The HKShanhai Group Limited DWDM-SFPGE-1535-04 is a high-performance DWDM Optical Transceiver designed to support 2.5G data rates over distances up to 120km. This single-mode module operates at a wavelength of 1535.04nm and is equipped with an LC connector, making it an ideal choice for long-haul dense wavelength division multiplexing applications.
Quick Spec
| Brand | HKShanhai Group Limited |
| Model | DWDM-SFPGE-1535-04 |
| Data Rate | 2.5G |
| Distance | 120km |
| Connector Type | LC |
Product Features
- ??High data rate of 2.5G for efficient data transfer.
- ??Supports long-distance transmission up to 120km.
- ??Operates at a wavelength of 1535.04nm, ideal for DWDM systems.
- ??Single-mode module for increased performance over longer distances.
- ??LC connector for reliable and secure connections.
Product Applications
- ??Long-haul DWDM systems requiring stable high-speed data transfer.
- ??Single-mode optical networks in metropolitan areas.
- ??Telecommunication networks needing extended reach optical links.
Supported Options
| Accessory | Model |
| Patch Cable | HKShanhai Group Limited LC-SC-10m |
| Optical Attenuator | HKShanhai Group Limited ATT-5dB |
| Transceiver Case | HKShanhai Group Limited CASE-SFP |
Compare to Similar Items
| Model | Differences |
| HKShanhai Group Limited DWDM-SFPGE-1540-04 | Wavelength of 1540.04nm |
| HKShanhai Group Limited DWDM-SFPGE-1530-04 | Wavelength of 1530.04nm |
| HKShanhai Group Limited DWDM-SFPGE-1550-04 | Wavelength of 1550.04nm |
Get more information
For more information about the HKShanhai Group Limited DWDM-SFPGE-1535-04 including pricing and the datasheet, contact us via Live Chat or email us at sales@router-switch.com. Check HKShanhai Group Limited DWDM-SFPGE-1535-04 price and DWDM-SFPGE-1535-04 datasheet, and buy HKShanhai Group Limited DWDM series with the best price and fast shipping. Free Live Chat support is available.
HKShanhai Group Limited DWDM-SFPGE-1535-04 Specification
DWDM-SFPGE-1535-04 Specifications |
|
| Brand | HKShanhai Group Limited |
| Product Name | DWDM-SFPGE-1535-04 |
| Interface Type | eSFP |
| Data Rate | 2.5G |
| Optical Wavelength | 1535.04nm |
| Distance | 120km |
| Connector Type | LC |
| Transmission Mode | Single-mode |
| Fiber Type | Single-mode Fiber (SMF) |
| Temperature Range | 0°C to 70°C |
| Power Supply Voltage | 3.3V |
| Maximum Power Consumption | 1.5W |
| Digital Diagnostic Monitoring (DDM) | Yes |
| EMI Safety | FCC Part 15 Class B |
| Operating Humidity | 5% to 95% (non-condensing) |
| Compatibility | Multi-vendor |
| Hot-swappable | Yes |
| MTBF | 1,000,000 hours |
| Compliance | IEC 60825-1, RoHS |
| Warranty | 1 Year |
