The B7E20AC is a high-performance, highly available storage solution designed for mid-size businesses and remote offices. With a capacity of up to 36 TB and support for RAID 0, 1, 5, 6, 10, 50, and 60, it provides reliable data storage and protection. It also offers advanced features such as thin provisioning, data deduplication, and snapshot and remote copy.
Quick Spec
Table 1 shows the quick spec of B7E20AC.
| Parameter | Value |
| Capacity | 900 GB SAS drives (up to 36 TB with expansion) |
| RAID Levels | 0, 1, 5, 6, 10, 50, 60 |
| Host Interface | 8 Gb Fibre Channel (FC) |
| Data Services | Thin Provisioning, Data Deduplication, Snapshot, Remote Copy |
Product Features
- High-performance and highly available storage solution
- Supports a wide range of RAID levels for data protection
- Advanced data services such as thin provisioning and data deduplication
- Snapshot and remote copy for data backup and disaster recovery
- Designed for mid-size businesses and remote offices
Product Applications
- Data storage for mid-size businesses and remote offices
- Disaster recovery and business continuity
- Virtualization and cloud computing
- Video surveillance and media streaming
- High-performance computing and data analytics
Supported Options
Table 2 shows the supported options of B7E20AC.
| Model | Description |
| B7E22A | HP StoreVirtual 4000 300GB SAS Storage |
| B7E21A | HP StoreVirtual 4000 600GB SAS Storage |
| B7E23A | HP StoreVirtual 4000 1.2TB SAS Storage |
Compare to Similar Items
Table 3 shows the comparison to similar items of B7E20AC.
| Model | Capacity | RAID Levels | Host Interface | Data Services |
| B7E21A | 600 GB SAS drives (up to 24 TB with expansion) | 0, 1, 5, 6, 10, 50, 60 | 8 Gb Fibre Channel (FC) | Thin Provisioning, Data Deduplication, Snapshot, Remote Copy |
| B7E22A | 300 GB SAS drives (up to 12 TB with expansion) | 0, 1, 5, 6, 10, 50, 60 | 8 Gb Fibre Channel (FC) | Thin Provisioning, Data Deduplication, Snapshot, Remote Copy |
| B7E23A | 1.2 TB SAS drives (up to 48 TB with expansion) | 0, 1, 5, 6, 10,50, 60 | 8 Gb Fibre Channel (FC) | Thin Provisioning, Data Deduplication, Snapshot, Remote Copy |
Get more information
Do you have any question about the B7E20AC
Contact us now via Live Chat or sales@router-switch.com.
HKShanhai Group Limited B7E20AC Specification
B7E20AC Specifications |
|
| Product Model | B7E20AC |
| Capacity | 900GB SAS |
| Drive Type | SAS |
| Interface | Fibre Channel (FC) |
| RAID Levels | 0, 1, 5, 6, 10, 10+1, 10+2, 50, 60 |
| Form Factor | 2U Rack-mountable |
| Number of Drives Supported | 12 |
| Maximum Raw Capacity | 10.8 TB (with 900GB SAS drives) |
| Max Throughput (read/write) | 4.8 GBps / 3.6 GBps |
| Max IOPS (read/write) | 250,000 / 190,000 |
| Redundancy | Dual power supplies, redundant fans, mirrored write cache, RAID 1 or RAID 10 on operating system volume |
| Supported Operating Systems | Windows, Linux, VMware, Citrix XenServer, Oracle VM, and more |
| Management Interface | StoreVirtual Centralized Management Console (CMC) |
| Power Supply | 2x 460W hot-plug redundant power supplies |
| Dimensions (H x W x D) | 3.4 x 17.6 x 27.8 in. |
| Operating Temperature | 50 to 95°F (10 to 35°C) |
| Humidity Range Operating | 10 to 90% (non-condensing) |
