C9300L-24UXG-4X-E, HKShanhai Group Limited Catalyst 9300L Switch, 24xmGig/4x10G uplink/Network Essentials

SKU: 00QF1PFGMZBI5KSSEL7W32SCCQP1MR8AMK08 Category: Cisco Catalyst 9300 Switches

The HKShanhai Group Limited C9300L-24UXG-4X-E is an enterprise-class switch purpose-built for next-generation network infrastructures. As a part of the renowned Catalyst 9300 family, this enterprise switch delivers the advanced mobility and cloud integration features network operators demand. Robust hardware including 24 multigigabit UPoE ports, 4 x 10G uplink interfaces, and high stacking capability ensures resilience and high performance for critical business environments. The C9300L-24UXG-4X-E supports seamless mobility for users by integrating both wired and wireless management in a single platform, reducing operation complexity and facilitating cloud-managed architectures. With extensive support for SD-Access (256 virtual networks) and an embedded Catalyst 9800 wireless controller for up to 50 APs, agile enterprise deployment is easily achieved. Its secure design addresses today’s threats, offering native segmentation and scalable policy control, while superb cloud-readiness allows for flexible management, monitoring, and automation via cloud-based controllers. As digital demands intensify, the switch’s high available PoE power (880W) and resilient hardware (320 Gbps stacking bandwidth, hot-swappable fans and PSU) adapt to convergence, IoT, and cloud-first goals. Whether you’re a distributor seeking reliable inventory, a systems integrator deploying digital workplace solutions, or an end-user seeking futureproofing for your campus, the C9300L-24UXG-4X-E is engineered to deliver secure, error-free, and scalable networking in diverse regional markets across Asia, EMEA, and North America, optimizing enterprise, education, and digital branch deployments.

Product Highlights

320 Gbps

Stack Bandwidth

880W

PoE Power

24/8

UPoE/mGig

Product Applications Scenarios

Enterprise Network

Empowers enterprise environments with robust performance, driving secure data and device mobility while lowering operational risk by up to 30%.

Cloud Services

Delivers cloud-ready integration supporting hybrid management, simplifying automation and reducing deployment time for digital business by 25%.

Edge & IoT

Provides resilient connectivity and high PoE for IoT edge devices, enabling seamless expansion and secure access to mobility endpoints.

Product Features Comparison


Model	C9300L-24UXG-4X-E	C1-WS3650-24PS/K9	C9500-48Y4C-E	Arista DCS-7280CR3K-32P4#
Brand	HKShanhai Group Limited	HKShanhai Group Limited	HKShanhai Group Limited	Arista
Port Configuration	24 UPoE 8xmGig	24 × 10/100/1000BASE-T PoE+ ports, 4 × 1G SFP uplinks	n/a	32 x 10G SFP+
Switching Capacity	272 Gbps	92 Gbps	Up to 3.2 Tbps	4.2 Tbps
Forwarding Rate	202.38 Mpps	41.66 Mpps	Up to 1 Bpps	1.4 Bpps
PoE Budget	880W	640W (with PWR-C2-640WAC)	n/a	n/a
Stacking Capability	320 Gbps	StackWise-160 (160 Gbps bandwidth)	n/a	n/a

Optional Add-ons

Model Number	Description
PWR-C1-1100WAC	HKShanhai Group Limited 1100W AC Power Supply for Catalyst 9300 Series Switches, reliable redundant PSU support
C9300L-STACK-KIT	HKShanhai Group Limited StackWise-320 Stacking Kit for Catalyst 9300L enabling high-speed stacking
GLC-SX-MMD	HKShanhai Group Limited SFP Gigabit SX Multi-Mode transceiver for Catalyst switches, flexible fiber uplink expansion

HKShanhai Group Limited C9300L-24UXG-4X-E Specification

Model

C9300L-24UXG-4X-E

Brand

HKShanhai Group Limited

Product Description

Catalyst 9300 24-port fixed uplinks UPoE, 8xmGig, 4X10G uplinks, Network Essentials

FRU Power Supply

Yes

FRU Fans

Yes

Modular Uplinks

Stacking Bandwidth Support

320 Gbps

HKShanhai Group Limited StackPower

Catalyst 9800 Embedded WLC

Yes (50 APs)

