> Equipped with starlight CMOS image sensor, it can achieve 30 times optical zoom, the resolution up to 1920 x 1080, perfect display of low illumination environment
> Low bit stream transmission, more resource saving
> Support WDR, combined with 3D DNR, perfect day / night image display
> Built in lithium battery, the usage up to 9 hours
> Flexible network, support through wired, 3G/4G and WiFi access network, adapt to a variety of network platform monitoring system
> Built in WiFi and Bluetooth module, support WiFiAP
> Built-in GPS module, an external GPS antenna is optional
> With OLED small screen, it can display the working state of the device in real time
> Dual TF card for local storage
> IR distance up to 100 meters
> Support lens heating and fog removal
> Magnetic composite sucker design, simple deployment, equipped professional draw-bar box, optional with tripods, which is easy to move
Dahua MSB-L200 Specification
| Model | ASI7214Y-V3 |
| Brand | Dahua |
| Type | Access Control |
| User Capacity | 100,000 |
| Fingerprint Capacity | 10,000 |
| Card Capacity | 50,000 |
| Face Capacity | 6,000 |
| Event Capacity | 150,000 |
| Communication Mode | TCP/IP, Wi-Fi |
| Display | 4.3-inch TFT Screen |
| Power Supply | 12V DC, 2A |
| Working Temperature | -10°C to +55°C |
| Dimensions | 201.5 mm Ă— 195 mm Ă— 22.8 mm |
| Weight | — Removed — |
|
Storage |
|
|
Micro SD |
2 Micro SD, plug-in card designed,plug and play,up to 256GB for each |
|
Network |
|
|
4G |
Dual 4G module, support load balancing, built-in antenna |
|
SIM card |
2 SIM ports |
|
Wired network |
Support 10/100M network audio and video transmission |
|
WIFI |
Support 2.4G and 5G dual settting, support 802.11b/g/n/ac to set AP, using smart phone or pad to directly access operations |
|
GPS |
Built-in GPS module, can connect external GPS antenna |
|
Bluetooth |
Bluetooth headphone voice pair |
|
External interface |
|
|
14-core aviation connector |
1.Network cable:RJ45. 2.Φ5.5*2.1mm power port 3.GPS port 4.RS232 |
|
8-core aviation connector(optional) |
1.alarm input 2.audio input 3.12V controllable power(alarm) input 4.RS485 |
|
Battery |
|
|
Battery temperature |
charge??/span>0??/span>~45??/span> discharge??/span>-20??/span>~60??/span> |
|
Battery capacity |
10.05Ah/109.45Wh |
|
Battery working time |
9 hours ??/span>lowest power consumption??/span> |
|
Detachable |
support |
|
Camera |
|
|
Image sensor |
1/1.9 CMOS |
|
Resolution |
About 2MP |
|
Horizontal resolution |
??000TVL |
|
Maximum Image Size |
1920Ă—1080 |
|
Minimum illumination |
Color: 0.004Lux@F1.6 ; Black&White:0.0004Lux@F1.6 |
|
Gain control |
Auto/Manual |
|
3D DNR |
Support |
|
2D DNR |
Support |
|
S/N Ratio |
??4dB |
|
White Balance |
Auto/ Manual/ Indoor/ Outdoor/ Daylight lamp/ Sodium lamp |
|
Shutter Time |
1/1 ~ 1/30000s |
|
Anti Shake DSP |
Support |
|
DEFOG |
Support |
|
BLC |
Support |
|
WDR |
120dB |
|
HLC |
Support |
|
Digital Zoom |
16X |
|
Day & Night |
Auto ICR optical filter color to black |
|
Focus Mode |
Auto/ Semiautomatic/ Manual |
|
Focal length |
6mm ~ 180mm |
|
Zoom Speed |
about 3.5s |
|
Field angle |
Horizontal:61.2? ~2.32?( wide-to-tele) |
|
Angle of View |
100mm~1500mm (wide-to-tele) |
|
Optical zoom |
30X |
|
PTZ control |
|
|
Fill-in light |
IR |
|
Fill light control |
on/off |
|
Fill light distance |
100m |
|
Lens defrost |
Support |
|
Horizontal range |
0° ~ 360° |
|
Vertical range |
-20° ~ 90° |
|
Manual control speed |
Horizontal:0.1° ~ 90°/s Vertical:0.1° ~ 90°/s” |
|
Preset speed |
Horizontal:0.1° ~ 100°/s Vertical:0.1° ~ 90°/s” |
|
Location accuracy |
±0.15° |
|
Preset |
255 |
|
Tour |
8 , each can add 32 presets |
|
Pattern |
5 |
|
Auto scan |
4 |
|
Idle motion |
Support |
|
Timing task |
Support |
|
Information display |
Support |
|
Main stream |
50Hz:50fps(1920Ă—1080) , 25fps(1280Ă—960) , 25fps(1280Ă—720) 60Hz:60fps(1920Ă—1080) , 30fps(1280Ă—960) , 30fps(1280Ă—720)” |
|
Sub stream |
50Hz:25fps(704Ă—576) , 25fps(352Ă—288) |
|
Third stream |
50Hz:25fps(1920Ă—1080), 25fps(1280Ă—960) , 25fps(1280Ă—720) , 25fps(704Ă—576) , 25fps(352Ă—288) |
|
Video compression |
H.265/H.264 |
|
Audio compression |
PCM/G.711a/G.711u |
|
Accessory |
|
|
Accessory (order separately) |
battery charging base, tripod, micro SD card |
|
General |
|
|
Power supply |
DC 24V??/span>6V – 36V??/span> |
|
Power consumption |
<20W(IR off<24W, IR on<40W , Motor IR on <56W) |
|
Working environment |
Temperature ??/span>-20 ~ 55??/span> |
|
Protection level |
IP66, surge protection and lightning protection GB/T17626.5-2008, ESD 17626.2??006 |
|
Dimension |
height:280mm diameter:170.5mm |
|
Weight |
4.87kg |
