The Hikvision NS-0105P-35(B) is a 4 Port Fast Ethernet Unmanaged POE Switch designed for small to medium-sized networks. With its Power over Ethernet (POE) capabilities, it simplifies the installation of IP cameras, wireless access points, and other IP-based devices by providing both power and data over a single Ethernet cable. This switch is perfect for expanding your network with minimal effort and maximum efficiency.
Quick Spec
| Brand | Hikvision |
| Model | NS-0105P-35(B) |
| Ports | 4 Fast Ethernet Ports |
| Type | Unmanaged POE Switch |
| Power Supply | Built-in 35W POE |
Product Features
- 4 Fast Ethernet ports with POE support
- Unmanaged switch, plug-and-play setup
- Reliable power supply with built-in 35W POE
- Automatic detection and protection against POE equipment damage
- Compact design suitable for various installation environments
Product Applications
- Installation of IP cameras for surveillance systems
- Deployment of wireless access points in office or retail environments
- Connecting IP phones for efficient communication networks
Supported Options
| Power Supply | PS-12V35W |
| Mounting Kit | MK-NS-01 |
| Cable Management Accessory | CMA-01 |
Compare to Similar Items
| Model | Ports | POE Budget |
| Hikvision DS-3E1105P-EI | 5 Fast Ethernet Ports | 57W |
| Hikvision DS-3E0105P-E/M | 5 Fast Ethernet Ports | 65W |
| Hikvision DS-3E0526P-E/C | 24 Fast Ethernet Ports + 2 Gigabit Uplinks | 370W |
Get more information
Check ‘Hikvision NS-0105P-35(B)’ price and ‘NS-0105P-35(B) datasheet, buy ‘Hikvision NS-0105P-35(B)’ with best price and fast shipping. Free Live Chat are supported. For further information about the product and its price, contact us through Live Chat or at sales@router-switch.com.
Hikvision NS-0105P-35(B) Specification
NS-0105P-35(B) Specifications |
|
| Brand | Hikvision |
| Model | NS-0105P-35(B) |
| Port Type | Fast Ethernet |
| Total Ports | 5 |
| PoE Ports | 4 |
| PoE Standard | IEEE 802.3af |
| Switch Type | Unmanaged |
| Switching Capacity | 1 Gbps |
| MAC Address Table | 2K |
| Forwarding Rate | 148,800 pps |
| Transmission Method | Store-and-Forward |
| Power Supply | External, 48V DC |
| Total PoE Power Budget | 35W |
| Operating Temperature | -10��C to 55��C |
| Storage Temperature | -40��C to 70��C |
| Operating Humidity | 10% to 90% RH non-condensing |
| Storage Humidity | 5% to 90% RH non-condensing |
| Dimensions (L x W x H) | 135 x 83.1 x 27.6 mm |
| LED Indicators | Power, PoE |
| Surge Protection | 6kV |
| Certifications | CE, FCC, RoHS |
