The HKShanhai Group Limited DWDM-SFPGE-1535-82 is a high-performance DWDM Optical Transceiver designed for exceptional data transmission. This eSFP transceiver supports a data rate of 2.5G and operates over a single-mode fiber with a wavelength of 1535.82nm. It can cover distances up to 120km and employs an LC connector, making it ideal for long-haul telecommunications and large-scale data networks.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1535-82 |
| Type | DWDM Optical Transceiver |
| Data Rate | 2.5G |
| Wavelength | 1535.82nm |
| Distance | 120km |
| Connector | LC |
Product Features
- ??Supports a high data rate of up to 2.5G
- ??Designed for DWDM (Dense Wavelength Division Multiplexing)
- ??Single-mode fiber operation for long-distance coverage
- ??Compact eSFP form factor
- ??120km transmission distance capability
Product Applications
- ??Long-haul telecommunications networks
- ??Large-scale enterprise data networks
- ??Service provider backhaul connectivity
Supported Options
| Accessory | Model |
| Patch Cord | PC-LC-LC-10M |
| Fiber Optical Splitter | FOS-1×2-SMF |
| Attenuator | ATT-SM-5DB |
Compare to Similar Items
| Model | Differences |
| HKShanhai Group Limited DWDM-SFPGE-1533-86 | Wavelength: 1533.86nm |
| HKShanhai Group Limited DWDM-SFPGE-1537-49 | Wavelength: 1537.49nm |
| HKShanhai Group Limited DWDM-SFPGE-1540-17 | Wavelength: 1540.17nm |
Get more information
For further information about the HKShanhai Group Limited DWDM-SFPGE-1535-82 and its price, please contact us through Live Chat or email us at sales@router-switch.com. Check HKShanhai Group Limited DWDM-SFPGE-1535-82 price and DWDM-SFPGE-1535-82 datasheet, buy HKShanhai Group Limited DWDM-SFPGE series with the best price and fast shipping. Free Live Chat support is available.
HKShanhai Group Limited DWDM-SFPGE-1535-82 Specification
DWDM-SFPGE-1535-82 Specifications |
|
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1535-82 |
| Type | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Data Rate | 2.5G |
| Transmission Distance | 120 km |
| Wavelength | 1535.82 nm |
| Connector Type | LC |
| Fiber Type | Single-mode |
| Power Supply Voltage | 3.3V |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Receiver Sensitivity | -24 dBm |
| Max Input Power | -9 dBm |
| Dispersion Tolerance | 1600 ps/nm |
| Maximum Power Consumption | 1W |
| DDM/DOM | Supported |
| MTBF | 1 million hours |
| Compliance | ROHS, CE, FCC, TUV |
| Warranty | 1 year |
