Hikvision DS-2PT3306IZ-DE3 is the PanoVu Mini Series IR Network PTZ Camera.
Quick Spec
Table 1 shows the quick spec.
|
Model |
DS-2PT3306IZ-DE3 |
|
Image Sensor |
Three 1/2.8″ progressive scan CMOS |
|
Min. Illumination |
Color: 0.05 Lux @(F2.0, AGC ON) |
|
Lens |
2 mm |
|
Angle of View |
Horizontal field of view: 128.5 3 |
|
Main Stream |
Main stream:(Sub-stream not enabled) |
|
Sub Stream |
50 Hz: 20 fps (704 576, 640 480, 352 288) |
|
Image Compression |
Main stream: H.265/H.264 |
|
Basic Event Detection |
Motion Detection, Video Tampering Detection, Exception |
|
Smart Image Enhancement |
Digital WDR/HLC/BLC/3D DNR/Defog/Regional Exposure |
Product Details
Hikvision DS-2PT3306IZ-DE3 provides these key features:
Three 1/2.8″ progressive scan CMOS
Up to 3-ch 1920 1080@30fps resolution
Min. illumination:
– Color: 0.05 Lux @(F2.0, AGC ON)
– B/W: 0.01 Lux @(F2.0, AGC ON)
– 0 Lux with IR
Horizontal FOV: 128.5 3
– Vertical FOV: 75.7
Up to 10 m IR radius
Compare to Similar Item
Table 2 shows the comparison.
|
Model |
DS-2PT3306IZ-DE3 |
DS-2PT3122IZ-DE3(2.8-12mm) |
|
Image Sensor |
Three 1/2.8″ progressive scan CMOS |
1/2.8″ progressive scan CMOS |
|
Min. Illumination |
Color: 0.05 Lux @(F2.0, AGC ON) |
Color: 0.05 Lux @(F2.0, AGC ON) B/W: 0.01 Lux @(F2.0, AGC ON) 0 Lux with IR |
|
Lens |
2 mm |
f2mm/F2.0 |
|
Angle of View |
Horizontal field of view: 128.5 3 |
Horizontal field of view: 128.5 |
Get More Information
Do you have any question about the DS-2PT3306IZ-DE3
Contact us now via Live Chat or sales@router-switch.com.
Hikvision DS-2PT3306IZ-DE3 Specification
DS-2PT3306IZ-DE3 Specification |
|
|
Panoramic Camera |
|
|
Image Sensor |
Three 1/2.8″ progressive scan CMOS |
|
Min. Illumination |
Color: 0.05 Lux @(F2.0, AGC ON) B/W: 0.01 Lux @(F2.0, AGC ON) 0 Lux with IR |
|
Lens |
2 mm |
|
Angle of View |
Horizontal field of view: 128.5° × 3 Vertical field of view: 75.7° |
|
Main Stream |
Main stream:(Sub-stream not enabled) 50 Hz: 25 fps (1920 Ă— 1080, 1280 Ă— 960, 1280 Ă— 720, 704 Ă— 576, 640 Ă— 480, 352 Ă— 288) 60 Hz: 30 fps (1920 Ă— 1080, 1280 Ă— 960, 1280 Ă— 720, 704 Ă— 480, 640 Ă— 480, 352 Ă— 240) Main stream:(Sub-stream enabled) 50 Hz: 20 fps (1920 Ă— 1080, 1280 Ă— 960, 1280 Ă— 720) 60 Hz: 20 fps (1920 Ă— 1080, 1280 Ă— 960, 1280 Ă— 720) |
|
Sub Stream |
50 Hz: 20 fps (704 Ă— 576, 640 Ă— 480, 352 Ă— 288) 60 Hz: 20 fps (704 Ă— 480, 640 Ă— 480, 352 Ă— 240) |
|
Image Compression |
Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG (MJPEG is only supported by channel 1) H.264 with Main Profile/High Profile, H.265 with Main Profile |
|
Basic Event Detection |
Motion Detection, Video Tampering Detection, Exception |
|
Smart Image Enhancement |
Digital WDR/HLC/BLC/3D DNR/Defog/Regional Exposure |
|
System Function |
|
|
IR |
10 m |
|
Smart Detection |
Audio Exception Detection, Intrusion Detection, Line Crossing Detection |
|
Input & Output |
|
|
Audio Input |
1-ch audio input |
|
Audio Output |
1-ch audio output |
|
Network |
|
|
Audio compression |
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2 |
|
Protocol |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour |
|
Application programming |
Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform |
|
System Integration |
|
|
User/Host Level |
Up to 32 users,3 Levels: Administrator, Operator and User |
|
Security Measures |
User authentication (ID and PW); Host authentication (MAC address); IP address filtering |
|
Web Browser |
IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51 |
|
Ethernet |
1 RJ45 10 M/100 M Ethernet |
|
General |
|
|
Power supply |
12 VDC & PoE+ (802.3 at, class 4) Max.20 W (Max. 6 W for IR) |
|
Working temperature |
-10°C to 50°C (14°F to 122°F) |
|
Working humidity |
??90% |
|
Material |
PC & Aluminum alloy |
|
Protection Level |
IP66, TVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection |
|
Dimensions (WĂ—DĂ—H) |
Φ 183 mm Ă— 76 mm (Φ 7.20″ Ă— 2.99″) |
