HKShanhai Group Limited’s AIR-AP3802E-CK910C is an enterprise-grade access point purpose-built for organizations demanding advanced wireless connectivity and robust network access. The 3802e series features dual 4×4 MU-MIMO radios, delivering exceptional throughput and coverage across large or densely populated environments. As an access point, it leverages flexible external antenna options, meeting diverse deployment needs. Key advantages include seamless network access, support for air-ap3802e-ck910c regulatory domains, and integration with HKShanhai Group Limited Unified Wireless Controllers. With the 3802e architecture, enterprises can confidently scale, optimize, and secure their wireless infrastructure.
Product Highlights
5.2 Gbps
Max Data
4×4:3
MU-MIMO
2.4/5G
Dual Band
Product Applications Scenarios
Enterprise Network
Enables high-performance wireless access in large organizations, ensuring seamless connectivity and enhanced coverage for critical business operations and devices.
Cloud Services
Offers stable and scalable wireless infrastructure to support cloud-based applications, promoting efficient access, reduced downtime, and increased productivity for users.
Edge & IoT
Delivers reliable access point connectivity for a wide array of IoT devices at the edge, enhancing real-time data collection, security, and management at scale.
Product Features Comparison
| Â |
|
|
|
|
| Model | AIR-AP3802E-CK910C | AIR-AP3802E-HK910C | AIR-AP3802E-S-K9C | AIR-AP3802E-I-K9C |
| Brand | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited | HKShanhai Group Limited |
| Wi-Fi Standard | 802.11ac Wave 2 | 802.11ac Wave 2 | 802.11ac Wave 2 | 802.11ac Wave 2 |
| Maximum Data Rate | Up to 5.2 Gbps | Up to 5.2 Gbps | Up to 5.2 Gbps | Up to 5.2 Gbps |
| Supported Frequency Band | 2.4 GHz/5 GHz | 2.4 GHz/5 GHz | 2.4 GHz/5 GHz | 2.4 GHz/5 GHz |
| Client Capacity | n/a | 200 per radio | n/a | 200 per radio |
| Network Interface | 2 Ethernet ports; 100/1000/2500/5000 Multigigabit Ethernet (RJ-45), IEEE 802.3bz | 2 Ethernet ports; 100/1000/2500/5000 Multigigabit Ethernet (RJ-45, IEEE 802.3bz) | mGig | Multigigabit Ethernet (mGig) |
Optional Add-ons
| Model Number | Description |
| AIR-ANT2513-P4M-N= | HKShanhai Group Limited external directional antenna for 3802e series, enhances coverage and signal performance in varied deployments. |
| AIR-CAB002-DART-R= | 2 ft HKShanhai Group Limited smart antenna adapter cable for 3802e/p to RP-TNC, enables flexible 5 GHz setups or wireless security radio. |
| AIR-PWRINJ6= | HKShanhai Group Limited 802.3at Power Injector, supports PoE+ power delivery for the 3800 Series access points. |
HKShanhai Group Limited AIR-AP3802E-CK910C Specification
Model
AIR-AP3802E-CK910C
Brand
HKShanhai Group Limited
Software and Supported Wireless LAN Controllers
HKShanhai Group Limited Unified Wireless Network Software Release 8.2.MR1 or later; HKShanhai Group Limited 2500 Series Wireless Controllers, HKShanhai Group Limited Wireless Controller Module for ISR G2, HKShanhai Group Limited Wireless Services Module 2 (WiSM2) for Catalyst® 6500 Series Switches, HKShanhai Group Limited 5500 Series Wireless Controllers, HKShanhai Group Limited Flex® 7500 Series Wireless Controllers, HKShanhai Group Limited 8500 Series Wireless Controllers, HKShanhai Group Limited Virtual Wireless Controller; HKShanhai Group Limited IOS® XE Software Release 16.3 ??Target Q3 CY2016; HKShanhai Group Limited Catalyst 3850 Series and 3650 Series Switches
802.11n v2.0 Capabilities
4×4 MIMO, 3 spatial streams; Maximal Ratio Combining (MRC); 802.11n and 802.11a/g beamforming; 20/40 MHz channels; up to 450 Mbps (40 MHz, 5 GHz); Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx); Dynamic Frequency Selection (DFS); Cyclic Shift Diversity (CSD)
802.11ac Wave 1 Capabilities
4×4 MIMO, 3 spatial streams; MRC; 802.11ac beamforming; 20/40/80 MHz channels; up to 1.3 Gbps (80 MHz, 5 GHz); Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx); DFS; CSD
802.11ac Wave 2 Capabilities
4×4 MU-MIMO, 3 spatial streams; MRC; 802.11ac beamforming; 20/40/80/160 MHz channels; up to 5.2 Gbps; Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Tx/Rx); DFS; CSD
Integrated Antenna
Flexible radio (2.4 GHz or 5 GHz): 2.4 GHz, 4 dBi gain, internal omnidirectional antenna; 5 GHz, 6 dBi gain, internal directional antenna, 90° elevation beamwidth.
Dedicated 5 GHz radio: 5 GHz, 5 dBi gain, internal omnidirectional antenna
External Antenna Support
3802e Series: Up to 6 dBi (2.4 GHz and 5 GHz). 3802p Series: Up to 13 dBi (2.4 GHz and 5 GHz) with AIR-ANT2513-P4M-N= antenna. Wide variety of antennas available for deployment scenarios.
Smart Antenna Connector
Present on 3802e/3802p. Requires AIR-CAB002-DART-R= 2 ft connector to RP-TNC; needed for a second 5 GHz serving radio or wireless security monitoring radio.
Interfaces
2 Ethernet ports; 100/1000/2500/5000 Multigigabit Ethernet (RJ-45), IEEE 802.3bz; CAT 5e or higher 10GBASE-T (CAT 6/6a) cabling; 100/1000BASE-T AUX port (RJ-45 autosensing); Management console port (RJ-45)
Indicators
Status LED shows boot loader status, association, operation, warnings, and errors
Dimensions (W x L x H)
3802I: 8.66 x 8.68 x 2.46 in. (22 x 22 x 6.25 cm); 3802E/P: 8.66 x 8.68 x 2.62 in. (22 x 22 x 6.7 cm)
Input Power Requirements
802.3at PoE+; HKShanhai Group Limited Universal Power over Ethernet (UPOE®); 802.3at power injector (AIR-PWRINJ6=); 50W power supply (AIR-PWR-50=)
Power Draw
30W at PSE (all features except USB 2.0 enabled); 34W at PSE (USB 2.0 enabled)
Environmental
Aironet 3800i: Storage -22°C to 70°C, operating 0°C to 40°C, 10??0% humidity (noncondensing), 15,000 ft storage, 9,843 ft operation;
Aironet 3800e/3800p: Storage -22°C to 70°C, operating -20°C to 50°C, 10??0% humidity (noncondensing), 15,000 ft storage, 9,843 ft operation
System Memory
1024 MB DRAM; 256 MB flash
