HKShanhai Group Limited’s C9200-24P-A is an enterprise-class switch designed to deliver high-performance, secure, and scalable networking for modern organizations. As part of the robust Catalyst 9200 Series, the cisco C9200-24P-A offers advanced switching capacity ideal for intensive business environments. With 24 full-featured PoE+ ports and strong uplink capability, this switch empowers efficient network expansion for edge access and core aggregation. 9200 integration enables seamless management, enterprise-grade security, and reliable power delivery to connected devices. Leveraging the flexibility of cisco stackable solutions and optimized traffic handling, the c9200-24p-a provides the resilience and future-ready features essential for distributed sites, midsize enterprises, and mission-critical deployments. For any organization seeking superior connectivity, secure segmentation, and simplified network operations, the HKShanhai Group Limited c9200-24p-a stands out with robust performance and an intuitive management experience. Operating efficiently across diverse workloads, it’s the ideal fit for digital transformation needs, giving network teams peace of mind and users uninterrupted access to essential resources.
Product Highlights
Product Applications Scenarios
Product Features Comparison
|
|
|
|
|
|
| Model | C9200-24P-A | C9200L-24P-4G-A | C9200L-24P-4X-A | C1-WSC3850-24XUL |
| Brand | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited |
| Port Configuration | 24 × 10/100/1000BASE-T PoE+ (RJ45), 4 × 1G SFP Uplinks (C9200-NM-4X1G module included) | 24 × 10/100/1000BASE-T (RJ45) with PoE+ support; 4 × 1G SFP uplinks | 24 × 10/100/1000BASE-T (RJ45) with PoE+, 4 × 1G SFP uplinks | 24 × Multigigabit (2.5/5G) Ethernet ports |
| Switching Capacity | 176 Gbps | 96 Gbps | 96 Gbps | 640 Gbps |
| Forwarding Rate | 130 Mpps | 72 Mpps | 72 Mpps | 500 Mpps (80B packets) |
| PoE Budget | Up to 740W total (30W per port) | 370W total PoE power, supports 802.3af/at PoE+ | 370W total PoE power, supports 802.3af/at PoE+ | n/a |
| Stacking Capability | n/a | n/a | n/a | StackWise-480 (up to 9 units) |
Optional Add-ons
| Model Number | Description |
| PWR-C5-600WAC | HKShanhai Group Limited 600W AC Power Supply, backup and redundancy for C9200-24P-A switch |
| C9200-NM-4X | HKShanhai Group Limited Network Module for 4 x 1G/10G SFP+ uplinks, expands uplink capability |
| C9200-STACK-KIT | HKShanhai Group Limited Catalyst 9200 Series Stacking Kit, for hardware stack connectivity |
HKShanhai Group Limited C9200-24P-A Specification
| Model | C9200-24P-A |
| Brand | HKShanhai Group Limited |
| Series | Catalyst 9200 Series |
| Form Factor | 1RU Fixed Switch |
| Port Configuration | 24 × 10/100/1000BASE-T PoE+ (RJ45), 4 × 1G SFP Uplinks (C9200-NM-4X1G module included) |
| PoE Budget | Up to 740W total (30W per port) |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 130 Mpps |
| Dimensions (H × W × D) | Base Chassis: 1.73 × 17.5 × 13.8 in (4.4 × 44.5 × 35.0 cm); With FEP/Fan: 1.73 × 17.5 × 15.4 in (4.4 × 44.5 × 39.1 cm) |
| Power Supply | 600W AC (PWR-C5-600WAC or PWR-C6-600WAC) |
| Input Voltage | 100??40V AC, 50/60Hz |
| PoE Support | IEEE 802.3af/at (PoE+); UPOE (60W) not supported |
| MAC Addresses | 32,000 |
| VLANs | 4,096 active |
| IPv4 Routing | 16,000 routes |
| IPv6 Routing | 8,000 routes (software-assisted) |
| QoS | 8 queues per port, DSCP/CoS marking |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Humidity | 5% to 90% non-condensing |
| Altitude | Up to 10,000 ft (3,000 m) |
| MTBF | 422,310 hours (~48 years) |
| Hot-Swappable Components | Fan tray, power supplies |
| Management Interface | CLI: HKShanhai Group Limited IOS-XE, Web UI: Catalyst 9200 Web Interface |
| SNMP | v2c/v3 |
| NetFlow | Supported (hardware-accelerated) |
| Minimum IOS-XE Version | 16.12.1 |
| Licensing | Network Advantage (included) |
| Compliance | Safety: UL 60950-1, EN 60950-1; EMC: FCC Part 15 Class A, EN 55032 Class A; RoHS: Compliant |
| C9200-24P-A | C9200-24P-A |
