The CBS220-16T-2G-EU is a smart 16-port GE 2×1 switch designed for efficient networking. It offers high performance and reliability, making it suitable for various applications. With its advanced features and flexible options, this switch provides seamless connectivity and enhances network efficiency.
Quick Spec
Table 1 shows the quick spec of the CBS220-16T-2G-EU.
| Parameter | Description |
|---|---|
| Ports | 16 GE ports, 2x1G ports |
| Switch Type | Layer 2 |
| Power over Ethernet | No |
| Management | Smart |
Product Features
- High-performance 16-port GE switch
- 2x1G uplink ports for enhanced connectivity
- Smart management for improved network control
- Reliable and efficient networking
- Compact and durable design
Product Applications
- Small to medium-sized businesses
- Office networks
- Home networks
- Enterprise environments
- Network expansion and optimization
Compare to Similar Items
Table 3 shows the comparison to similar items of the CBS220-16T-2G-EU.
| Model | Differences |
|---|---|
| CBS220-24P-4X-EU | 24-port GE with PoE support |
| CBS220-24T-4X-EU | 24-port GE with 4x10G uplink ports |
| CBS220-48T-4G-EU | 48-port GE with 4x1G uplink ports |
Get more information
Do you have any question about the CBS220-16T-2G-EU price?
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited CBS220-16T-2G-EU Specification
CBS220-16T-2G-EU Specification |
|
| Capacity in millions of packets per second (mpps) (64-byte packets) | 26.78 mpps |
| Switching capacity in gigabits per second (Gbps) | 36 Gbps |
| Head-of-Line (HOL) blocking | HOL blocking prevention |
| MAC table |
2K addresses for CBS110-5T-D 8K addresses for all other models |
| Jumbo frame | 9216 bytes |
| Quality of Service (QoS) | 802.1p priority based, 4 hardware queues, priority queuing and Weighted Round-Robin (WRR) |
| Loop detection | Helps discover loops in the network to avoid broadcast storms |
| Cable diagnostics | Quickly identify and troubleshoot network cable faults and/or shorts |
| Media-dependent interface | Automatic Media Dependent Interface (MDI) and MDI crossover (MDI-X) |
| Standards | IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, 802.1p priority, Energy Efficient Ethernet, 802.3af, Power over Ethernet |
| Total system ports | 18 Gigabit Ethernet |
| RJ-45 ports | 16 Gigabit Ethernet |
| Uplink ports | 2 Gigabit Ethernet SFP |
| LEDs |
System, Link/Act, Speed |
| Cabling type | Category 5e or better |
| Mounting options | Desktop, wall-mount or rack mount |
| Physical security lock | Kensington lock slot |
| Flash |
64 MB |
| CPU memory |
256 MB |
| Packet Buffer | 4.1 Mb |
| Unit dimensions | 440 x 203 x 44 mm (17.3 x 8.0 x 1.7 in) |
| Unit weight | 2.48 kg (5.47 lb) |
| System power consumption |
110V=11.1W 220V=11.4W |
| Power consumption (with PoE) |
N/A |
| Heat dissipation (BTU/hr) | 38.9 |
| Operating temperature | 32° to 122°F (0° to 50°C) |
| Storage temperature | ??° to 158°F (??0° to 70°C) |
| Operating humidity | 10% to 90%, relative, noncondensing |
| Storage humidity | 10% to 90%, relative, noncondensing |
| Mean Time Between Failures (MTBF) | 1,062,289 hours |
