Hikvision DS-8632NI-I8 is one of the Hikvision NVR 8600 Series.
Quick Spec
Table 1 shows the quick spec.
|
Model |
DS-8632NI-I8 |
|
IP video input |
32-ch |
|
Incoming bandwidth |
320Mbps |
|
Outgoing bandwidth |
256Mpbs |
|
VGA1/HDMI1 output resolution |
HDMI1: 4K (3840 2160)/60Hz, 4K (3840 2160)/30Hz, 2K (2560 1440)/60Hz, 1920 1080/60Hz, 1600 1200/60Hz, 1280 1024/60Hz, 1280 720/60Hz, 1024 768/60HzVGA1: 2K (2560 1440)/60Hz, 1920 1080/60Hz, 1280 1024/60Hz, 1280 720/60Hz, 1024 768/60Hz |
|
VGA2/HDMI2 output resolution |
HDMI2: 1920 1080/60Hz, 1280 1024/60Hz, 1280 720/60Hz, 1024 768/60HzVGA2: 1920 1080/60Hz, 1280 1024/60Hz, 1280 720/60Hz, 1024 768/60Hz |
|
Audio output |
2-ch, RCA (Linear, 1 K ) |
|
Decoding format |
H.265/H.264/MPEG4 |
|
Recording resolution |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/ QCIF |
|
Synchronous playback |
16-ch |
|
Capability |
4-ch@4K/16-ch@1080p |
Product Details
Hikvision DS-8632NI-I8 provides these main features:
Centralized management of IP cameras, including configuration, information import/export, real-time information display, two-way audio, upgrade, etc.
Connectable to smart IP cameras from Hikvision, and the recording, play back, and backing up of VCA alarms can be realized
Supports VCA detection alarm
Instant playback for assigned channel under multi-channel display mode
Smart search for the selected area in the video; and smart playback for improving the playback efficiency
Supports HDD quota and group modes; and different capacity can be assigned to different channels
Get More Information
Do you have any question about the DS-8632NI-I8
Contact us now via Live Chat or sales@router-switch.com.
Hikvision DS-8632NI-I8 Specification
DS-8632NI-I8 Specification |
|
|
IP video input |
32-ch |
|
Incoming bandwidth |
320Mbps |
|
Outgoing bandwidth |
256Mpbs |
|
VGA1/HDMI1 output resolution |
HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz VGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
|
VGA2/HDMI2 output resolution |
HDMI2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz VGA2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
|
Audio output |
2-ch, RCA (Linear, 1 K Ω) |
|
Decoding format |
H.265/H.264/MPEG4 |
|
Recording resolution |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/ QCIF |
|
Synchronous playback |
16-ch |
|
Capability |
4-ch@4K/16-ch@1080p |
|
SATA |
8 SATA interfaces |
|
eSATA |
1 eSATA interface |
|
Capacity |
500GB/1TB/2TB/3TB/4TB/5TB/6TB |
|
Two-way audio |
1-ch, RCA (2.0 Vp-p, 1 kΩ) |
|
Network interface |
2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces |
|
Serial interface |
RS-232; RS-485; Keyboard |
|
USB interface |
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
|
Alarm in/out |
16/4 |
|
Power supply??/strong> |
100 to 240 VAC, 50 to 60 Hz |
|
Consumption (without hard disk) |
??35 W |
|
Max. Power |
200 W |
|
Working temperature |
-10 to +55°C (14 to 131°F) |
|
Working humidity |
10% to 90% |
|
Chassis |
19-inch rack-mounted 2U chassis |
|
Dimensions??/strong>(W × D × H)??/strong> |
445 × 470 ×90 mm ( 17.5”??18.3??× 3.5?? |
