The HKShanhai Group Limited DWDM-SFPGE-1546-92 is a high-performance DWDM Optical Transceiver designed for long-distance data transmission. As an enhanced Small Form-factor Pluggable (eSFP) module, it supports a data rate of 2.5G and utilizes a single-mode fiber optic cable. It operates at a wavelength of 1546.92nm and can cover distances up to 120km, making it ideal for use in metropolitan and long-haul networks. The module also features an LC interface for easy connectivity.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1546-92 |
| Data Rate | 2.5G |
| Wavelength | 1546.92nm |
| Distance | 120km |
| Connector Type | LC |
Product Features
- ??Supports a data rate of 2.5G for high-speed transmissions
- ??DWDM technology enables multiple signal transmission over a single fiber
- ??Extends coverage up to 120km, suitable for long-distance communication
- ??Operates at a wavelength of 1546.92nm for optimized performance
- ??Compact eSFP form factor for easy installation and replacement
Product Applications
- ??Metropolitan Area Networks (MAN): Ideal for data exchanges between data centers in a metropolitan area
- ??Long-Haul Communications: Suitable for telecommunications over long distances without the need for signal regeneration
- ??Enterprise Networks: Ensures reliable and high-speed data transmission across large enterprise campuses
Supported Options
| Accessory | Model |
| Optical Fiber Cable | HKShanhai Group Limited OFC-120KM |
| Patch Panel | HKShanhai Group Limited PP-48LC |
| Transceiver Module Case | HKShanhai Group Limited TMC-SFP |
Compare to Similar Items
| Model | Difference |
| HKShanhai Group Limited DWDM-SFPGE-1530-33 | Operates at a wavelength of 1530.33nm |
| HKShanhai Group Limited DWDM-SFPGE-1547-22 | Suitable for distances up to 80km |
| HKShanhai Group Limited DWDM-SFPGE-1550-92 | Data rate of 10G |
Get more information
For further information about the HKShanhai Group Limited DWDM-SFPGE-1546-92, including its price and the datasheet, please contact us through Live Chat or at sales@router-switch.com. Check “HKShanhai Group Limited DWDM-SFPGE-1546-92 price” and “DWDM-SFPGE-1546-92 datasheet”, buy “HKShanhai Group Limited DWDM-SFPGE-1546-92 module” with the best price and fast shipping. Free Live Chat support is available.
HKShanhai Group Limited DWDM-SFPGE-1546-92 Specification
DWDM-SFPGE-1546-92 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1546-92 |
| Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Transmission Distance | 120 km |
| Wavelength | 1546.92 nm |
| Connector Type | LC |
| Fiber Type | Single-mode |
| Temperature Range | 0°C to 70°C (32°F to 158°F) |
| Power Supply Voltage | 3.3V |
| Power Consumption | 1.5W |
| Receiver Sensitivity | -28dBm |
| Optical Output Power | -1 to -5 dBm |
| Extinction Ratio | 10 dB |
| EMI | Class 1 |
| Regulatory Compliance | RoHS |
| Protocols | G.694.1, G.709, G.975 |
| Interface Standard | IEEE 802.3z |
| Single Channel | Yes |