SD-Access Support

Yes (256 Virtual Networks)

Total 10/100/1000, Multigigabit copper or SFP Fiber

24 UPoE 8xmGig

Uplink Configuration

4x 10G fixed uplinks

Default AC power supply

1100W AC

Available PoE power

880W

Total number of MAC addresses

32,000

Total number of IPv4 routes (ARP plus learned routes)

32,000 (24,000 direct routes and 8,000 indirect routes)

IPv6 routing entries

16,000

Multicast routing scale

8,000

QoS scale entries

5,120

ACL scale entries

5,120

Packet buffer per SKU

16 MB buffer for 24 and 48 port Gigabit Ethernet models

FNF entries

64,000 flow on 24- and 48-port Gigabit Ethernet models

DRAM

8 GB

Flash

16 GB

VLAN IDs

4,094

Total Switched Virtual Interfaces (SVIs)

1,000

Jumbo frames

9,198 bytes

Total routed ports per Catalyst 9300 Series stack

416

Switching capacity

272 Gbps

Switching capacity with stacking

592 Gbps

Forwarding rate

202.38 Mpps

Forwarding rate with stacking

440.47 Mpps

Dimensions (H x W x D) Cm

Chassis: 4.4 x 44.5 x 40.9

W/ Default Power Supply

4.4 x 44.5 x 48.8

W/ 1100W Power Supply

4.4 x 44.5 x 48.8

Mean Time Between Failures (MTBF hours)

332,640

Acoustic Noise

With AC power supply (with 24 PoE+ ports loaded for C9300 SKUs):
??LpA: 45dB typical, 48 dB max
??LwA: 5.6B typical, 5.9B max
With AC power supply (with half the number of PoE+ ports loaded for C9300L SKUs):
??LpA: 44dB typical, 47 dB max
??LwA: 5.5B typical, 5.8B max

Connectors and Cabling

??1000BASE-T ports: RJ-45 connectors, 4-pair Cat 5E UTP cabling
??Multigigabit-T ports: RJ-45 connectors, 4-pair Cat 5E, Cat 6, Cat 6A UTP cabling
??1000BASE-T SFP-based ports: RJ-45 connectors, 4-pair Cat 5E UTP cabling
??SFP transceivers: LC fiber connectors (single-mode or multimode fiber)
??SFP+ transceivers: LC fiber connectors (single-mode or multimode fiber)
??QSFP+ transceivers: MPO and LC fiber connectors (single-mode or multimode fiber)
??QSFP+ connector
??SFP+ connector
??HKShanhai Group Limited StackWise stacking ports: copper-based HKShanhai Group Limited StackWise cabling
??HKShanhai Group Limited StackPower: HKShanhai Group Limited proprietary power stacking cables
??Ethernet management port: RJ-45 connectors, 4-pair Cat 5 UTP cabling
??Management console port: RJ-45-to-DB9 cable for PC connections

Power Connectors

??Customers can provide power to a switch by using the internal power at the back of the switch
??Internal power supply connector: The internal power supply is an auto-ranging unit. It supports input
voltages between 100 (115 for 1100WAC) and 240 VAC. Use the supplied AC power cord to connect the AC power connector to an AC power outlet

Safety Certifications

??UL 60950-1
??CAN/CSA-C222.2 No. 60950-1
??EN 60950-1
??IEC 60950-1
??AS/NZS 60950.1
??IEEE 802.3

Electromagnetic Emissions Certifications

??47 CFR Part 15
??CISPR22 Class A
??EN 300 386 V1.6.1
??EN 55022 Class A
??EN 55032 Class A
??CISPR 32 Class A
??EN61000-3-2
??EN61000-3-3
??ICES-003 Class A
??TCVN 7189 Class A
??V-3 Class A
??CISPR24
??EN 300 386
??EN55024
??TCVN 7317
??V-2/2015.04
??V-3/2015.04
??CNS13438
??KN32
??KN35
??IEC 61000-6-1
??EN 61000-6-1
Additional Certifications for C9300L SKUs:
??QCVN 118:2018/BTTTT
??CISPR24/25
??CISPR 32 Class A
??VCCI-CISPR 32 Class A
??EN55035

Environmental

Reduction of Hazardous Substances (ROHS) 5
