, iPad, Android |
|
Interoperability |
ONVIF 2.4, SDK, CGI |
|
Storage |
|
|
Internal HDD |
8 SATA III Ports, Up to 6 TB capacity for each HDD |
|
HDD Mode |
Single |
|
Auxiliary Interface |
|
|
USB |
2 ports(1 USB2.0, 1 USB3.0) |
|
RS232 |
1 Port, for PC Communication and Keyboard |
|
RS485 |
1 Port, for PTZ Control |
|
Electrical |
|
|
Power Supply |
AC100V ~ 240V, 50 ~ 60 Hz |
|
Power Consumption |
NVR: <13.7W (Without HDD) |
|
PoE: Max 25.5w for single port, 150w in total |
|
|
Environmental |
|
|
Operating Conditions |
-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
|
Storage Conditions |
-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH |
|
Construction |
|
|
Dimensions |
2U, 440mm x 450.1mm x 95mm(17.3″ x 17.7″ x3.7″) |
|
Certifications |
|
|
CE |
EN55032, EN55024, EN50130-4, EN60950-1 |
|
FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
|
UL |
UL60950-1 |
