The Dahua DC12-200 is a top-quality lead acid battery designed to provide reliable and long-lasting power solutions for a range of applications. Its robust construction and advanced technology make it a dependable choice for both commercial and residential uses. Experience the efficiency of Dahua°s innovative battery solutions with the DC12-200.
Quick Spec
| Battery Type | Lead Acid |
| Nominal Voltage | 12V |
| Capacity | 200Ah |
| Dimensions (L x W x H) | 522mm x 240mm x 219mm |
| Weight | 58.2kg |
Product Features
- High capacity of 200Ah for longer power supply
- Robust construction ensures durability
- Maintenance-free design for ease of use
- Safe discharge and recharge cycles
- Reliable performance in diverse environments
Product Applications
- Backup power for data centers and IT infrastructure
- Energy storage for renewable energy systems
- Power supply for emergency lighting and communication systems
Supported Options
| Battery Charger | CHG12-20 |
| Battery Monitor | BM12-200 |
| Connection Cable | CC12-50 |
Compare to Similar Items
| Model | Difference |
| DC12-150 | Lower capacity at 150Ah |
| DC12-250 | Higher capacity at 250Ah |
| DC12-100 | Compact size with 100Ah capacity |
Get more information
Contact us through Live Chat or at sales@router-switch.com for further details on the Dahua DC12-200, including its price and datasheet. Check Dahua DC12-200 price and Dahua DC12-200 datasheet, buy Dahua DC12-200 Battery with the best price and fast shipping. Free Live Chat is supported.
Dahua DC12-200 Specification
DC12-200 Specifications |
|
| Brand | Dahua |
| Model | DC12-200 |
| Type | Lead Acid Battery |
| Nominal Voltage | 12 V |
| Capacity | 200 Ah |
| Rated Capacity | 20 Hour Rate 10.5V |
| Terminal Type | T11 |
| Length | 522 mm |
| Width | 240 mm |
| Height | 218 mm |
| Total Height | 224 mm |
| Case Material | ABS |
| Internal Resistance | 3.5 m° (Fully charged) |
| Float Charging Voltage | 13.5 – 13.8 V |
| Max Charging Current | 40 A |
| Operating Temperature Range | -20°C to 60°C |
| Cycle Use Voltage | 14.4 – 15.0 V |
| Self-Discharge | Approx. 3% per month at 25°C |
| Application | Solar, Wind, UPS, Telecom |
| Life Expectancy | 10-12 years |
