The Dahua HCVR8816S-URH-S3 is a robust 16 Channel Quadri-brid Digital Video Recorder designed to deliver exceptional 1080P Ultra HD video quality. This high-performance 2U DVR integrates seamlessly with various camera types, making it an ideal solution for diverse surveillance needs.
Quick Spec
| Brand | Dahua |
| Model | HCVR8816S-URH-S3 |
| Channel | 16 |
| Resolution | 1080P Ultra HD |
| Form Factor | 2U |
Product Features
- Supports HDCVI/AHD/TVI/CVBS/IP video inputs
- Smart H.264+ video compression reduces bandwidth and storage requirements
- Long distance real-time transmission over coaxial cable
- Advanced motion detection and smart search functionality
- Remote viewing through mobile apps and web interface
Product Applications
- Retail stores – Monitor various sections of the store to prevent theft and manage operations efficiently
- Office buildings – Ensure safety and security with comprehensive surveillance of entrances and key areas
- Warehouses – Enhance security through continuous monitoring of large storage facilities
Supported Options
| Remote Control | RC-PLUS |
| Hard Drive | 2TB Seagate ST2000VX008 |
| Alarm Box | DHI-ASC1204B-S |
Compare to Similar Items
| Model | Differences |
| Dahua XVR5216AN-S2 | Lower resolution (720P), fewer features, smaller form factor (1U) |
| Dahua HCVR7216A-S2 | Different video compression (H.264), no support for TVI inputs |
| Dahua HCVR8816S-S3 | Supports fewer HDD, lacks ultra-low bit rate feature |
Get more information
For further details about the Dahua HCVR8816S-URH-S3 and its price, please contact us through Live Chat or email us at sales@router-switch.com.
Dahua HCVR8816S-URH-S3 Specification
HCVR8816S-URH-S3 Specifications |
|
| Brand | Dahua |
| Model | HCVR8816S-URH-S3 |
| Channels | 16 |
| Video Format | Quadri-brid (supports HDCVI, AHD, TVI, and CVBS) |
| Resolution | 1080P-Ultra |
| Compression | H.264 |
| Video Input | BNC ports |
| Audio Input/Output | 16/1 |
| Recording Mode | Manual, Schedule, Motion Detection, Alarm |
| Playback Channels | 16 channels synchronous playback |
| Backup | USB, Network, eSATA |
| Network Interface | 1 RJ45 10/100/1000 Mbps Ethernet port |
| USB Ports | 3 ports (2 USB 2.0, 1 USB 3.0) |
| RS232 | 1 port for PC communication and keyboard |
| RS485 | 1 port for PTZ control |
| Alarm In/Out | 16/6 |
| Storage | Supports up to 8 SATA HDDs, up to 6TB capacity for each HDD |
| Power Supply | AC 100-240V, 50-60Hz |
| Power Consumption | 25W (without HDD) |
| Operating Temperature | -10C to +55C |
| Dimensions | 2U, 440mm x 455mm x 95mm |
| Net Weight | 8.2 kg (without HDD) |
Reviews
There are no reviews yet.
