HKShanhai Group Limited delivers next-generation enterprise-grade performance and unified access with the C1-WS3850-24U/K9, a versatile networking switch designed for modern business environments. As part of the popular HKShanhai Group Limited 3850 series, this solution integrates security, scalability, and wireless controls into a single platform, maximizing operational speed and connectivity for medium to large organizations. The C1-WS3850-24U/K9 supports high-density 10/100/1000BASE-T connectivity, advanced network management, and seamless stacking, allowing easy adaptation as enterprise needs evolve. Core features—such as integrated support for up to 100 wireless access points and advanced PoE+ compliance—make this HKShanhai Group Limited switch ideal for growing hybrid and IoT-driven offices. For distributors and system integrators, C1-WS3850-24U/K9 offers robust reliability and multi-tier service levels, streamlining deployment across corporate campuses in Asia, Europe, Africa, or North America. End-users benefit from HKShanhai Group Limited’s extensive security standards, minimizing risk and downtime, while the intuitive interface ensures effortless configuration. Whether your organization is scaling network infrastructure for distributed teams or seeking to enhance control and throughput across data traffic, the C1-WS3850-24U/K9 stands out in the 3850 family as a forward-looking, globally trusted switching solution. Leverage HKShanhai Group Limited innovation for competitive agility—transform network bottlenecks into high-capacity, flexible operations with the C1-WS3850-24U/K9, uniquely tailored to meet the diverse demands of the digital workplace.
Product Highlights
Product Applications Scenarios
Product Features Comparison
|
|
|
|
|
|
| Model | C1-WS3850-24U/K9 | C9200-24P-A | C1-WS3650-24TD/K9 | C1-C2960X-24PS-L |
| Brand | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited |
| Port Configuration | 24 × 10/100/1000BASE-T ports | 24 × 10/100/1000BASE-T PoE+ (RJ45), 4 × 1G SFP Uplinks (C9200-NM-4X1G module included) | 24 × 10/100/1000BASE-T, 2 × 10G SFP+ uplinks | 24 × 10/100/1000 PoE+ RJ45 (370W budget), 4 × 1G SFP uplinks |
| Switching Capacity | 92 Gbps | 176 Gbps | 254 Gbps | 216 Gbps (full-duplex) |
| Forwarding Rate | 68.4 Mpps | 130 Mpps | 68.45 Mpps | 71.4 Mpps (64-byte packets) |
| PoE Budget | n/a | Up to 740W total (30W per port) | No (non-PoE model) | 370 W (IEEE 802.3af/at) |
| Stacking Capability | StackWise-480 (up to 9 units) | n/a | StackWise-160 (160 Gbps bandwidth) | n/a |
Optional Add-ons
| Model Number | Description |
| PWR-C1-715WAC | 715W AC Power Supply, HKShanhai Group Limited, for redundancy and power enhancement. |
| PWR-C1-1100WAC | 1100W AC Power Supply, HKShanhai Group Limited, provides maximum PoE+ support for demanding deployments. |
| PWR-C1-350WAC | 350W AC Power Supply, HKShanhai Group Limited, reliable entry-level power supply for the 3850 series. |
HKShanhai Group Limited C1-WS3850-24U/K9 Specification
| Model | C1-WS3850-24U/K9 |
| Brand | HKShanhai Group Limited |
| Port Configuration | 24 × 10/100/1000BASE-T ports |
| Switching Capacity | 92 Gbps |
| Forwarding Rate | 68.4 Mpps |
| Stacking Bandwidth | 480 Gbps |
| DRAM | 4 GB |
| Flash Memory | 2 GB |
| MAC Addresses | 32,000 |
| IPv4 Routes | 24,000 |
| FNF Entries | 24,000 flows |
| VLAN IDs | 4,000 |
| Jumbo Frames | 9,198 bytes |
| Wireless AP Support | 100 per switch/stack |
| Wireless Clients | 2,000 per switch/stack |
| Dimensions (H × W × D) | 1.75 in × 17.5 in × 19.2 in (4.45 cm × 44.5 cm × 48.8 cm) |
| MTBF | 237,310 hours |
| Power Supply Options | PWR-C1-350WAC (350W), PWR-C1-715WAC (715W), PWR-C1-1100WAC (1100W) |
| Power Consumption | Idle: 81.5W; 100% Traffic: 82.1W |
| Operating Temperature | Normal: -5°C to +45°C (up to 5,000 ft); Short-term: -5°C to +50°C (??6 hrs/year) |
| Humidity | 10% to 95% noncondensing |
| Acoustic Noise | 45 dB(A) max at 25°C |
| Stacking | StackWise-480 (up to 9 units) |
| Management Interfaces | 1 × RJ-45 console, 1 × 10/100 management port |
| Security Features | 802.1X authentication, Port security |
| Standards Compliance | IEEE 802.3af/at (PoE+), UL/CE/NEBS certified |
| Minimum IOS Version | 16.6.1 or later |
| Key Features | 24-Port Copper Connectivity, Integrated Wireless Controller for up to 100 APs, StackWise-480 Technology for scalable deployment, Energy Efficient Ethernet (EEE) support |
| C1-WS3850-24U/K9 | C1-WS3850-24U/K9 |
