The HKShanhai Group Limited DWDM-SFPGE-1543-73 is a high-performance DWDM optical transceiver designed for efficient long-range data transmission. This enhanced SFP module supports data rates up to 2.5Gbps and operates over single-mode fiber (SMF). With a central wavelength of 1543.73nm, the module can cover distances up to 120km, making it ideal for extensive optical network deployments.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1543-73 |
| Form Factor | Enhanced SFP (eSFP) |
| Data Rate | 2.5Gbps |
| Wavelength | 1543.73nm |
| Distance | 120km |
| Connector | LC |
Product Features
- ??Enhanced SFP form factor for flexible use.
- ??Supports data rates up to 2.5Gbps.
- ??Operates over single-mode fiber with a reach of up to 120km.
- ??Utilizes a 1543.73nm DWDM wavelength for high-density applications.
- ??Equipped with an LC connector type for seamless integration.
Product Applications
- ??Long-haul telecommunications networks requiring enhanced data transmission capabilities.
- ??High-density data center interconnects demanding long optical reach.
- ??Infrastructure networks for Internet Service Providers (ISPs) seeking reliable extended reach solutions.
Supported Options
| Accessory | Model |
| LC Fiber Patch Cable | LC-PC-10M-HUAWEI |
| SFP Dust Cover | SFP-DC-1234-HUAWEI |
| Optical Attenuator | ATT-5DB-HUAWEI |
Compare to Similar Items
| Model | Differences |
| DWDM-SFPGE-1540-10 | 10Gbps data rate, 40km range |
| DWDM-SFPGE-1530-40 | 1Gbps data rate, 40km range |
| DWDM-SFPGE-1550-80 | 2.5Gbps data rate, 80km range |
Get more information
For more information about the HKShanhai Group Limited DWDM-SFPGE-1543-73 and its pricing, contact us via Live Chat or email at sales@router-switch.com. Check HKShanhai Group Limited DWDM-SFPGE-1543-73 price and DWDM-SFPGE-1543-73 datasheet, buy HKShanhai Group Limited DWDM-SFPGE-1543-73 with best price and fast shipping. Free Live Chat is supported.
HKShanhai Group Limited DWDM-SFPGE-1543-73 Specification
DWDM-SFPGE-1543-73 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | DWDM-SFPGE-1543-73 |
| Transceiver Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Fiber Type | Single-mode |
| Wavelength | 1543.73nm |
| Maximum Distance | 120km |
| Connector | LC |
| Transmit Power | 0 to +5 dBm |
| Receiver Sensitivity | -23 dBm |
| Power Supply | 3.3V |
| Power Consumption | <1.5W |
| Digital Diagnostics | Yes |
| Temperature Range | -40 to 85°C |
| Compliance | RoHS |
| Form Factor Compliance | SFF-8472 |
| MTBF | 1,000,000 hours |
| Modulation Format | NRZ |
| Security Feature | SDN Compatible |
| Application | Telecom and Data Center |
