Hikvision DS-2CD2685G0-IZS is the 8 MP(4K) IR Varifocal Bullet Network Camera.
Quick Spec
Table 1 shows the quick spec.
|
Model |
|
|
Image Sensor |
1/2″ Progressive Scan CMOS |
|
Signal System |
PAL/NTSC |
|
Min. Illumination |
Color: 0.008 Lux @ (F1.2, AGC ON), 0.011 Lux @ (F1.4, AGC ON) |
|
Shutter time |
1/3 s to 1/100,000 s |
|
Slow shutter |
Support |
|
Lens |
2.8 to 12 mm |
|
Lens Mount |
14 |
|
Adjustment Range |
Pan: 0 to 360, tilt: 0 to 90, rotate: 0 to 360 |
|
Day& Night |
IR Cut Filter |
|
Wide Dynamic Range |
120 dB |
|
Digital noise reduction |
3D DNR |
|
Focus |
Auto |
Product Details
Hikvision DS-2CD2685G0-IZS provides these key features:
1/2″ Progressive Scan CMOS
3840 2160 resolution
H.265, H.265+, H.264+, H.264
120dB WDR
BLC/3D DNR/ROI/HLC
IP67, IK10
Powered by Darkfighter
4 behavior analyses and face detection
Color: 0.008 Lux @ (F1.2, AGC ON), 0.011 Lux @ (F1.4, AGC ON)
Compare to Similar Item
Table 2 shows the comparison.
|
Model |
||
|
Image Sensor |
1/3″ Progressive Scan CMOS |
1/2″ Progressive Scan CMOS |
|
Min. Illumination |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON), 0 Lux with IR |
Color: 0.008 Lux @ (F1.2, AGC ON), 0.011 Lux @ (F1.4, AGC ON) |
|
Shutter time |
1/3 s to 1/100,000 s |
1/3 s to 1/100,000 s |
|
Slow shutter |
Support |
Support |
|
Adjustment Range |
Pan: 0 to 355, tilt: 0 to 75, rotate: 0 to 360 |
Pan: 0 to 360, tilt: 0 to 90, rotate: 0 to 360 |
Get More Information
Do you have any question about the DS-2CD2685G0-IZS
Contact us now via Live Chat or sales@router-switch.com.
Hikvision DS-2CD2685G0-IZS Specification
DS-2CD2685G0-IZS Specifications |
|
| Brand | Hikvision |
| Model | DS-2CD2685G0-IZS |
| Camera Type | Bullet Camera |
| Resolution | 8 MP |
| Lens Type | Varifocal |
| IR Range | Up to 50m |
| Image Sensor | 1/2.5″ Progressive Scan CMOS |
| Max Resolution | 3840 �� 2160 |
| Signal System | PAL/NTSC |
| Minimum Illumination | Color: 0.014 Lux @ (F1.2, AGC ON), B/W: 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Day & Night | IR Cut Filter |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | 120dB |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Power Supply | 12 VDC �� 25%, PoE (802.3af, class 4) |
| Power Consumption | 12 VDC, 0.7 A, Max: 8.64 W; PoE (802.3at, 42.5 V to 57 V), 0.3 A to 0.2 A, Max: 10 W |
| Operating Conditions | -30��C to 60��C (-22��F to 140��F), Humidity 95% or less (non-condensing) |
| Ingress Protection | IP67 |
| Dimensions | Varies (model-specific) |
| Material | Metal |
| Usage | Outdoor |
